USER INSTRUCTION
PMR Panel Mount Power
PMR 1500W series / PMR-

Table of Contents

1.
General safety information ................................................................................................................................................................ 2
1.1
Safety instructions ................................................................................................................................................................. 3
1.2
Warning ................................................................................................................................................................................. 4
2.
General overview ............................................................................................................................................................................... 5
2.1
General Description ............................................................................................................................................................... 5
2.2
Connections ........................................................................................................................................................................... 6
2.3
Installation Instruction ............................................................................................................................................................ 9
3.
Electrical Functions of Main output .................................................................................................................................................. 13
3.1
Start-up timing ..................................................................................................................................................................... 13
3.2
Rise Time ............................................................................................................................................................................ 14
3.3
Hold up time......................................................................................................................................................................... 14
3.4
Protections ........................................................................................................................................................................... 15
3.4.1
Over voltage protection (OVP) ............................................................................................................................... 15
3.4.2
Over load ............................................................................................................................................................... 15
3.4.3
Short circuit protection (SCP) ................................................................................................................................ 15
3.4.4
Over temperature protection .................................................................................................................................. 15
3.5
Remote On_Off control ........................................................................................................................................................ 16
3.6
Voltage Adjustment .............................................................................................................................................................. 17
3.7
Parallel operation ................................................................................................................................................................. 18
1
www.DeltaPSU.com (November 2024, Rev. 00)
V1K5W1BT
PLEASE READ AND FULLY UNDERSTAND THIS USER
MANUAL BEFORE UNPACK AND INSTALL THE POWER
SUPPLY

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PMR 1500W Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Delta PMR 1500W Series

  • Page 1: Table Of Contents

    USER INSTRUCTION PMR Panel Mount Power PMR 1500W series / PMR- V1K5W1BT □ □ PLEASE READ AND FULLY UNDERSTAND THIS USER MANUAL BEFORE UNPACK AND INSTALL THE POWER SUPPLY Table of Contents General safety information ................................2 Safety instructions ................................. 3 Warning ....................................
  • Page 2: Highlight & Features

    USER INSTRUCTION PMR Panel Mount Power PMR 1500W series / PMR- V1K5W1BT □ □ Highlight & Features Up to 1500 Watt in 5" x 8.03" x 1.59" Package • • Up to 23.5W/inch Power Density • Full Power up to 50℃ Ambient •...
  • Page 3: Safety Instructions

    Critical Components: These products are not authorized for use as critical components in nuclear control systems, life support systems or equipment for use in hazardous environments without the express written management approval from Delta. Product Usage: These products are designed to apply in medical, industrial, commercial and IT equipment which need to use DC voltages.
  • Page 4: Warning

    Delta Electronics assumes no responsibility if the power supply is not correctly maintained according this manual. Delta Electronics assumes no responsibility for any if the power supply is modified in any way after sale. It is not allowed to disassemble the power supply without Delta’s technical support or authorization, to avoid the injury by high voltage.
  • Page 5: General Overview

    USER INSTRUCTION PMR Panel Mount Power PMR 1500W series / PMR- V1K5W1BT □ □ 2. General overview 2.1 General Description The PMR-1K5 series of internal built power supplies come with universal AC input range from 85Vac to 264Vac. The PMR-1K5 series is certified for EMC standards according to EN 55032 for Industrial Technology Equipment (ITE) radio-frequency equipment.
  • Page 6: Connections

    USER INSTRUCTION PMR Panel Mount Power PMR 1500W series / PMR- V1K5W1BT □ □ 2.2 Connections AC/DC input terminal block (CN1) CN1 is the input connector, a standard screw type 3-pin connector with clamp washer and a terminal centres pitch distance of 9.5 mm (0.37 in).
  • Page 7: User Instruction

