Carrot XL
Car Seat
Installation and
User Manual
CARROT XL
#4116-0020-259
IMPORTANT CONSUMER INFORMATION NOTICE:
This manual contains important instructions that
must be passed on to the user of this product.
Please do not remove this manual before delivery
to the end user.
SUPPLIER:
This manual must be given to the user of this product.
USER:
Before using this product, read entire manual and save
for future reference.
User Manual for Carrot XL Car Seat
Manual: Carrot_20240326
Serial Number:
Advertisement
Table of Contents
Related Manuals for Medifab Carrot XL
Summary of Contents for Medifab Carrot XL
- Page 1 Please do not remove this manual before delivery to the end user. SUPPLIER: User Manual for Carrot XL Car Seat This manual must be given to the user of this product. Manual: Carrot_20240326 USER:...
- Page 2 Read Before Use Welcome The Carrot 3000 XL Car Seat is a larger version of the standard Carrot 3000 Car Seat, designed to offer a configuration to meet the needs of larger children that require additional seat growth. Always consult a medical professional to make sure that this restraint system is suitable for your child.
-
Page 3: Table Of Contents
Table of Contents Warning Safety Information Features Installation Functions Securing Your Child Optional Accessories Care and Maintainance Product Dimensions Warranty... -
Page 4: Warning
Incorrect reassembly may • Attach the Carrot XL Car Seat to the vehicle’ s seat using both compromise the car seat’ s performance. upper and lower fixing straps, and always use the vehicle’ s lap and shoulder (3-point) safety belts as well. -
Page 5: Safety Information
• It is recommended to use this car seat in an upright 90° position unless specified by a health professional. SAFETY STANDARDS & CERTIFICATION • The Carrot XL Car Seat is specifically designed for children weighing between 40kg and 75kg. It has undergone successful crash testing with a 75kg dummy, beyond the... - Page 6 It is NOT sufficient to secure a child solely with the 4-point harness straps of the car seat. It is legally required to always use the vehicle’ s 3-point lap and shoulder safety belt together with the Carrot XL 4-point H-Harness to secure both the car seat and the child.
-
Page 7: Features
Features Head Support Head Pillow Shoulder Protector Wing Belt Loop Guides Comfort Pads 4-point Harness Strap Back Support XL Seat Base Tray Feet Reciever Head Support Fixing Strap Metal Yoke Backrest Release (D-shape) Ring Instruction Manual (In Pocket) Seat Depth Adjuster Knob Lower Fixing Strap... -
Page 8: Installation
Installation STANDARD INSTALLATION Fixing Strap Installation 1. Begin by installing the provided fixing straps at both the upper and lower sections of the car seat. 2. Attach the car seat head support to the vehicle seat head support using the upper fixing strap and secure the car seat’ s main body to the vehicle seat using the lower fixing strap. -
Page 9: Functions
Functions HEAD SECTION IMPORTANT: Head-Support Depth Adjustment Adjusting the Head Support position (forward/backward) The Head Support can be requires tools. Please contact your local distributor for adjusted forward or backward assistance with adjustments. in 15mm increments, ensuring a better fit and enhanced protection for the occupant. - Page 10 Functions BACK SUPPORT SECTION IMPORTANT: Adjusting the Back Support To release the locking • The Shoulder Harness mechanism, pull the Back Strap height adjusts along Support Release (D-shaped) with the Back Support Ring on the back of the car height. seat.
-
Page 11: Securing Your Child
Securing Your Child Once you have installed the Carrot XL Car Seat on the vehicle’ s seat and made necessary adjustments, follow these instructions to secure your child in the seat: 1. Loosen the Carrot XL 4-point H-Harness and unfasten both the upper and lower buckles. - Page 12 Securing Your Child IMPORTANT • Ensure that the Carrot XL 4-point H-Harness is positioned to properly hold the child’ s hips as deep as possible. • Reconfirm that the 4-point harness is not twisted and that the child is properly secured.
-
Page 13: Optional Accessories
Optional Accessories TRAY TABLE The X-Large supporting tray table is specifically designed for the Carrot XL car seat, providing extra support to secure the child’ s upper limbs. TILT WEDGE This foam wedge is used to increase and adjust the height and angle of the front of the seat section, enhancing the seat’... -
Page 14: Care And Maintainance
Do not bleach, machine wash, machine dry, or iron any of the Carrot XL components, as washing may damage the fabric. Maintaining clean upholstery is important, and periodic replacement is recommended. -
Page 15: Product Dimensions
Product Dimensions Overall Width: 51-56cm Seat Depth: 38 or 42cm Seat Width: 51cm Back Support Height: 74.5-87cm Weight Capacity: 36-75kg User Height: 145-180cm Product Weight: 10.5kg... -
Page 16: Warranty
WARRANTY LIMITATIONS This warranty does not cover damages resulting from negligence, misuse, or use that does not comply with the product instructions. The use of non-genuine Carrot XL covers, inserts, toys, accessories, or installation devices is not approved. Using such items may cause the child seat to fail safety standards, such as ECE regulation No.16,... - Page 17 Warranty LIMITED ONE-YEAR WARRANTY Product and Purchase Details Product Model: Date of Purchase: Distributor: Your Detaills Your Name: Phone: Email Address: Street Address: City: Zip Code: State: Country:...
- Page 18 Distributed by Medifab Ltd +64 3 307 9790 solutions@medifab.com medifab.com DISTRIBUTED BY: Manual: Carrot_20240326...
