Managing Authentication Plug-Ins - Red Hat CERTIFICATE SYSTEM 7.3 - ADMINISTRATION Administration Manual

6. Verify that the certificate is installed in the browser's certificate database.
7. If directory- or PIN-based authentication was configured with PIN removal, re-enroll for another
certificate using the same PIN. The request should be rejected.

16.7. Managing Authentication Plug-ins

Custom authentication plug-in modules can be registered through the CA Console. Authentication
plug-in modules can also be deleted through the CA Console. Before deleting a module, delete
instances that are based on that module.
To register or delete a module:
1. Log into the Console.
pkiconsole https://server.example.com:9443/ca
2. In the Configuration tab, click Authentication in the navigation tree
3. In the right pane, click the Authentication Plug-in Registration tab.
The tab lists modules that are already registered.
4. To delete a registered module, select that module, and click Delete.
5. To register a plug-in, click Register.
The Register Authentication Plug-in Implementation window appears.
6. Specify which module to register by filling in the two fields:
• Plugin name. The name for the module.
• Class name. The full name of the class for this module. This is the path to the implementing
Java™ class. If this class is part of a package, include the package name. For example, to
register a class named customAuth in a package named com.customplugins, the class
name is com.customplugins.customAuth.
7. Click OK.
Managing Authentication Plug-ins
389
