Kuryakyn 7202 Installation

FORK SKINS FOR XL
PARTS INCLUDED
1 Narrow Fork Brace
2 Fork Brace Inner Clamp Half
1 Left Fork Skin — (Deep Caliper Cutout)
1 Right Fork Skin — (No Cutout)
1 Right Axle Cap — with Black Plastic Axle Cap Carrier — W/O Threads—'04-'07
1 Left Axle Cap — with Black Plastic Axle Cap Carrier — Threaded—'04-'07
1 Round Hole Axle Cap—'08 and Later
1 Hex Hole Axle Cap—'08 and Later
1 Hardware Kit, Including:
4 #8–32 x 1/4" Setscrews
2 1/4"–20 x 5/8" Setscrews
4 1/4"–20 x 1" Socket Head Cap Screws
1 1/2"–20 Flanged Prevailing Torque Nut
2 1/8" x 3/8"O-Ring
2 Fork Bottom Centering Inserts
1 Installation Instructions
Please read and understand entire instructions before starting installation.
THANK YOU FOR CHOOSING K
IN ORDER TO PROTECT YOU AND OTHERS FROM POSSIBLE INJURY AND/OR
PROPERTY DAMAGE OR LOSS, PLEASE PAY CLOSE ATTENTION TO ALL
INSTRUCTIONS, WARNINGS, CAUTIONS AND NOTICES REGARDING THE USE
AND CARE OF THIS PRODUCT.
IF INSTALLING THIS PRODUCT FOR ANOTHER PARTY,
PLEASE MAKE SURE THEY RECEIVE THIS COPY OF THE
INSTALLATION INSTRUCTIONS SO THEY ARE AWARE OF
THE IMPORTANT INFORMATION CONTAINED IN THEM.
TOOLS SUGGESTED
Set of Hex Wrenches, Set of Combination Wrenches, Clean Rag, Foot-Pound Torque Wrench,
Hex Wrench Socket Set
STRICTLY OBSERVE THE FOLLOWING GUIDELINES IN ORDER TO USE THE
PRODUCT PROPERLY AND AVOID POTENTIALLY DANGEROUS ACCIDENTS.
STEP 1
Read and understand all steps in the instructions before starting the
installation. Park the motorcycle on a hard, level surface and turn off the
ignition.
STEP 2
Place the O-ring in the groove on the chrome centering inserts. PIC 1 Slide the
inserts into the holes in the bottom of the fork sliders. PIC 2 The O-ring serves
only to keep the insert in place during installation.
-cont.-
7202-21HD-0412
ϋ
RYAKYN!
This indication alerts you to the fact that ignoring the
contents described herein may negatively affect product
performance and functionality.
This indication alerts you to the fact that ignoring
the contents described herein can result in potential
injury.
INSTALLATION
7202
