Delta PMT-5V350W1A Series Technical Data Sheet

TECHNICAL DATASHEET
PMT Panel Mount Power Supply
5V 300W 1 Phase / PMT-5V350W1A
General Description
The new PMT series of panel mount power supplies is the latest offering from one of the world's largest power supply manufacturers
and solution providers - Delta.
20°C to +70°C and can withstand shock and vibration (in accordance to IEC 60068-2-27 and IEC 60068-2-6 respectively). In addition
to features like overvoltage and overload protections, Delta's PMT series of panel mount power supplies is unlike many other brands in
the same price level. The PMT series is designed for cost competitive markets without compromising the quality of the components and
product specifications. The series of products has an expected life time of 10 years and will have no output power de-rating from
100Vac to 132Vac & 180Vac to 264Vac.
Model Information
PMT Panel Mount Power Supply
Model Number
PMT-5V350W1A☐
Model Numbering
PM T –
Panel Mount Product Type
T – Enclosed
*Options
**
For Terminal Block
All parameters are specified at 25°C ambient unless otherwise indicated.
1
www.DeltaPSU.com (February 2015, Rev. 03)
PMT-5V350W1A☐ offers a nominal output voltage of 5V with a wide operating temperature range from -
Input Voltage Range
90-132Vac, 180-264Vac
(Selectable by Switch)
5V
350W
Output Voltage Output Power
(350W series
model)
□
PMT
Highlights & Features
– AC input range selectable by switch
– Full Aluminium casing for light weight and corrosion resistant
handling
– Built-in automatic fan speed control circuit
– Wide operating temperature range from -20°C to +70°C and
cold start at -40°C
– MTBF > 700,000 hrs. as per Telcordia SR-332
– Short Circuit / Overvoltage / Overload / Over Temperature
Protections
Safety Standards
CB Certified for worldwide use
Model Number:
Unit Weight:
Dimensions (L x W x D):
Output Voltage
5Vdc
1 A
Single Phase No PFC
Series
PMT-5V350W1A☐
0.81 kg
215 x 115 x 50 mm
Output Current
60.0A
CC Code**
□ □
Connector Type Blank – Without
M – Terminal Block connector cover
N – Front Face* A – With connector
cover
