JVC TH-BC3 Instructions

ENGLISH
W
arnings, Cautions and Others /
For U.S.A.
HOME THEATER SOUND SYSTEM
The lightning flash with arrowhead symbol,
TH-BC3
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
"dangerous voltage" within the product's
enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to
the presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
Pour les Etats-Unis
Le symbole de l'éclair à l'intérieur d'un triangle
équilatéral est destiné à alerter l'utilisateur sur
la présence d'une "tension dangereuse" non
isolée dans le boîtier du produit. Cette tension
est suffisante pour provoquer l'électrocution
de personnes.
Le point d'exclamation à l'intérieur d'un
triangle équilatéral est destiné à alerter
l'utilisateur sur la présence d'opérations
d'entretien importantes au sujet desquelles
des renseignements se trouvent dans le
manuel d'instructions.
CAUTION
The button in any position does not disconnect the
mains line.
Disconnect the mains plug to shut the power off
completely (the STANDBY lamp goes off). The MAINS plug
or an appliance coupler is used as the disconnect device,
the disconnect device shall remain readily operable.
Thank you for purchasing a JVC product.
• When the System is on standby, the STANDBY lamp lights red.
Before operation, please read the instructions
• When the System is turned on, the STANDBY lamp goes off.
carefully.
The power can be remote controlled.
ATTENTION
For customer use:
La touche , dans n'importe quelle position, ne
Enter below the Model No. and Serial No. which are
déconnecte pas le système du secteur. Déconnectez la
located either on the rear, bottom or side of the cabinet.
fiche de secteur pour mettre l'appareil complètement hors
Retain this information for future reference.
tension (le témoin STANDBY s'éteint). La fiche secteur ou
Model No.
un coupleur est utilisé comme dispositif de déconnexion
de l'appareil, et l'appareil déconnecté doit être prêt à être
Serial No.
utilisé.
INSTRUCTIONS
GVT0327-002B[J]
• Quand le système est en attente, le témoin STANDBY est
1210WMKMDWJMM
allumé en rouge.
• Quand le système est sous tension, le témoin STANDBY
EN
s'éteint.
© 2010 Victor Company of Japan, Limited
L'alimentation peut être télécommandée.
CAUTION: Proper Ventilation
To avoid risk of electric shock and fire, and to prevent damage, locate the apparatus as follows:
1. Front: No obstructions and open spacing.
2. Sides/Top/Back: No obstructions should be placed in the areas indicated by the dimensions in the illustration.
3. Bottom: Place on the level surface. Maintain an adequate air path for ventilation by placing on a stand with a height of 10
cm (3-15/16") or more.
ATTENTION: Ventilation Correcte
Pour éviter tout risque de choc électrique et d'incendie, placez l'appareil en respectant ce qui suit:
1. Avant: Rien ne doit gêner le dégagement.
2. Flancs/Dessus/Arrière: Aucun obstacle ne doit être placé dans les zones indiquées par les dimensions dans
l'illustration.
3. Dessous: Poser l'appareil sur une surface plate. Laissez suffisamment d'espace pour que la ventilation puisse
s'effectuer correctement en plaçant l'appareil sur un socle d'une hauteur de 10 cm ou plus.
Front / Face
15 cm (5-15/16")
15 cm 15 cm (5-15/16")
(5-15/16")
10 cm (3-15/16")
For U.S.A.
Caution: Changes or modifications not expressly approved by party responsible for compliance could void the user's
authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
Pour les Etats-Unis
Attention: Les changements ou les modifications qui ne sont pas explicitement approuvés par la partie responsable de
l'observance pourraient mettre fin au droit de l'utilisateur d'utiliser le matériel.
Remarque: Cet appareil a été testé et il s'est avéré conforme aux limites applicables à un appareil numérique de
classe B, en vertu de la Partie 15 des Règles de la FCC. Ces limites sont conçues de manière à assurer une protection
raisonnable contre les interférences nuisibles dans une installation résidentielle. Cet appareil produit, utilise et peut
émettre une énergie de haute fréquence et, s'il n'est pas installé et utilisé en conformité avec les instructions, il peut
causer des interférences nuisibles aux communications radio. Il n'y a, toutefois, aucune garantie que des interférences
ne se produiront pas dans une installation particulière. Si cet appareil cause effectivement des interférences nuisibles
à la réception de la radio ou de la télévision, ce qu'on peut établir en mettant l'appareil en marche et à l'arrêt, nous
encourageons l'utilisateur à tenter de corriger l'interférence par une ou plusieurs des mesures suivantes:
– réorienter ou déplacer l'antenne de réception;
– accroître la séparation entre l'appareil et le récepteur;
– brancher l'appareil dans une prise ou un circuit autre que celui auquel le récepteur est branché;
– consulter un vendeur ou un technicien radio/TV expérimenté pour obtenir de l'aide.
