Black Horse Off Road 9JPREA Installation Instructions Manual

3” sidebar 15-24 jeep renegade
Hide thumbs
1
2
3
4
5
6

Advertisement

Quick Links

Download this manual
TEL：1-866-XANATOS
INSTALLATION INSTRUCTIONS
3" SIDEBAR
15-24 JEEP RENEGADE
PART #9JPREA

Advertisement

loading
Need help?

Need help?

Do you have a question about the 9JPREA and is the answer not in the manual?

Questions and answers

Related Manuals for Black Horse Off Road 9JPREA

Summary of Contents for Black Horse Off Road 9JPREA

  • Page 1 TEL：1-866-XANATOS INSTALLATION INSTRUCTIONS 3” SIDEBAR 15-24 JEEP RENEGADE PART #9JPREA...

  • Page 2: Parts List

    3” SIDEBARS 2015-24 JEEP RENEGADE PARTS LIST: Driver/left Sidebar 10mm Lock Washers Passenger/right Sidebar 10-1.5mm Hex Nuts Driver/left Front Mounting Bracket 8-1.25mm x 25mm Combination Bolts Passenger/right Front Mounting Bracket 8-1.25mm x 25mm Hex Bolts Driver/left Rear Mounting Bracket 8mm x 24mm x 2mm Flat Washers Passenger/right Rear Mounting Bracket 8mm Lock Washers Driver/left Front, Passenger/right Rear Support...
  • Page 3 3” SIDEBARS 2015-24 JEEP RENEGADE 6. Move toward the rear of the vehicle. Locate the square plug in the bottom of the frame channel, (Figure 6). Repeat Steps 2—5 to install the passenger side rear Bracket and Support Bracket, (Figures 7—9). NOTE: The passenger side rear Support Bracket will attach to the front of the rear Bracket.
  • Page 4 3” SIDEBARS 2015-24 JEEP RENEGADE Passenger Side Installation Pictured 10mm x 30mm 8mm x 25mm Hex Bolt Bolt Plate (2) 8mm Flat Washers Front 8mm Lock Washer 8mm Hex Nut 10mm Flat Washer 10mm Lock Washer 10mm Hex Nut (Fig 3) Insert Bolt Plate into hole in body panel Front 10mm x 30mm Bolt Plate...
  • Page 5 3” SIDEBARS 2015-24 JEEP RENEGADE Passenger Side Installation Pictured 8mm x 25mm Hex Bolt Attach Bracket to Bolt Plate (2) 8mm Flat Washers 10mm Flat Washer Support 8mm Lock Washer 10mm Lock Washer Bracket 8mm Hex Nut 10mm Hex Nut Rear Rear (Fig 8) Attach Support Bracket to front of Bracket...
  • Page 6 3” SIDEBARS 2015-24 JEEP RENEGADE Passenger Side Installation Pictured (2) 6mm Hex Bolts (4) 6mm Flat Washers (2) 6mm Lock Washers (2) 6mm Hex Nuts Rear Front (Fig 14) Attach passenger rear Support (Fig 13) Passenger/right front installation Brackets to back of pinch weld Rear (2) 8mm Combo Bolts...
