Fiber Solution
NetWaySP2BT Series
802.3bt Media Converter/Injectors
Models Include:
NetWaySP2BT
- 802.3bt Media Converter/Injector
- Modular plastic case.
NetWaySP2BTWPN
- 802.3bt Media Converter/Injector.
- NEMA4/4X rated outdoor enclosure.
Installation Guide
DOC#: NetWaySP2BT Rev. 012925
Installing Company: _______________ Service Rep. Name: __________________________________
Address: _____________________________________________ Phone #: __________________
NetWaySP2BTWP
- 802.3bt Media Converter/Injector with
Integral Power.
- NEMA4/4X rated outdoor enclosure.
NetWaySP2BTWPX
- 802.3bt Media Converter/Injector with
Integral Power.
- NEMA4/4X rated outdoor enclosure.
- Accommodates up to
four (4) 12VDC/4AH batteries.
More than just power.
TM
Advertisement
Related Manuals for Altronix Spectrum NetWaySP2BT Series
Summary of Contents for Altronix Spectrum NetWaySP2BT Series
- Page 1 Fiber Solution NetWaySP2BT Series 802.3bt Media Converter/Injectors Models Include: NetWaySP2BT NetWaySP2BTWP - 802.3bt Media Converter/Injector - 802.3bt Media Converter/Injector with - Modular plastic case. Integral Power. - NEMA4/4X rated outdoor enclosure. NetWaySP2BTWPN NetWaySP2BTWPX - 802.3bt Media Converter/Injector. - 802.3bt Media Converter/Injector with - NEMA4/4X rated outdoor enclosure.
- Page 2 Overview: Altronix NetWaySP2BT Series 802.3bt media converter/injectors provide two (2) 802.3bt (4PPoE) ports up to 180W total and accommodate Fiber (1000Base-X/SX/LX) or structured cable to transmit data. Units can be deployed with structured cable, conventional single/multimode fiber or composite cable (fiber + copper combined).
-
Page 3: Installation Instructions
Recommended Altronix Power Sourcing Equipment (for NetWaySP2BT and NetWaySP2BTWPN): NetWaySP4P Ethernet to Fiber Media Converter with Integral Power Supply/Charger. Four (4) 56VDC non power-limited outputs up to 120W max. full power per port (240W total power). Four (4) 1Gb SFP ports. - Page 4 Power Connection (NetWaySP2BT and NetWaySP2BTWPN): 1. Use external 48-55V UL Listed ITE power supply, carefully observing correct polarity (Fig. 1, pg. 4). 2. Use 14AWG or larger for all power connections. Power Connection (NetWaySP2BTWP and NetWaySP2BTWPX): 1. Connect AC power from overcurrent protective device circuit breaker (20A @ 115VAC, 60Hz or 16A @ 230VAC, 50/60Hz) to the terminals marked [L, N] on power supply board (Fig.
-
Page 5: Typical Application
Typical Application: Fig. 2 Brooklyn, NY U.S.A. www.altronix.com NetWaySP2BT NetWaySP2BT Converts Ethernet or Fiber to 802.3bt Converter/Injector Input: 48–56VDC two (2) 802.3bt PoE ports Output: IEEE 802.3bt (180W) 48-56VDC 802.3bt 802.3bt Fiber – Input + Output Signal Output Signal From power supply... - Page 6 Fig. 3 - NetWaySP2BT Fig. 3a Brooklyn, NY U.S.A. www.altronix.com NetWaySP2BT 802.3bt Converter/Injector Input: 48–56VDC Output: IEEE 802.3bt (180W) 48-56VDC 802.3bt 802.3bt Fiber – Input + Output Signal Output Signal Optional Earth Ground 48-56VDC – Input + Fig. 4 - NetWaySP2BTWPN Brooklyn, NY U.S.A.
- Page 7 Fig. 5 - NetWaySP2BTWP Brooklyn, NY U.S.A. www.altronix.com NetWaySP2BT 802.3bt Converter/Injector Input: 48–56VDC Output: IEEE 802.3bt (180W) 48-56VDC 802.3bt 802.3bt Fiber 48-56VDC 802.3bt 802.3bt Fiber – Input + – Input + Output Output Signal Signal Output Output Signal Signal Ground...
- Page 8 Fig. 6 - NetWaySP2BTWPX Optional rechargeable Optional rechargeable battery battery Brooklyn, NY U.S.A. www.altronix.com NetWaySP2BT 802.3bt Converter/Injector Input: 48–56VDC Output: IEEE 802.3bt (180W) 48-56VDC 48-56VDC 802.3bt 802.3bt 802.3bt 802.3bt Fiber Fiber – Input + – Input + Output Output Signal...
-
Page 9: Wall Mount Installation
This installation should be made by qualified service personnel. This product contains no serviceable parts. PMK1 and PMK2 outdoor pole mount kits are designed to simplify the installation of Altronix outdoor rated power supplies and accessories housed in models WP1, WP2, WP3 and WP4 NEMA rated enclosures. PMK1 and PMK2 can be mounted on 2”... - Page 10 NetWaySP2BTWPN Mechanical Drawing and Dimensions (H x W x D approx.): 9.5” x 7.32” x 4.92” (241.3mm x 185.9mm x 125mm) 1.38” 7.32” (185.9mm) 3.54” (89.9mm) (35.1mm) 316 Stainless Steel Padlock Latch Attached 0.375” (9.5mm) Padlock Eye 6.75” (171.5mm) 6.0” (152.4mm) 4.25”...
- Page 11 NetWaySP2BTWP Enclosure Drawing and Dimensions (H x W x D approx.): 13.31” x 11.31” x 5.59” (338.1mm x 287.3mm x 142mm) FRONT VIEW RIGHT SIDE VIEW 11.31” (287.3mm) 3.96” (100.6mm) FRONT VIEW COVER REMOVED END VIEW 10.75” (273.1mm) 10.00” (254mm) STAINLESS STEEL PIANO HINGE 8.25”...
- Page 12 WALL MOUNTING HOLE X 4 10-32 X 0.250 BRASS INSERT 4 PLCS. 12.00” (304.8mm) Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty...
