- Page 1 Adjustable PC Cart with Storage SKU: CART-PC03P Instruction Manual Assembly Video & Product Info www.vivo-us.com/products/cart-pc03p...
- Page 2 If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
-
Page 3: Assembly Steps
STEP 2 ASSEMBLY STEPS Flip assembly on it’s back and secure the second Shelf (A) onto Frames (B) using M6x40mm Screw (S-D) and 4mm Allen Wrench (T-A). STEP 1 Take note of the mounting holes on Shelf (A), which are slightly offset. There will be a small and large gap between the holes and the front/back edges of the shelf. - Page 4 STEP 5 STEP 3 To adjust the height of the upper shelf, loosen and remove the Height Adjustment Knobs (B1) on the Place Struts (C) onto to the back of assembled Frame (B) as shown below. Secure Struts (C) in the center hole back of the assembled frame.
- Page 5 LAST UPDATED: 10/17/2023 REV1 v1.0 Need Help? Get In Touch Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com 309-278-5303 Chat live with an agent! FOR MORE GREAT VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: WWW.VIVO-US.COM VIVO-us @vivo_us...
