Tokina Varifocal Lens TVR3314DC Specifications

VARIFOCAL LENS
TVR3314DC
SPECIFICATION
MODEL NUMBER
IMAGE FORMAT
FOCAL LENGTH
MAXIMUM APERTURE
APERTURE RATIO
ANGLE
OF
VIEW
OPERATING TEMPERATURE RANGE
OPERATING HUMIDITY RANGE
●DC IRIS
CABLE COLOR CONNECTION
WHITE DRIVING COIL+
GREEN DRIVING COIL-
BLACK DAMPING COIL+
RED DAMPING COIL-
●DC-IRIS LENS CONNECTOR
4 PIN CONNECTOR
E4-191J-100: 1PCS to lens
DESIGN AND SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE
f = 3.3 - 8mm F 1.4 DC IRIS
M.O.D.
DIAGONAL
HORIZONTAL
VERTICAL
DIMENSIONS
WEIGHT
MOUNT
TOKINA Co.,Ltd.
Security Products Division
120-4 NOZUTA-MACHI,MACHIDA-SHI,
TOKYO, 195-0063 JAPAN
TEL:+81-42-734-8912 FAX:+81-42-735-1463
E-mail:cctv@tokina.co.jp
TVR3314DC
1/3inch
3.3-8mm
F1.4
F1.4-360
0.3m
W104.52° T45.32°
W81.95° T36.24°
W60.65° T27.15°
W44.5×H40.5×D31.0mm
60g
-10°C - 45°C
30% - 70%
CS
