IP ADVANCED RADIO SYSTEM
IP501H
IP503H
Thank you for choosing this Icom product.
READ ALL INSTRUCTIONS carefully and completely
before using this product.
EXPLICIT DEFINITIONS
WORD
R DANGER Personal death, serious injury or an
R WARNING! Personal injury, fire hazard or electric
CAUTION
NOTE
Icom is not responsible for the destruction, damage to,
or performance of any Icom or non-Icom equipment, if
the malfunction is because of:
• Force majeure, including, but not limited to, fires,
earthquakes, storms, floods, lightning, other natural
disasters, disturbances, riots, war, or radioactive
contamination.
• The use of Icom transceivers with any equipment that
is not manufactured or approved by Icom.
Icom, Icom Inc. and the Icom logo are registered trademarks
of Icom Incorporated (Japan) in Japan, the United States,
the United Kingdom, Germany, France, Spain, Russia,
Australia, New Zealand, and/or other countries.
The Bluetooth
trademarks owned by the Bluetooth SIG, Inc. and any use
of such marks by Icom Inc. is under license.
Other trademarks and trade names are those of their
respective owners.
1-1-32 Kamiminami, Hirano-ku,
Osaka 547-0003, Japan
Jun. 2020
explosion may occur.
shock may occur.
Equipment damage may occur.
If disregarded, inconvenience only. No risk
of personal injury, fire or electric shock.
word mark and logos are registered
®
INSTRUCTIONS
DEFINITION
© 2012–2020 Icom Inc.
A7415D-2EX-2
Printed in Japan
Advertisement
Table of Contents
Related Manuals for Icom IP501H
Summary of Contents for Icom IP501H
- Page 1 • The use of Icom transceivers with any equipment that is not manufactured or approved by Icom. Icom, Icom Inc. and the Icom logo are registered trademarks...
- Page 2 R DANGER! NEVER use or charge Icom battery packs with non-Icom transceivers or non-Icom chargers. Only Icom battery packs are tested and approved for use with Icom transceivers or charged with Icom chargers. Using thirdparty or counterfeit battery packs or chargers may cause smoke, fire, or cause the battery to burst.
-
Page 3: D Battery Caution
R WARNING! Immediately stop using the battery if it emits an abnormal odor, heats up, or is discolored or deformed. If any of these conditions occur, contact your Icom dealer or distributor. R WARNING! Immediately wash, using clean water, any part of the body that comes into contact with fluid from inside the battery. -
Page 4: D Charging Caution
10°C ~ 40°C (50°F ~ 104°F) BC-218: 10°C ~ 40°C (50°F ~ 104°F) Icom recommends charging the battery at 25°C (77°F). The battery may heat up or rupture if charged out of the specified temperature range. Additionally, battery performance or battery life may be reduced. -
Page 5: Safety Training Information
Only interference to radio or television reception, which can be Icom battery packs are tested and approved for use with determined by turning the equipment off and on, the user Icom transceivers or charged with Icom chargers. Using... -
Page 6: Technical Information
Technical Information IP501H SAR 10g: 0.63 W/kg Frequency Band Version 3G (W-CDMA) 4G (LTE) Bluetooth FDD-LTE B1, B3, B7, B1, B8 B8, B20 2402 – TD-LTE B38, B40 2480 MHz FDD-LTE B2, B4, B5, B2, B5 Output Power Version 3G (W-CDMA) -
Page 7: Panel Description
PANEL DESCRIPTION NOTE: Instructions and screens on this guide may diff er, depending on the settings. [PWR/VOL] Antenna dial [TX/RX] indicator Function [PTT] screen switch [Option] Keypad key*1 Microphone Speaker* *1 Ask your dealer about the assigned function. *2 While connecting an optional speaker microphone, the audio is not output from the internal speaker. - Page 8 D Function Display Standby screen Example: When receiving a custom message 10/4 13:00 10/4 12:57 All Gather immediately Scrolls, depending on the message length : Signal strength The signal strength is represented by 3 bars. In the 3G mode, the received signal strength is indicated by the icon.
-
Page 9: Basic Operation
• A beep sounds. The dial rotation is made tight to resist dust and water Turn intrusion. IP501H Ver. . . / 10/4 12:57 Standby screen Turning OFF Turn [PWR/VOL] maximum counter clockwise until it makes a "click"... -
Page 10: Battery Charging
Lights green: Charged If the indicator blinks in orange, read the IP501H/ IP503H instruction manual on the Icom web site. Fully charge the battery pack when the fi rst time of use or has not been used for more than 2 months. -
Page 11: Attaching The Battery Pack
ATTACHING THE BATTERY PACK Follow the order (q ~ w) in the illustration below. After attaching, check that the battery pack is securely attached. (2 sliding locks are in the place.) Battery pack CAUTION: Even when the transceiver's power is OFF, a small current still fl ows in the transceiver. - Page 12 OPTIONS D Carrying case LC-185 (For use with BP-272) MB-57L: Shoulder strap D Battery Pack BP-272: Li-ion Battery Pack Voltage: 7.4 V Capacity: Minimum: 1880 mAh, Typical: 2000 mAh Operating time: 17 hours (TX:RX:Standby=5:5:90) D Chargers BC-202IP2: Rapid Charger (with BC-123S) BC-202IP3L: Rapid Charger (with BC-123S) BC-211:...
