Medifab Ltd
solutions@medifab.com
New Zealand: Call 0800 543 343
7-9 Allens Road, Ashburton 7700
Australia: Call 1300 543 343
26 Pardoe Street, Devonport, TAS 7310
www.medifab.com
Kidslover Car Seat
Installation &
User manual
IMPORTANT CONSUMER INFORMATION NOTICE: This manual
contains important instructions that must be passed on to the
user of this product. Please do not remove this manual before
delivery to the end user.
SUPPLIER: This manual must be given to the user of this product.
USER: Before using this product, read entire manual and save for
future reference.
User Manual for all Kidslover Car Seats (product code begins with "4170")
Manual: Kidslover20140613
Advertisement
Table of Contents
Related Manuals for Medifab kidslover
Summary of Contents for Medifab kidslover
- Page 1 Serial Number: Medifab Ltd solutions@medifab.com New Zealand: Call 0800 543 343 User Manual for all Kidslover Car Seats (product code begins with “4170”) 7-9 Allens Road, Ashburton 7700 Australia: Call 1300 543 343 Manual: Kidslover20140613 26 Pardoe Street, Devonport, TAS 7310...
- Page 2 Providers of Rehabilitation Technology Kidslover Disabled Child Car Seat Instructions...
-
Page 3: Table Of Contents
Behinderten - Kinderautositz Kidslover Dear Customer, We would like to thank you for purchasing our ‚Kidslover‘ special needs car seat. Prior to installation and use of this seat in a vehicle, in the interest of correct and safe use, we ask that you read carefully and understand this instruction manual. -
Page 4: General Information
The seat can be installed and used on the passenger side or on the drivers side (location to be specified at purchase). In addition to the vehicles 3-point seat belt, the Kidslover car seat is equipped with a 5-point support harness, with both shoulders, lap and crotch strap, to provide added support for the child. -
Page 5: Safety
Kidslover - Disabled Child Car Seat Kidslover - Disabled Child Car Seat Behinderten - Kinderautositz Kidslover Safety Before use – all components must be checked for proper function. The operating instructions must always be carried on the car seat. -
Page 6: Component Overview - Kidslover
Kidslover - Disabled Child Car Seat Behinderten - Kinderautositz Kidslover Component Overview - Kidslover Base Plate Framework Seat Plate Seat Depth Adjustment Plate Back Plate Mount Bracket for Seat Belt Guide Seat Belt Guide - Shoulder Seat Belt Guide - Lap Seat Cushion 10. -
Page 7: Adjustments - Kidslover 1 And 2
Kidslover - Disabled Child Car Seat Behinderten - Kinderautositz Kidslover Adjustments Kidslover 1 and 2 Seat Depth Adjustment Remove the Seat Cushion. Loosen the screws (1) and slide the Seat Depth Adjustment Plate to the desired position. ... -
Page 8: Component Overview - Accessories
Kidslover - Disabled Child Car Seat Behinderten - Kinderautositz Kidslover Component Overview – Kidslover Accessories Seat Recline Adjustment Swivel Base Release Abductor Pommell Footrest Trunk Supports (Left / Right) Stabiliser Bracket / Iso-fix Padded Playtray / Crash Pad Outer Leg Supports (Left / Right) -
Page 9: How To Use - Accessories
Kidslover - Disabled Child Car Seat Behinderten - Kinderautositz Kidslover How to Use Kidslover Accessories Abductor Pommell To remove the Abductor Pommell, loosen the quick clamp lever (1), simply lift out the Pommell (2) from the retaining bracket (3). - Page 10 Kidslover - Disabled Child Car Seat Behinderten - Kinderautositz Kidslover Setting the Footrest Open the quick release lever each side(1) Adjust the knee angle as required (2) close both quick relaese levers to set (1) Open the Allen screws each side (3) to set...
-
Page 11: Installation In A Vehicle
Kidslover - Disabled Child Car Seat Behinderten - Kinderautositz Kidslover Seating the Child Kidslover is designed and intended for use only in the rear seat of a car Open the Child Support Harness and if necessary release some strap to make room in the harness. -
Page 12: Seat And Accessories
Hernik GmbH. Claims, irrespective of their legal basis, in particular claims for direct or indirect damages are excluded. Hernik Kidslover Handicap Child Car Seats meet the requirements of European Standard EN 12182 and is labelled according to EU Directive 93/42/EEC. -11-... -
Page 13: Serial Number / Identification
29 to 40 cm Approved 25 kg 36 kg 75 Kg Nameplate The nameplate is readily visible on the Kidslover The Nameplate: HERNIK GmbH – Agents for Rehabilitation HERNIK GmbH - Agentur für Reha – Technik Partenhauserweg 14 – 81369 München Technology Partenhauserweg 14 –... - Page 14 Instructions for use: ISOFIX – Mounting Bracket Our seats are available with an Iso-fix Adapter Bracket option, in place of the regular clamp style Stability Bracket. The Iso-fix Adapter Bracket allows the seat to locate to existing Iso-fix attachment points in all cars after 2006.