M
ises en garde, précautions et indications diverses
CAUTION CAUTION
Battery shall not be exposed to excessive heat such as • Do not block the ventilation openings or holes. (If the
sunshine, fire or the like. ventilation openings or holes are blocked by a newspaper
ATTENTION or cloth, etc., the heat may not be able to get out.)
Les piles ne doivent en aucun cas être exposées à une • Do not place any naked flame sources, such as lighted
chaleur excessive (lumière du soleil, feu, etc.). candles, on the apparatus.
• When discarding batteries, environmental problems must
CAUTION
be considered and local rules or laws governing the disposal
To reduce the risk of electrical shocks, fire, etc.:
of these batteries must be followed strictly.
1. Do not remove screws, covers or cabinet.
• Do not expose this apparatus to rain, moisture, dripping
2. Do not expose this appliance to rain or moisture.
or splashing and that no objects filled with liquids, such as
ATTENTION
vases, shall be placed on the apparatus.
Afin d'éviter tout risque d'électrocution, d'incendie, etc.:
ATTENTION
1. Ne pas enlever les vis ni les panneaux et ne pas ouvrir le
• Ne bloquez pas les orifices ou les trous de ventilation. (Si
coffret de l'appareil.
les orifices ou les trous de ventilation sont bloqués par un
2. Ne pas exposer l'appareil à la pluie ni à l'humidité.
journal un tissu, etc., la chaleur peut ne pas être évacuée
correctement de l'appareil.)
This device compiles with RSS-210 of Industry Canada
• Ne placez aucune source de flamme nue, telle qu'une
Rules. Operation is subject to the following two conditions:
bougie, sur l'appareil.
(1) this device may not cause interference, and
• Lors de la mise au rebut des piles, veuillez prendre en
(2) this device must accept any interference, including
considération les problèmes de l'environnement et suivre
interference that may cause undesired operation of the
strictement les règles et les lois locales sur la mise au
device.
rebut des piles.
• N'exposez pas cet appareil à la pluie, à l'humidité, à un
Cet appareil est conforme au réglement CNR-210 de
égouttement ou à des éclaboussures et ne placez pas des
l'industrie du Canada. L'utilisation de ce dispositif est
objets remplis de liquide, tels qu'un vase, sur l'appareil.
autorisée seulement aux conditions suivantes:
(1) il ne doit pas produire de brouillage et (2) l'utilisateur
This device complies with Part 15 of the FCC Rules.
du dispositif doit étre prét à accepter tout brouillage
Operation is subject to the following two conditions:
radioélectrique reçu, même si ce brouillage est susceptible
(1) This device may not cause harmful interference, and
de compromettre le fonctionnement du dispositif.
(2) this device must accept any interference received,
including interference that may cause undesired operation.
For Canada
Changes or modifications not expressly approved by
THIS DIGITAL APPARATUS DOES NOT EXCEED THE CLASS
the manufacturer for compliance could void the user's
B LIMITS FOR RADIO NOISE EMISSIONS FROM DIGITAL
authority to operate the equipment.
APPARATUS AS SET OUT IN THE INTERFERENCE-CAUSING
EQUIPMENT STANDARD ENTITLED "DIGITAL APPARATUS,"
Cet appareil est conforme à la partie 15 des règles
ICES-003 OF THE DEPARTMENT OF COMMUNICATIONS.
de la FCC (Federal Communications Commission). Le
fonctionnement est sujet aux deux conditions suivantes:
Pour le Canada
(1) Cet appareil ne peut pas causer d'interférences
CET APPAREIL NUMERIQUE RESPECTE LES LIMITES
nuisibles, et (2) cet appareil doit accepter toute
DE BRUITS RADIOELECTRIQUES APPLICABLES AUX
interférence reçue, y compris des interférences qui
APPAREILS NUMERIQUES DE CLASSE B PRESCRITES DANS
peuvent causer un mauvais fonctionnement.
LA NORME SUR LE MATERIEL BROUILLEUR; "APPAREILS
Tout changement ou modification non expressément
NUMERIQUES", NMB-003 EDICTEE PAR LE MINISTRE DES
approuvés par le fabricant pour conformité peut annuler
COMMUNICATIONS.
l'autorité de l'utilisateur d'utiliser l'appareil.
