- Page 1 Adjustable Computer Mobile Cart SKU: CART-PC02T Instruction Manual Assembly Video & Product Info www.vivo-us.com/products/cart-pc02t...
- Page 2 [ THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK ]...
-
Page 3: We're Here For You
If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual. -
Page 4: Package Contents
Package Contents A (x1) B (x1) C (x1) Base Keyboard Tray Large Plastic Sleeve F (x2) D (x1) E (x1) Locking Caster Plastic Cover Clamp Bracket G (x2) H (x1) I (x1) Caster VESA Mount PC Holder J (x1) K (x1) L (x1) Clamp Middle Pole... -
Page 5: Included Hardware & Tools
Included Hardware & Tools S-A (x1) S-B (x5) S-C (x3) S-D (x4) S-E (x2) Carriage Bolt M6x6mm M6x12mm M6x16mm Screw Screw Screw S-F (x2) S-G (x9) S-H (x2) M6x50mm M-B (x4) M-A (x4) Washer M6x45mm Screw M4x16mm M4x12mm Screws Screw Screw M-C (x4) M-D (x4) -
Page 6: Assembly Steps
ASSEMBLY STEPS STEP 1 Mount Locking Casters (F) and Casters (G) to Base (A). Tighten with Wrench (T-C). Locking Caster Orientation Locking casters (F) can be mounted on the back (as shown) or front of Base (A). - Page 7 STEP 2 Follow the substeps below to secure the Lower Pole (L) to the Base (A), then slide Plastic Cover (D) on top of Lower Pole (L). Secure Lower Pole (L) to Base (A) using Carriage Bolt (S-A), Washer (S-G), and Nut (S-B).
- Page 8 STEP 3 Slide Small Plastic Sleeve (V) down Middle Pole (K), positioning the sleeve over the second hole from the bottom, as shown. Fit Middle Pole (K) into Lower pole (L), making sure to align the holes on the sides. Secure using M6x50mm Screws (S-F), Washers (S-G), and Nuts (S-B).
- Page 9 STEP 4 Remove nuts from PC Holder (I) assembly with Wrench (T-C). Separate halves of the assembly and set Washers aside. Assemble Clamp Bracket (E) to PC Holder (I) using M6x6 screws (S-C) and 4mm Allen Wrench (T-A).
- Page 10 STEP 5 Mount PC Holder (I) to Lower Pole (L) using Clamp (J), Plastic Sleeve Halves (Q) and M6x16 screws (S-E), as shown. Tighten with 4mm Allen wrench (T-A). PLASTIC SLEEVE IS REQUIRED The Plastic Sleeve Halves (Q) MUST be used in the Clamp assembly for the CPU Holder to be properly secured.
- Page 11 STEP 6 Reassemble PC Holder (I) using Knobs (R) and previously removed Washers. Thread “T” End ofPC Straps (N) through slots in PC Holder (I), as shown. Clips on CPU Straps (N) should face away from center of CPU Holder (I) “T”...
- Page 12 STEP 7 Please Note: The keyboard tray can be assembled at two different heights. Option 1: Standard Keyboard Tray Height Clip Large Plastic Sleeve (C) into pole mount bracket of Keyboard Tray (B) as shown. Slide Keyboard Tray (B) onto Middle Pole (K) and tighten with knobs on the back and side. Place Mouse Pad (U) on preferred side of Tray.
- Page 13 Option 2: Raised Keyboard Tray Height Please Note: Assembly is reverse of Option Steps Begin by fitting Upper Pole (M) into Middle Pole (K), making sure to align the holes on the sides. Secure using M6X45mm Screws (S-H), Washers (S-G), and Nuts (S-B). Tighten using 4mm Allen Wrench (T-A) and Wrench (T-C).
- Page 14 STEP 8 Slide VESA Mount (H) onto pole and secure at desired height using 5mm Allen Wrench (T-B). Attach Cable Clips (S) to Upper Pole (K). STEP 9 Adjust PC Holder (I) to fit the width of your PC tower. Then follow assembly order below to secure the CPU Straps (N).
- Page 15 STEP 10 Place PC tower in PC Holder (I), then follow assembly order below to secure PC tower in Holder. Retighten Straps (N) through plastic clips. Lock in place with security clip. Slide lower Cable Clip (S) down if desired.
- Page 16 STEP 11 Remove VESA Plate (H1) from VESA Mounting assembly by removing preinstalled Security Screw using 4mm Allen Wrench (T-A). Security Screw...
- Page 17 STEP 12 Choose the mounting option for your style of monitor: Option 1: Flat Back Monitor Mount VESA Plate (H1) to monitor using appropriate Screws (M-A or M-C) and Washer (M-E), as shown below. Option 2: Curved Monitor Mount VESA Plate (H1) to monitor using appropriate Screws (M-B or M-D), Washers (M-E), and Spacers (M-F) as shown below.
- Page 18 STEP 13 Slide monitor with VESA Plate (H1) onto VESA Mount (H) and secure with previously removed Security Screw and 4mm Allen Wrench (T-A). Security Screw...
- Page 19 Adjustments and Extra Features +15° -15° Monitor can be raised, lowered, and tilted using 5mm Allen Wrench (T-B). Keyboard Tray (B) can be raised and lowered using adjustment knobs. Both Allen Wrenches (T-A,T-B)can Locking Casters (F) can be be stored in the VESA Mount (H). locked by pressing down on the lever.
- Page 20 LAST UPDATED: 6/19/24 REV2 v2.0 Need Help? Get In Touch Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com 309-278-5303 Chat live with an agent! FOR MORE GREAT VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: WWW.VIVO-US.COM VIVO-us @vivo_us...