    USER INSTRUCTION PMR Panel Mount Power PMR 1500W series / PMR- V1K5W1BT □ □ Control Connector (CVILUX CI0108P1HDL-NH OR EQUILVALENT) Mating With CVILUX CI0108SD0L0 OR EQUIVALENT Terminal: CVILUX CI01TD21PE0 OR EQUIVALENT Pin 1 CURRENT SHARING Pin 5 Pin 2 REMOTE ON/OFF +...
  • Page 8 USER INSTRUCTION PMR Panel Mount Power PMR 1500W series / PMR- V1K5W1BT □ □ Output voltage adjustment potentiometer The Output voltage adjustment potentiometer is for output voltage adjustment within the range of specifications. Fig. 7: Output voltage adjustment potentiometer Main DC output terminal (CN101)
  • Page 9: Installation Instruction

    USER INSTRUCTION PMR Panel Mount Power PMR 1500W series / PMR- V1K5W1BT □ □ 2.3 Installation Instruction The Installer Requirement: Must have necessary electric knowledge and understand the risks of electric shock;  Must read the safety warning from section 1.1-1.2 carefully ...
  • Page 10 USER INSTRUCTION PMR Panel Mount Power PMR 1500W series / PMR- V1K5W1BT □ □ Fig. 13: Position of mounting holes Note: Always keep ≥20 mm (0.79 in) space on the fan side and on the connector side to ensure proper airflow.
  • Page 11 USER INSTRUCTION PMR Panel Mount Power PMR 1500W series / PMR- V1K5W1BT □ □ Dimensional drawings Fig. 14: Dimensional drawing PMR-1K5 www.DeltaPSU.com (November 2024, Rev. 00)
  • Page 12 USER INSTRUCTION PMR Panel Mount Power PMR 1500W series / PMR- V1K5W1BT □ □ Note: Base plate mounting, M4 thread holes, maximum penetration 3.0mm (0.12 inch) from outside face of chassis, maximum torque 9.0- 10.0kgf.cm (7.8-8.6 inch.Ibs). Side mounting, M4 thread holes, maximum penetration 4.0mm (0.16inch) from outside face of chassis, maximum torque 9-10kgf.cm (7.8-8.6 inch.Ibs).
  • Page 13: Electrical Functions Of Main Output

    USER INSTRUCTION PMR Panel Mount Power PMR 1500W series / PMR- V1K5W1BT □ □ 3. Electrical Functions of Main output 3.1 Start-up timing Start-up time is defined as the time duration from when the AC is applied with remote on_off signal enabled to the output voltage reaching to higher than 90% of its final steady value.
  • Page 14: Rise Time

    USER INSTRUCTION PMR Panel Mount Power PMR 1500W series / PMR- V1K5W1BT □ □ 3.2 Rise Time Rise time is defined as the time from when the output voltage is higher than 10% regulation voltage to the point when the output voltage reaches 90% output regulation level.
  • Page 15: Protections

    USER INSTRUCTION PMR Panel Mount Power PMR 1500W series / PMR- V1K5W1BT □ □ 3.4 Protections 3.4.1 Over voltage protection (OVP) When the output voltage sees unusual high peak or the internal feedback control loop fails to lead the output voltage to be unusually high, power supple can sense the output voltage, if the output voltage is higher than certain limit (145% regulation max), the power converter will be disabled with latch mode, and require removal/re-application of input AC voltage in order to restart..
  • Page 16: Remote On_Off Control

    USER INSTRUCTION PMR Panel Mount Power PMR 1500W series / PMR- V1K5W1BT □ □ 3.5 Remote On_Off control Remote On_off control allows customer to easily control the power supply from system level point of view, PMR-1K5 series uses an isolated diode located within the power supply. The remote control signal can be used to enable or disable only the main output. When the main output is disabled, the +5V Standby output will stop to operate.
  • Page 17: Voltage Adjustment

    USER INSTRUCTION PMR Panel Mount Power PMR 1500W series / PMR- V1K5W1BT □ □ 3.6 Voltage Adjustment The power supply provides a potentiometer for user to adjust the output voltage. The output voltage is designed to be able to adjust up to ±10% of rated voltage, when the output is adjusted below nominal value, the maximum output current is the same as the nominal...
  • Page 18: Parallel Operation

    The difference in output voltage can impact the current sharing accuracy, all the units to be paralleled, please use the voltage adjustment function to set the voltage to be ±50 mV of the set value. If system application more than 2pcs power supplies need to be paralleled please contact Delta for technical support. Fig. 25: parallel connection without remote sense...
