User Name:
Serial Number:
www.medifab.com
Timy Car Seat
Installation &
User manual
IMPORTANT CONSUMER INFORMATION NOTICE: This manual
contains important instructions that must be passed on to the
user of this product. Please do not remove this manual before
delivery to the end user.
SUPPLIER: This manual must be given to the user of this product.
USER: Before using this product, read entire manual and save for
future reference.
User Manual for all Timy Car Seats (product code begins with "415")
Manual: Timy20140612
Advertisement
Related Manuals for Medifab Timy
Summary of Contents for Medifab Timy
- Page 1 SUPPLIER: This manual must be given to the user of this product. USER: Before using this product, read entire manual and save for future reference. User Name: User Manual for all Timy Car Seats (product code begins with “415”) Serial Number: Manual: Timy20140612 www.medifab.com...
- Page 2 Special Needs Carseat TIMY Application area: The Timy car seat helps keeping the retention of a symmetrical and balanced seat position with posture supporting components. The seat shell can be adapted on the various needs. Extensive accessories take care that the therapeutical demands are fulfilled.
- Page 3 Installation into the car Unpacking Take the seat from the packing and remove the packaging also of the accessories. Put the seat to a just and firm pad and adjust this as follows: Back height The back and shoulder belt height is adjusted with the headrest.
- Page 4 Adapter The car safety seat Timy should as a matter of priority be occurred on the right back seat of the car. Therefore, the Timy car seat is moved to the seat with an adapter and pushed tightly against the back of the vehicle.
- Page 5 Adjustings Adapterset “Light” 300 135 The light adapter connects the rotating function with the angle adjustment at flat style and low weight. You accomplish the rotating function by pulling the red belt webbing and swiveling the seat. Different click in options are predefined.
- Page 6 Examining place/date: Mot (TÜV) Hanover registered association of 2-7-1989 Certificate: The support facilities “Child bucket seat Timy” were installed into cars of various size and manufacturer. The belts always went at proper adjustment, that particularly in the comparison with checked facilities, it can be started out of sufficient support facilities.
- Page 7 Specialist dealer confirmation The delivering specialist dealer confirms that the above customer has been delivered child bucket seat Timy junior, Timy or Timy senior in accordance with the individual needs of the child/youth is equipped and adjusted body-oriented, that a safe, stable seat position and a correct seat of the 3 point belt is ensured.
- Page 8 The seat hits at a fall from 80 cm (table edge) of height with a speed of approx. 14 km/h. Measure Timy Junior Timy Senior Maxi...
- Page 9 Security The T imy is an aid which was developed especially for disabled children. At the conception we permanently take the various needs of the needy patients into account. A documented quality control makes sure that your car safety seat fulfills the high requests. Safety After the seat's first week of use all hand screws and altering mechanisms should be checked and adjusted if necessary.
- Page 10 For replacement copies please call Medifab: (AU) 1300 543 343 or (NZ) 0800 543 343 The Timy car seat is intended for children between 3 – 12 years old, with a maximum weight limit of 36kg. The child must not exceed 36kg (except for the Timy Maxi size)
- Page 11 Installing the Timy to the Vehicle seat Shoulder belt guide: At side of backrest, unwind the small grub-screw to position the belt guide correctly for the child. Swivel ‘D’ Bar: Position the ‘D’ bar into the gap between the seat, and tighten the 2 grub screws.
- Page 12 Harness Tension: Underneath the seat, press the tension adjuster to lengthen the belt length, and then pull to tighten. Warning! Always ensure correct belt tension when child is in the Timy car seat. Medifab Ltd: www.medifab.com solutions@medifab.com New Zealand: 7-9 Allens Road, Ashburton 7700. Call 0800 543 343...
