- Page 1 ENGLISH HOME THEATER SOUND SYSTEM TH-BC1 Thank you for purchasing a JVC product. Before operation, please read the instructions carefully. INSTRUCTIONS GVT0326-003A[US] 0411WMKMDWJMM © 2011 Victor Company of Japan, Limited...
- Page 2 arnings, Cautions and Othe arnings, Cautions and Others CAUTION CAUTIO CAUTION button in any position does not disconnect the mains line. • Do no button in any position does not disconnect the mains line. Disconnect the mains plug to shut the power off completely (the open Disconnect the mains plug to shut the power off completely (the STANDBY lamp goes off).
- Page 3 CAUTION • Do not block the ventilation openings or holes. (If the ventilation openings or holes are blocked by a newspaper or cloth, etc., the heat may not be able to get out.) • Do not place any naked flame sources, such as lighted candles, on the apparatus.
-
Page 4: Notes On Handling
ntroduction Auto power save function When no operation is done in certain situations for 29 minutes, the unit turns off automatically. This function is on at the initial setting. For details, refer to “Operations.” In this manual, the remote control buttons are used for explaining the operations unless mentioned otherwise. -
Page 5: Supplied Accessories
Do not block the vents Blocking the vents may damage the System. Care of the cabinet • Stains on the System should be wiped off with a soft cloth. If the System is heavily stained, wipe it with a cloth soaked in water diluted neutral detergent and wrung well, then wipe clean with a dry cloth. -
Page 6: External Components
roubleshooting If you have a problem with this System, check this list for a possible solution before calling for service. POWER Power does not come on. The power cord is not inserted securely. Plug it in securely. The unit turns off suddenly. Auto power save function is on. - Page 7 pecifications Output power 60 W (30 W + 30 W) at 4 Ω (10% THD) Audio section Analog Input ANALOG: 1 Vrms/50 kΩ Digital Input* DIGITAL 1 (OPTICAL) : –21 dBm to –15 dBm (660 nm ±30 nm) DIGITAL 2 (COAXIAL): 0.5 Vp-p/75 Ω...
-
Page 8: Preparing The Remote Control
etting started DO NOT connect the p etting started DO NOT connect the power cord until all other connections have been made. Preparing the remote control Installing the unit Preparing the remote control When you use the remote control for the first time, pull out the insulation sheet. Install the unit on a flat and level surface to ensure the best sound quality. -
Page 9: Installing The Unit
Installing the unit Install the unit on a flat and level surface to ensure the best sound quality. • The sound may be affected depending on the location in which you install it. To avoid such issues, change the location and orientation of the unit. •... - Page 10 Connecting the TV remote pass through cable If you install the unit near the TV, the unit may block the remote control signal of the TV, and it may not be transmitted to the TV unit. Connect the TV remote pass through cable (supplied) to the unit for smooth signal transmission.
-
Page 11: Connecting External Components
Connecting external components You can connect an analog component to the ANALOG IN terminal and digital components to the (OPTICAL) DIGITAL IN 1 and (COAXIAL) DIGITAL IN 2 terminals. You can also connect a subwoofer to the SUBWOOFER PRE-OUT terminal. Subwoofer (not supplied) RCA pin plug cord... -
Page 12: Basic Operation
perations power cord until all other connections have been made. Connecting the TV remote pass through cable Installing the unit Connecting external components If you install the unit near the TV, the unit may block the remote control signal Install the unit on a flat and level surface to ensure the best sound quality. of the TV, and it may not be transmitted to the TV unit. - Page 13 Basic operation Turning on/off the power Press NOTE • A small amount of power is consumed even when the power is turned off (standby mode). During standby mode, the STANDBY indicator lamp on the front panel lights up. Unplug the power cord from the AC outlet to turn the power off completely.
-
Page 14: Adjusting The Volume
Adjusting the volume Press VOLUME +/–. CAUTION • Set the volume to the minimum level before starting any source. If the volume is set to a high level, the sudden blast of sound may damage your hearing and blow out the speakers. Turning off the sound temporarily Press MUTING. -
Page 15: Adjusting The Sound Level
Adjusting the sound level You can adjust the bass and treble sound level within the range of –3 to +3. Press BASS/TREBLE repeatedly to select the sound you want to adjust. – BASS: Adjusts the bass sound level. – TREBLE: Adjusts the treble sound level. -
Page 16: Listening To Fm Radio
Listening to FM radio Selecting the station Press FM. Press UP or DOWN to select the station. 4 or ¢ for 2 seconds, then release it to change the • Press and hold frequency automatically until a station of sufficient signal strength is tuned in. Presetting stations You can preset up to 30 stations.