For U.S.A.
WARNING
TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE
THIS APPARATUS TO RAIN OR MOISTURE.
Pour les Etats-Unis
AVERTISSEMENT
POUR PRÉVENIR LES RISQUES D'INCENDIE OU DE CHOCS
ÉLECTRIQUES, NE PAS EXPOSER CE APPAREIL À LA PLUIE
OU À L'HUMIDITÉ.
[European Union only]
[Union européenne seulement]
Playable iPod models • "Made for iPod" and "Made for iPhone" mean that an
electronic accessory has been designed to connect
• Compatible iPod:
specifically to iPod or iPhone, respectively, and
has been certified by the developer to meet Apple
Made for Audio Video
performance standards. Apple is not responsible for
iPod nano (6th generation) *
the operation of this device or its compliance with
iPod nano (5th generation)
safety and regulatory standards. Please note that the
iPod nano (4th generation)
use of this accessory with iPod or iPhone may affect
wireless performance.
iPod nano (3rd generation)
• iPhone, iPod, iPod classic, iPod nano and iPod touch
iPod nano (2nd generation) –
are trademarks of Apple Inc., registered in the U.S.
iPod touch (4th generation)
and other countries.
iPod touch (3rd generation)
iPod touch (2nd generation)
• HDMI, the HDMI logo and High-Definition Multimedia
iPod touch Interface are trademarks or registered trademarks of
HDMI Licensing LLC.
iPod classic
• HDCP is the abbreviation of "High-bandwidth Digital
iPhone 4
Content Protection," and is the high-reliable copy
iPhone 3GS control technology licensed by Digital Content
Protection, LLC.
iPhone 3G
* Only for still picture
• In this manual, "iPod" means iPod, iPod touch and
• Also refer to the instruction manual for iPod.
iPhone device. When iPod touch or iPhone device
• If the NOT SUPP indicator is shown on the display, the
is especially referred to, "iPod touch" or "iPhone" is
connected iPod is not supported.
used.
• If iPod does not play correctly, update iPod software to
the latest version.
– For details about updating iPod, check on the Apple
web site <http://www.apple.com/>.
USA ONLY
I
ntroduction
Do not block the vents
Auto power save function
Blocking the vents may damage the System.
When no operation is done in certain situations for 29
Care of the cabinet
minutes, the unit turns off automatically. This function is
• Stains on the System should be wiped off with a soft
on at the initial setting. For details, refer to "Operations."
cloth. If the System is heavily stained, wipe it with a cloth
soaked in water diluted neutral detergent and wrung
In this manual, the remote control buttons are used for
well, then wipe clean with a dry cloth.
explaining the operations unless mentioned otherwise.
• Since the System may deteriorate in quality, become
However, if the System has the same or similar button
damaged or get its paint peeled off, be careful about the
names, they can also be used for the operations.
following:
– DO NOT wipe it forcefully.
Notes on handling – DO NOT wipe it with thinners, benzines or other
organic solvents including disinfectants.
Important cautions
– DO NOT apply any volatile substances such as
Installation of the System
insecticides to it.
• Select a place which is level, dry, and neither too hot nor
– DO NOT allow any rubber or plastic to remain in contact
too cold; between 5°C and 35°C (41°F and 95°F).
with it for a long time.
• Leave sufficient distance between the System and the TV.
• Do not place anything on top of the System. Doing so
• Do not use the System in a location near heat sources,
may cause the System to fall, causing malfunctioning
or in a place subject to direct sunlight, excessive dust, or
and/or injury.
vibration. • The manufacturer accepts absolutely no liability for any
• Install the System in a location with adequate ventilation accidents or damage resulting from inadequate assembly
to prevent internal heat buildup. or mounting, insufficient strength of attachment, misuse
Power cord or abuse, or natural disasters.
• Do not handle the power cord with wet hands. If water gets inside the System
• A small amount of power is always consumed while the Turn the System off and disconnect the power cord from
power cord is connected to the wall outlet.
the wall outlet, then call the store where you purchased
• Do not pull on the cord to unplug the power cord. When
this System. Using the System in this condition may cause
unplugging the power cord, always grasp and pull the
a fire or electrical shock.
plug so as not to damage the cord.
To prevent malfunctions of the System
Supplied accessories
• There are no user-serviceable parts inside. If anything
goes wrong, unplug the power cord and consult your
Check to make sure you have all of the supplied accessories.
dealer. If anything is missing, contact your dealer immediately.
