- Page 1 KEEP FOR FUTURE REFERENCE ROWE This instruction booklet covers model: AX-ROW-123-CP INSTALLATION / USER MANUAL VADO Wedmore Road, Cheddar, Somerset, England BS27 3EB tel 01934 744466 fax 01934 744345 BATH SHOWER MIXER www.vado.com sales@vado.com Version 1, 1-10-20...
-
Page 2: General Installation
Important - please read Contents of Packaging Please read these instructions carefully before starting installation and keep for Fixing Kit future reference. Remove all packaging and check the product for missing parts or damage before starting installation. Any alterations made to this product and fittings may infringe water regulations and will invalidate the guarantee. - Page 3 Dimensions Installation - Quick guide 99mm 150mm 1/2” 137mm 150±20mm 40mm 190mm...
-
Page 4: Installation
Installation Operation: Offset connector ½” connector Shroud Control handle Cold Locking nuts Rubber filter/washer Shower hose Lifting the mixer lever upwards will Pull up the diverter handle to connection increase the flow of water. change outlets. Push down the diverter and go back Before installing your new mixer, flush through the pipe work to ensure removal of to the primary outlet. -
Page 5: Cleaning Instructions
Cleaning instructions: Notes: Our products are finished to the highest standard and due care needs to be taken to ensure their looks are retained. We recommend cleaning all products with a soft damp cloth ONLY and advise strongly against the use of ALL cleaning products i.e. powders and liquids. If the above instructions are not followed this will invalidate your guarantee in the event of a problem occurring. - Page 6 •The extended guarantee is only available if you have completed the Guarantee Registration Process. This can be done via the VADO website or via phone to our aftersales team. Registration must be completed within 6 months from date of purchase.
