MikroTik mANTBox Manual

mANTBox series
The mANTBox is a solid and waterproof outdoor device based on the RB911 wireless router series. It has high power
802.11b/g/n wireless, and one Gigabit Ethernet connector, which supports MDI-X auto detection. The device has a built in
Sectoral antenna. The device is packaged with a 24V power adapter, a PoE injector and a mounting kit.
First use
1. Unscrew the lid screw by hand, or with a hex screwdriver.
2. The device accepts 10-28V Passive PoE from a PoE injector (please compensate voltage for loss due to cable length)
or from the power jack
3. The default IP address from Ether1 is 192.168.88.1 for configuration
Username is admin and there is no password
Powering
The device comes included with a 24V 0.8A power adapter. It can be used with the included PoE injector, or the power jack.
Device accepts 8-30V for both methods. Maximum power consumption of the device is 11W at 24V. Please use the PoE
injector with the DATA+POWER end connected to the mANTBox unit, and DATA end to your switch or PC.
Booting process
Connect to wireless SSID "MikroTik" and open 192.168.88.1 in your web browser. Username is admin and there is no
password. In case IP connection is not available, Winbox can be used to connect to the MAC address of the device.
More information here:
In case you wish to boot the device from network, for example to use MikroTik Netinstall, hold the RESET button of the device
when starting it until the LED light turns off, and the device will start to look for Netinstall servers.
Mounting
The mANTbox 12s comes with a QuickMount adapter that can be attached to a wall using the included screws, or attached to
a pole, using the included metal mounting ring. The QuickMount allows the device to be adjusted horizontally and vertically.
The mANTbox 12s comes with metal pole brackets, that clamp around metal poles. More detailed instructions for assembly
are available on http://routerboard.com
Please avoid connecting a loose Ethernet cable to the Ethernet port - secure the cable to a wall or the pole, so that the cable
weight is not pulling the port. It is recommended to secure the Ethernet cable less than 2m from the device. This is to ensure
that the cable doesn't damage the port by its weight, or doesn't fall out.
It is possible to connect a grounding wire to the device, by opening the lid, a grounding screw is provided there.
Expansion Slots and Ports
 Built in 2,4GHz, 802.11b/g/n wireless, 2x2 MIMO, AP/staton/bridge modes supported
 One 10/100/1000 Gigabit Ethernet port, supporting automatic cross/straight cable correction (Auto MDI/X), so you can
use either straight or crossover cable for connecting to other network devices. The Ethernet port accepts 10-28V DC
powering from a passive PoE injector.
See www.routerboard.com for more information. Contact
http://wiki.mikrotik.com/wiki/First_time_startup
support@mikrotik.com for support questions. 19-Jun-18
