Star TSP100IIIW Easy Setup Manual

Introduction
This manual describes the setup procedures for the TSP100IIIW. It also describes the connection settings to
be made over a wireless LAN with a DHCP server, using WPS*. When you would like to know how to install the
utility software or driver, when the network used does not have a DHCP server, or when a wireless LAN access
point or router does not support WPS* , and setup and connection does not proceed smoothly, refer to the
online manual for the TSP100IIIW.
* WPS : A standard for making easy connections between wireless networking devices.
Check the Supplied Accessories
TSP100III Power Cord*
Set Up the Printer
1
Inserting a Roll of
Paper
Push the cover opening lever

open the rear cover .
2
1

When using a paper roll with 58 mm width,
install the supplied paper guide on the
printer.
To change the paper width, the memory
switch must be set. Refer to the online
manual for details.
3
Connect to the Network
Press and hold the PAIR button until LED
(blue) starts
flashing.
(about 2sec.)
RST PAIR
Easy Setup Guide
Roll Paper
Paper Roll Guide

and then Insert a roll of paper in the direction shown in
the illustration.
Pull the end of the paper out straight
push down both sides of the printer cover to

close .
3
Press the WPS button of the access point
or router. When the printer connects to
the network, it will print the connection
information and its LED (blue) will change
from flashing
to solid.
1.0A
5V DK
If any of the package contents are missing or damaged, contact the dealer where the
product was purchased.
*Accessories vary depending on the region where the printer was purchased.
Switch Cover Rubber Feet
Holder Plate

, and
4
O
OF F
I
ON
WPS
TSP100IIIW
TSP100IIIW
online manual
www.star-m.jp/
tsp100iiiw-oml.html
Safety Instructions
Screws(2)
2
Turn ON the Main Unit
Power
Connect the included power cable to the inlet
on the back side of the TSP100III
plug of the power cable to the outlet
2
Turn on the power to the TSP100III
check the LED (blue) to light up
O
O F
F I
O N
3

Operation for access points and routers
varies according to your device. For details,
refer to your device manual.
When a connection cannot be made, start
from step 3 and perform the settings
again.
 If your POS software requires a static IP
address, please continue to next section
"Assigning a static IP address".
This Manual
Easy Setup Guide
 . Connect the

.
1

, and

.
4
