curt 60601 Manual

60601
11/12/2013
***DO NOT EXCEED VEHICLE MANUFACTURER'S RECOMMENDED TOWING CAPACITY.***
HAVING INSTALLATION QUESTIONS? CALL TECHNICAL SUPPORT AT
60601 BALL LOCKED
HANDLE
(ROTATED @ 90°)
BALL UNLOCKED
60601 OPERATION:
1. To install gooseneck ball, lift the handle from its seat and rotate 90°. Insert gooseneck ball in receiver
tube in the bed of truck. Rotate the handle to the locked position and flip it down into its seat. Note: If
handle does not want to rotate into the locked position, rotate the ball while applying light pressure to
the side of the handle until the handle rotates into the locked position and flip it down into its seat.
2. When gooseneck ball is not in use, remove from the receiver tube and store in a dry / clean area.
PERIODICALLY CHECK THIS GOOSENECK HITCH TO ENSURE THAT ALL FASTENERS
ARE TIGHT AND THAT ALL STRUCTURAL COMPONENTS ARE SOUND.
Curt Manufacturing LLC., warrants this product to be free of defects in material and/or workmanship at the time of retail purchase by the original purchaser. If the product is found to be defective,
Curt Manufacturing LLC., may repair or replace the product, at their option, when the product is returned, prepaid, with proof of purchase. Alteration to, misuse of, or improper installation of
this product voids the warranty. Curt Manufacturing LLC.'s liability is limited to repair or replacement of products found to be defective, and specifically excludes liability for incidental or
consequential loss or damage.
OE GOOSENECK BALL
SEAT
1-800-798-0813
TRUCK BED
RECEIVER TUBE
NOTE: HANDLE MUST MATCH
BALL PROFILE WHILE IN THE
LOCKED POSITION, PRIOR
BALL LOCKED
PAGE 1 OF 2
TO COUPLING
