Medifab Ltd
solutions@medifab.com
New Zealand: Call 0800 543 343
7-9 Allens Road, Ashburton 7700
Australia: Call 1300 543 343
26 Pardoe Street, Devonport, TAS 7310
www.medifab.com
Starlight Car Seat
Installation &
User manual
IMPORTANT CONSUMER INFORMATION NOTICE: This manual
contains important instructions that must be passed on to the
user of this product. Please do not remove this manual before
delivery to the end user.
SUPPLIER: This manual must be given to the user of this product.
USER: Before using this product, read entire manual and save for
future reference.
User Manual for all Starlight Car Seats (product code begins with "4140")
Manual: Starlight20140613
Advertisement
Related Manuals for Medifab Starlight
Summary of Contents for Medifab Starlight
- Page 1 Serial Number: Medifab Ltd solutions@medifab.com New Zealand: Call 0800 543 343 User Manual for all Starlight Car Seats (product code begins with “4140”) 7-9 Allens Road, Ashburton 7700 Australia: Call 1300 543 343 Manual: Starlight20140613 26 Pardoe Street, Devonport, TAS 7310...
- Page 2 Special Needs Child – Car Seat Thank you for purchasing your STARLIGHT-Reha special needs child seat, for maximum satisfaction please read and follow the enclosed instructions carefully. Should you have a question, require any advice or help please contact our offices at:...
- Page 3 4. It is necessary for the dealer to adjust and install your STARLIGHT-Reha to suit the individual needs of the child, achieving the optimal seating position for comfort and support.
- Page 4 Page 3 1. Fitting the STARLIGHT-Reha: Your STARLIGHT-Reha seat will be fitted with one of the following options: A. Iso-Fix stability bracket (fig. i). B. Tubular stability bracket option (fig. ii) (fig.i) (fig. ii) Position the chosen stability bracket into the 2 square receiving tubes provided in the base plate.
- Page 5 Page 4 (fig. iii) Use the quick clamps to adjust the angle of the footrest (ref. 5) Position the footrest to the correct height by loosening both grub screws as shown (ref. 6), slide footrest plate up or down, re-tighten grub screws when the desired position is achieved.
- Page 6 Page 5 4. Added recline option: This option allows for increased tilt, by making adjustments each side of the base plate as shown below (fig vi): Remove fixing screw and nut each side (ref. 11) Chose tilt position ...
- Page 7 Important: the STARLIGHT-Reha child seat is designed to use the vehicles seatbelt on the front of the child, the harness as fitted to the Play seat is a posture support only, always use the...
- Page 8 Page 7 7. Using the Swivel Base: STARLIGHT-Reha is available with a Swivel Base option, which allows easy access for positioning the child. This option is available for passenger or driver side. (fig. ix) (fig. x)
- Page 9 Both plunger types should lock easily when the seat is rotated back to forward facing. Care and Maintenance: 1. At 8 weekly intervals check the overall condition of the STARLIGHT-Reha seat. Check all screw and bolt connections for tightness and tighten as required, or seek advice / attention from your supplying dealer.
- Page 10 Page 9 This seat is for use in the rear seat of the vehicle and must not be positioned in the front seat at any time, otherwise you jeopardize the safety of your child. Ensure the car seat is not in contact, or damaged by moving parts in the vehicle.
- Page 11 Page 10 Dear Customer: Thank you for purchasing a STARLIGHT-Reha special needs seat, which will give your child support and growth for their transport needs. Please ensure that your supplying dealer / fitter gives you instruction in the use of the seat and all of its component parts.
- Page 12 Instructions for use: ISOFIX – Mounting Bracket Our seats are available with an Iso-fix Adapter Bracket option, in place of the regular clamp style Stability Bracket. The Iso-fix Adapter Bracket allows the seat to locate to existing Iso-fix attachment points in all cars after 2006.
