Carrot 3000
Swivel Base
Installation and
User Manual
# 4116-0180-104
IMPORTANT CONSUMER INFORMATION NOTICE:
This manual contains important instructions that
must be passed on to the user of this product.
Please do not remove this manual before delivery
to the end user.
SUPPLIER:
This manual must be given to the user of this product.
USER:
Before using this product, read entire manual and save
for future reference.
User Manual for all Carrot Swivel Base
Manual: Carrot Swivel- 20180813
Serial Number:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Carrot 3000 Swivel Base and is the answer not in the manual?

Questions and answers

Related Manuals for Medifab Carrot 3000 Swivel Base

Summary of Contents for Medifab Carrot 3000 Swivel Base

  • Page 1 Carrot 3000 Swivel Base Installation and User Manual # 4116-0180-104 IMPORTANT CONSUMER INFORMATION NOTICE: This manual contains important instructions that must be passed on to the user of this product. Please do not remove this manual before delivery to the end user. SUPPLIER: User Manual for all Carrot Swivel Base This manual must be given to the user of this product.
  • Page 2 Device Directive 93/42 EEC. The ISO-TURN with ISOFIX connection is produced under the control of quality management in accordance to DIN EN ISO 9100 and DIN EN 46001. Distributed in Australia/New Zealand by: Medifab Ltd Head Office: 32 Detroit Drive, Rolleston 7675, New Zealand...
  • Page 3 ISO-TURN with ISOFIX connection Instruction manual Before using the ISO-TURN To ensure the safe use of the ISO-TURN please read and use the instruction manual and especially the safety arrangements. Please understand that the instruction manual may be different to the various designs of the product.
  • Page 4 SAFETY ARRANGEMENTS Attention (this symbol means that misusage can cause a high risk of death or injury.) The following car seats are not suitable for the use with the ISO-TURN: •car seats without ISOFIX connection •car seats which are fixed sideways or backwards •car seats which are less than 40cm deep •car seats with a pronounced bulge on the seat which can lead to an unstable attachment •car seats with an two-point seat belt...
  • Page 5 Use of the ISO-TURN RULES how to fix: 1.Fix the Carrot/Carrot II on the ISO-TURN At first please solve and remove the adjustment screws of the Carrot/Carrot II. Now put the car safety seat on to the turntable so that the back of the seat is between the holders of the back angel adjustment.
  • Page 6 3.Back angel adjustment The back of the ISO-TURN and of the Carrot/Carrot II can be fitted to the back of the car seat if you solve the clamp lever at the back angle adjustment. Please push the back frame of the ISO-TURN according to the inclination of the car seat.
  • Page 7 5.Spinning process In order to turn the ISO-TURN the indexing plunger have to be unlocked. The indexing plunger is located at the top of the rotation plate, drag it upward to unlock. Now you can turn the Carrot/Carrot II with the ISO-TURN in the direction of the car door to exit it.
  • Page 8 ISO-TURN turntable with ISOFIX connection address client name phone Date of purchase Medifab Ltd dealer 32 Detroit Drive, Rolleston 7675, New Zealand Your enthusiastic distributor is New Zealand Head Office 32 Detroit Drive, Rolleston 7675 Call 0800 543 343...
