TPS6125xEVM-766, 3.5-MHz High Efficiency Step-Up
This user's guide describes the characteristics, operation, and use of the TPS6125xEVM-766 evaluation
module (EVM). This EVM enables test and evaluation of the Texas Instruments' TPS61253, TPS61258,
and TPS61259 devices, a series of 3.5-MHz, up to 5.1-V, step-up dc-dc converters. This user's guide
includes EVM specifications, the schematic diagram, bill of materials, and board layout.
1
2
3
4
5
6
1
TPS6125xEVM-766 Schematic
2
TPS61253 in Power Save Mode Operation with 40-mA load
3
4
5
6
7
8
9
PS6125xEVM-766 Inner Layer 2 (Viewed from Top)
10
1
Table 1. TPS6125xEVM-766 Output and Input Voltage Options and Ordering Information
2
SLVU744 - August 2012
Submit Documentation Feedback
Downloaded from
Elcodis.com
electronic components distributor
Converter In Chip Scale Packaging EVM
..................................................................................................................
...........................................................................................
..................................................................................................
.................................................................................................................
.............................................................................................................
...........................................................................................
....................................................................................
TPS6125xEVM-766, 3.5-MHz High Efficiency Step-Up Converter In Chip
Copyright © 2012, Texas Instruments Incorporated
Contents
...................................................................
List of Figures
.........................................................
......................................................................
...................................................................
...................................................................
..........................................................
..................................................................
..............................................................
.................................................................
........................................................
List of Tables
User's Guide
SLVU744 - August 2012
2
3
4
5
8
13
3
5
6
7
7
8
9
10
11
12
......................
3
13
1
Scale Packaging EVM
Advertisement
Table of Contents
Related Manuals for Texas Instruments TPS61253EVM-766
Summary of Contents for Texas Instruments TPS61253EVM-766
-
Page 1: Table Of Contents
This user's guide describes the characteristics, operation, and use of the TPS6125xEVM-766 evaluation module (EVM). This EVM enables test and evaluation of the Texas Instruments' TPS61253, TPS61258, and TPS61259 devices, a series of 3.5-MHz, up to 5.1-V, step-up dc-dc converters. This user's guide includes EVM specifications, the schematic diagram, bill of materials, and board layout. -
Page 2: Introduction
Double-sided, two-active-layer printed circuit board (PCB) with all components on top side • Active converter area of approximately 25 mm TPS6125xEVM-766, 3.5-MHz High Efficiency Step-Up Converter In Chip SLVU744 – August 2012 Scale Packaging EVM Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated Downloaded from Elcodis.com electronic components distributor... -
Page 3: Tps6125Xevm-766 Schematic
Up to 1000 mA peak output current. TPS6125xEVM-766 Schematic Figure 1. TPS6125xEVM-766 Schematic SLVU744 – August 2012 TPS6125xEVM-766, 3.5-MHz High Efficiency Step-Up Converter In Chip Scale Packaging EVM Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated Downloaded from Elcodis.com electronic components distributor... -
Page 4: Connector And Test Point
By default, J8 is not assembled on the EVM. TPS6125xEVM-766, 3.5-MHz High Efficiency Step-Up Converter In Chip SLVU744 – August 2012 Scale Packaging EVM Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated Downloaded from Elcodis.com electronic components distributor... -
Page 5: Test Results
Figure 2. TPS61253 in Power Save Mode Operation with 40-mA load SLVU744 – August 2012 TPS6125xEVM-766, 3.5-MHz High Efficiency Step-Up Converter In Chip Scale Packaging EVM Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated Downloaded from Elcodis.com electronic components distributor... -
Page 6: Tps61253 In Pwm Operation With 260-Ma Load
PWM Operation Figure 3. TPS61253 in PWM Operation with 260-mA Load TPS6125xEVM-766, 3.5-MHz High Efficiency Step-Up Converter In Chip SLVU744 – August 2012 Scale Packaging EVM Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated Downloaded from Elcodis.com electronic components distributor... -
Page 7: Tps61253 Load Transient From 100 Ma To 300 Ma
Figure 5. TPS61253 Load Transient from 100 mA to 500 mA SLVU744 – August 2012 TPS6125xEVM-766, 3.5-MHz High Efficiency Step-Up Converter In Chip Scale Packaging EVM Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated Downloaded from Elcodis.com electronic components distributor... -
Page 8: Tps6125Xevm-766 Assembly Drawing And Layout
EXAS NSTRUMENTS Figure 6. TPS6125xEVM-766 Component Placement (Viewed TOP) TPS6125xEVM-766, 3.5-MHz High Efficiency Step-Up Converter In Chip SLVU744 – August 2012 Scale Packaging EVM Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated Downloaded from Elcodis.com electronic components distributor... -
Page 9: Tps6125Xevm-766 Top Copper (Viewed From Top)
TPS6125xEVM-766 Assembly Drawing and Layout www.ti.com Figure 7. TPS6125xEVM-766 Top Copper (Viewed from Top) SLVU744 – August 2012 TPS6125xEVM-766, 3.5-MHz High Efficiency Step-Up Converter In Chip Scale Packaging EVM Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated Downloaded from Elcodis.com electronic components distributor... -
Page 10: Tps6125Xevm-766 Inner Layer 1 (Viewed From Top)
Figure 8. TPS6125xEVM-766 Inner Layer 1 (Viewed from Top) TPS6125xEVM-766, 3.5-MHz High Efficiency Step-Up Converter In Chip SLVU744 – August 2012 Scale Packaging EVM Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated Downloaded from Elcodis.com electronic components distributor... - Page 11 Figure 9. PS6125xEVM-766 Inner Layer 2 (Viewed from Top) SLVU744 – August 2012 TPS6125xEVM-766, 3.5-MHz High Efficiency Step-Up Converter In Chip Scale Packaging EVM Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated Downloaded from Elcodis.com electronic components distributor...
-
Page 12: Tps6125Xevm-766 Bottom Copper (Viewed From Bottom)
TPS6125xEVM-766 Assembly Drawing and Layout www.ti.com Figure 10. TPS6125xEVM-766 Bottom Copper (Viewed from Bottom) TPS6125xEVM-766, 3.5-MHz High Efficiency Step-Up Converter In Chip SLVU744 – August 2012 Scale Packaging EVM Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated Downloaded from Elcodis.com electronic components distributor... -
Page 13: Bill Of Materials
5. Install label in silkscreened box after final wash. Text shall be 8 pt font. Text shall be per Table 1. SLVU744 – August 2012 TPS6125xEVM-766, 3.5-MHz High Efficiency Step-Up Converter In Chip Scale Packaging EVM Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated Downloaded from Elcodis.com electronic components distributor... -
