EarFun Free Mini Manual

What's in the Box

Product Diagram

Touch button control zone
Microphone
Earbuds LED indicator
Charging contactor
USB-C charging port
Charging case
Charging dock
Charging case indicator

Specifications

Bluetooth version	V5.0
Bluetooth frequency	2.402GHz-2.48GHz
Bluetooth transmitted power	<7dBm
Bluetooth profile	A2DP, AVRCP, HFP, HSP
Maximum working range	15m(without obstacle)
Battery capacity	40mAh x 2(earbuds); 470mA(charging case)
Charging time	1.5 hour(for earbuds); 2.5 hours(for charging case via USB-C);
Playtime:	Up to 5 hours, Totally 24 hours with the charging case; (varies by volume level and audio content)
Input	DCSV/1A
Dimensions	55mm x 26mm x 43mm
Weight	38g

How to fit

information Note: If the earbuds are not worn correctly, they may affect the bass effect.

How to fit

Choose the ear tips that fit your ears the best.
Identify the left and right earbuds.
Insert the earbuds into the canal of your ears.
Turn and find the most comfortable position.

Pairing Your Earbuds

First-time Pairing with Device
Step 1: Remove both earbuds from the charging case simultaneously, and the earbuds will automatically power on and enter into pairing mode.
Step 2: Activate Bluetooth on your Bluetooth-enabled device and search for other Bluetooth devices.
Step 3: Select "EarFun Free Mini" from the list of Bluetooth devices shown (if a password is needed, type '0000').

information Notes:

The earbuds will automatically connect with the device they were last paired with when the case is open.
Each earbud could be used independently.

Connect to a New Device
Step 1. Unpair the earbuds from the Bluetooth-enabled device that's connected. The earbuds will disconnect from the current device and enter into pairing mode for another pair.
Step 2. Search on the new device and connect.

Functions

Power on/off
Open the charging case and pick up the earbuds, the earbuds will automatically power on. Place the earbuds back into the charging case, the earbuds will automatically power off.

information Note:
If the earbuds are not connected to any device, they will automatically power off after 5 minutes for saving the battery life.

Playing music
Playing music - Step 1
Playing music - Step 2

Hands free conversation

Activate the voice assistant

Earbuds LED Indicator

Power on	Blue indicator flashes 1 second
Power off	Red indicator flashes 1 second
Pairing mode	Indicator flashes blue
Successfully connected	Indicator goes out
Charging	Red always ON
Factory reset	Indicator flashes purple (blue+ red)

Reset and Manually Pairing

Reset Bluetooth Connection
If you fail to build connection between earbuds and Bluetooth device, please try the following steps:

Keep the earbuds out of the charging case, touch and hold the earbuds button for at least 10 seconds to turn off both earbuds and make sure the both earbuds power off.
In power-off mode, touch and hold the button on each earbud at the same time for at least 10 seconds until they flash purple 3 times then earbuds have been reset successfully.
Delete the old connection from the Bluetooth device and reconnect "EarFun Free Mini".

Left and Right Manually Pairing
If the left or right earbud is disconnected alone, you may need to manually pair them again.

Troubleshooting

Q: Can I use both earphones separately?
A: Yes, each earbud could be used independently.

Q: The earphones are turning on, but it doesn't connect to my device?
A: To connect the earbuds to your device, please check if the Bluetooth of the device is on at first, then select 'EarFun Free Mini' on the Bluetooth list to get paired. If the earbuds still can't connect to your device, please try to reset it, or contact our customer support.

Q: Why the connection is not stable and cuts out intermittently?
A: Please make sure there are no objects between the earphones and your Bluetooth device, and make sure there is no radio or WIFI interference nearby.

Q: What is the range of Bluetooth earphones?
A: Bluetooth earphones have maximum range of 49 feet (15m, no obstacle). However, the actual range will depend on usage and environment.

Q: Is there volume control on the earphones?
A: Yes, touch L earbud once decreases the volume and touch R once could increase it.

Q: Is the charging case waterproof?
A: No, the earbuds are IPX7 sweat & waterproof, but the charging case is not waterproof.

Customer Service
For FAQS and more information
Please Email to: service@myearfun.com
www.myearfun.com
