- Page 1 INSTALLATION GUIDE 60" 16-UCT60 SINGLE CROSSBAR 60" NO FEET 1630-TCX 1630-PCX Scan the QR for the latest Install-Guide.
-
Page 2: Before You Begin
• Incorrect installation could cause water leaks, electric shock or fire. • Any cargo vehicle with any cargo or equipment should use a certified partition. See Ranger Design website for some partition options. (https://rangerdesign.com/) • Mountings rails are recommended for any attachment to the vehicle walls. - Page 3 QUICK START GUIDE Phase 1 - Assembly q 1.1.1 S )....................eTuP erify arTs are resenT q 1.2.1 a ............................ssembly 16-UCT60 Installation Guide | REV. A2 | Page 3 of 6 For technical support, contact us at 1-800-565-5321...
-
Page 4: Phase 1 - Assembly
Flat Washer 4× 4× 5/16" OD, 3/4" # 98-117 SS18-8 #90-998 Hex Bolt 3/4" Lock Washer 4× 4× 5/16" # 98-123 SS304 16-UCT60 Installation Guide | REV. A2 | Page 4 of 6 For technical support, contact us at 1-800-565-5321... - Page 5 TOOLS q Cordless Impact q 1/2" Socket FASTENERS USED FRONT LADDER HOOK 8× RUNG STOPPER #90-998 Hex Bolt 3/4" 2 - 3/4" 16-UCT60 Installation Guide | REV. A2 | Page 5 of 6 For technical support, contact us at 1-800-565-5321...
- Page 6 1.2.2 Position the 16-UCT60 single crossbar no feet as indicated in the image below. 16-UCT60 single crossbar 60" no feet 77" ( crossbar center to center “Thank you for doing business with us.” cs@rangerdesign.com For any feedback or suggestions you might have, please contact: 16-UCT60 Installation Guide | REV.
