EarFun Wave Pro HP200B Manual

EarFun Audio App

Download the EarFun Audio app for an enhanced experience

• No Forced Registration. Easy to Use.
• Multi-Band EQ, Multipoint Devices Management.
• Game Mode, Firmware Update, and More.

Please update your headphones firmware to the latest version via the EarFun Audio app for the best user experience. If headphones can't connect to the app, reinstall or update the app in the app store.

What's in the Box

Product Diagram

1. MFB Button
2. Volume +/- Button
3. ANC Control Button
4. Headphone Status LED Indicator
5. Microphone
6. 3.5mm AUX Audio Input Jack
7. USB-C Charging Contactor
8. Charging LED Indicator

Pairing Your Unit

First-time Pairing with Device

1. Press and hold the MFB button for 2 seconds to power on the headphones. It will automatically enter into pairing mode.
2. Activate Bluetooth on your Bluetooth-enabled device and search for other Bluetooth devices.
3. Select "EarFun Wave Pro" from the list of Bluetooth devices shown. (if a password is needed, type '0000').

Notes:
The headphones will automatically connect with the previously paired device when power on again.

Connect to a New Device

Option A

1. Unpair the headphones from the Bluetooth-enabled device that's connected. The headphones will disconnect from the current device and go into pairing mode to be paired again.

2. Search on the new device and connect.


Option B

1. Press triple MFB button quickly in connecting status. The headphones will disconnect from the current device and go into pairing mode.
2. Search on the new device and connect.

Pairing and Connecting two Bluetooth Devices Simultaneously

1. Pair with the first device and stay connected.

2. Press triple MFB button quickly. The headphones will enter pairing mode and will disconnected from the first device.

3. Search on the second device to connect the headphones.

4. Manually reconnect the headphones on the first device.


Notes:
The headphones will automatically connect to both devices after finishing setting up the multipoint connection.

Functions

Power on:
Press and hold MFB button for 2 seconds

Power off:
Press and hold MFB button for 5 seconds

Note: If the headphones are not connected to any devices, they will automatically power off after 30 minutes for saving the battery life.

Playing music

Noise cancelling control

Hands free conversation

Activate the voice assistant

Game Mode

Please enable in EarFunAudio app

Device Status LED Indicator

Reset and Reconnecting

If you fail to establish a connection between the headphones and Bluetooth devices, please try the following steps:

1. Press and hold MFB button for 5 seconds to power off headphones
2. Press and hold the MFB button for at least 10s until headphones status LED indicate in pink, and then release the button. The Headphones have been reset successfully.
3. Power on headphones again and then delete the previous connection from the Bluetooth device and reactivate Bluetooth to reconnect "EarFun Wave Pro".

Charging

Connect USB-C cable for charging

1. Please clean the USB-C charging port before charging
2. Fully charge the headphones before first use.
3. You can check the headphones battery level from the Bluetooth device or EarFun Audio app
4. The headphones will power off automatically after connecting to charging.

AUX Input

1. The headphones will power off and disconnect Bluetooth connection when plugging in the AUX audio cable.

2. In AUX input mode, the audio connects to the transducer directly, disabling volume and play/pause control on the headphones, and also can't be controlled by the EarFun Audio app. Please use the front-end device to adjust the volume and play/pause.

Note:
Please ensure that the volume of front-end device is turned down to minimum to protect hearing when connecting the AUX audio. Adjust the volume of front-end device after putting on this headphones.

Specifications

Connectivity	Bluetooth
Bluetooth frequency	2.402GHz-2.480GHz
Bluetooth profile	A2DP, AVRCP, HFP
Bluetooth transmitted power	<7dBm (for EU)
Maximum working range	15m(without obstacle)
Battery capacity	800mAh
Charging time	2 hours
Playtime(varies by volume level and audio content)	ANC OFF - Up to 80 hours ANC ON - Up to 55 hours
Input	5V 1A
Dimensions	159.7mm x 82.4mm x 210.8mm
Weight	268g

Troubleshooting

The headphones are turning on, but it doesn't connect to my device?
To connect the headphones to your device, please ensure headphone is power-on, then check if the Bluetooth is enabled. If the headphones still don't connect to your device, please perform a reset or contact our customer support.

Why is the connection not stable and cuts out intermittently?
Please make sure there are no objects between the headphones and your Bluetooth device and make sure there is no radio or WIFI interference nearby.

What is the range of the unit

Bluetooth headphones have maximum range of 49 feet (15m, no obstacle). However, the actual range will depend on usage and environment

My device will not switch on

Please recharge them and make sure they have enough battery power. If they are fully charged and still nothing happens or if you are not able to charge them, please contact our customer support.

Will the device shut off automatically?

The headphones will stay on as long as they are connected to a device. If no audio is playing, they will enter power-saving mode and wake up once audio playback resumes. If the headphones are not connected to any devices they will automatically power off after 30 minutes.

Customer Service

For FAQS and more information:
Please send an email to: service@myearfun.com
www.myearfun.com
