Summary of Contents for CONDTROL Omniliner 3D
- Page 1 Cross line laser Kreuzlinienlaser Лазерный нивелир Laser krzyżowy Omniliner 3D/G3D EN User manual DE Bedienungsanleitung RU Руководство пользователя PL Instrukcja obsługi...
-
Page 2: Safety Instructions
Cross line laser Omniliner 3D/G3D User manual SAFETY INSTRUCTIONS Attention! This user manual is an essential part of this product. The user manual should be read carefully before you use the product for the first time. If the product is given to someone for temporary use, be sure to enclose user manual to it. -
Page 3: Product Description
PRODUCT DESCRIPTION CCross line lasers Omniliner 3D/G3D CONDTROL are intended to project vertical and horizontal planes. They project one 360° horizontal and two 360° vertical planes and provide compensation of the slope up to ±4°. The laser levels have 2 operating modes: - Automatic leveling to compensate irregularities within self-leveling range of ±... - Page 4 Laser level – 1 pc. Battery – 2 pcs. Charger – 1 pc. Remote control – 1 pc. Bag – 1 pc. User manual – 1 pc. TECHNICAL SPECIFICATIONS Omniliner 3D Omniliner G3D Working range/ 50 m/100 m with receiver Self-levelling accuracy ±0,2 mm/m Self-levelling range ±...
-
Page 5: Operation
Relative humidity <90% Dust and water IP65 protection rate Thread for mounting 1/4’’, 5/8’’ on a tripod Class II 635 nm Class II 520 nm Laser type < 1 mW < 1 mW Battery 3.7V 5200 mAh Li-ion Dimensions 140х138х110 mm Weight - without battery 660 g... - Page 6 ACCURACY CHECK Check of horizontal line Use 2 parallel vertical walls which are located opposite each other at a distance of 5 m. 1. Set the instrument close to the wall A (see Fig. A). Switch on the vertical and horizontal laser emitters, unlock the compensator.
-
Page 7: Care And Maintenance
UTILIZATION Expired tools, accessories and package should be passed for waste recycle. Please send the product to the following address for proper recycle: CONDTROL GmbH Wasserburger Strasse 9 84427 Sankt Wolfgang Germany Do not throw the product in municipal waste! According to European directive 2002/96/ЕC expired... -
Page 8: Warranty
6) After holding warranty works by CONDTROL GmbH warranty period is not renewed or extended. 7) CONDTROL GmbH is not liable for loss of profit or inconvenience associated with a defect of the device, rental cost of alternative equipment for the period of repair.
