Rugged Ridge 13551.14 Manual

Contents:
Storage Console
Mounting Brackets
M8 Bolt
M8 Flat Washer
M8 Nut
Long Velcro Strap
Short Velcro Strap
1. Locate the mounting holes at the ends of the Storage Console. Position
Mounting Bracket above the mounting holes with the slots facing forward.
Attach the Mounting Bracket to the Storage Console using the supplied M8
hardware.
2. Place the Storage Console inside the vehicle such that the mounting
brackets rest on the roll bar. The Storage Console should sit just above the
visors. Insert Long Velcro Straps through the slots in each Mounting Bracket
and strap them tightly around the roll bar on both sides of the vehicle.
3. Insert the Short Velcro Strap through the slot in the rear of the Storage
Console and attach to the footman loop of the windshield.
For assistance, please contact Omix-ADA Technical Support department
OVH Storage Console
Quantity
(1)
(2)
(4)
(4)
(4)
(4)
(1)
(770) 614-6101
techsupport@omix-ada.com
Page 1 of 1
13551.14