• Do not insert any metallic objects or liquids into the • Remote control RM-STHBC3J (× 1)
System. • AC adaptor (AA-R1904) (× 1)
• AC power cord (× 1)
Safety precautions
• Lithium coin battery CR2025 (× 1)
Avoid moisture, water, and dust
– The battery has been installed in the remote control
Do not place the System in moist or dusty places.
when shipped from the factory.
Avoid high temperatures
• Core filter (× 2)
Do not expose the System to direct sunlight and do not
• TV remote pass through cable (× 1)
place it near any heating devices.
• Double-sided adhesive tape (× 1)
When you are away
• FM antenna (× 1)
When away on holiday or for other reasons for an extended
period of time, disconnect the power cord from the wall
outlet.
S T
pecifications roubleshooting
Output power 60 W (30 W per channel- If you have a problem with this System, check this list for a
measure at 1 kHz Optical possible solution before calling for service.
Digital In at full scale
POWER
sinewave), RMS at 4 Ω at 1
Power does not come on.
kHz, with 10% total harmonic
=
The power cord is not inserted securely. Plug it in
distortion
securely.
Audio section
The unit turns off suddenly.
Analog Input ANALOG: 1 Vrms/50 kΩ
=
Auto power save function is on. Refer to "Activating/
Digital Input* DIGITAL 1 (OPTICAL) :
deactivating APS (Auto Power Save)" in "Basic
–21 dBm to –15 dBm (660 nm
operation."
±30 nm)
REMOTE CONTROL
DIGITAL 2 (COAXIAL) :
0.5 Vp-p/75 Ω The remote control does not work.
=
Pull out the insulation sheet.
Speaker section
=
Sunlight is shining directly on the remote sensor. Hide
Type: Bass-Reflex Type
the remote sensor from direct sunlight.
Speaker: Woofer: 8 cm (3-3/16") cone × 4
=
The path between the remote control and the remote
Tweeter: 2.5 cm (1") balance
sensor on the front panel is blocked.
dome × 2
=
Point the remote control at the remote sensor on the
Power Handling Capacity: 30 W
front panel.
Impedance: 4 Ω
=
Signals cannot reach the remote sensor. Move closer to
Frequency Range: 82 Hz to 25 kHz
the unit.
Sound Pressure Level: 88 dB/W•m
=
The battery is exhausted. Replace the battery.
General
The remote control of the TV does not work.
Power Source (DC IN): DC 19 V 3.37 A =
If you install the unit near the TV, connect the TV remote
AC adaptor (AA-R1904): Input: AC 100 – 240 V ,
pass through cable (supplied).
50 Hz/60 Hz, 1.5 A – 0.9 A
FM tuner
Output: DC19 V 3.37 A
Hard to listen to broadcasts because of noise.
Power Consumption(in Standby mode):
=
Electrostatic discharge from your body may cause noise.
0.50 W or less
If this happens, turn off and on the unit again.
Dimensions (W × H × D): 900 mm ×98 mm × 107 mm
External components
(35-7/16" × 3-7/8" × 4-3/16")
Mass: 3.4 kg (7.4 lbs) No sound can be heard when DIGITAL 1 or DIGITAL 2 is
selected as a source.
=
Tuner Check the output setting of the connected digital
components. Set the output setting as the PCM signal
FM tuning range: 87.5 MHz – 108.0 MHz
is outputted.
iPod
iPod
Output power: DC 5 V 1 A iPod cannot be connected firmly.
=
Check to see whether the connector between iPod and
the unit is not damaged, and connect it.
HDMI
iPod does not provide sound.
HDMI Input: HDMI 1 IN, HDMI 2 IN*
=
iPod is not properly connected. Remove iPod from the
HDMI Output: HDMI OUT
unit, and then connect it again.
Max. Capability: 1920 × 1080 at 60 Hz
iPod cannot be charged.
Output power: DC 5 V 55 mA
=
iPod is not properly connected. Remove iPod from the
* Corresponding to Linear PCM (with sampling frequency
unit, and then connect it again. After connecting iPod,
— 32 kHz, 44.1 kHz, 48 kHz)
turn on the power again.
HDMI
Designs & specifications are subject to change without
No sound can be heard when HDMI 1 or HDMI 2 source
notice.
is selected as a source.
=
Check the output settings on the HDMI connected
devices. Set the audio output setting to PCM signal and
enable HDMI Audio Out.
No sound can be heard when TV ARC is selected as a
source.
=
Check if your TV supports this function and turn on the
settings for ARC and set the digital audio output setting
to PCM signal on your TV.
