ORRSC2 # : ORRSC2
Assembly Instructions
Please visit our website for the most current instructions, assembly tips, report damage,
or request parts. www.walkeredison.com
Revised 07/02/2018
P.1
Copyright © 2018, by Walker Edison Furniture Co., LLC. All rights reserved.
Advertisement
Related Manuals for Walker Edison Estrella ORRSC2
Summary of Contents for Walker Edison Estrella ORRSC2
- Page 1 ORRSC2 # : ORRSC2 Assembly Instructions Please visit our website for the most current instructions, assembly tips, report damage, or request parts. www.walkeredison.com Revised 07/02/2018 Copyright © 2018, by Walker Edison Furniture Co., LLC. All rights reserved.
- Page 5 Attach part (3) to part (4) using bolt (A), flat (B), and hex nut (D) with hex key (C) and open spanner (E). Then place screwdriver cap (F) on hex nut (D) per diagram.
- Page 6 Attach parts (1,2) to part (3) using bolt (A), flat (B) and hex nut (D) with hex key (C) and open spanner (E). Then place screwdriver cap (F) on hex nut (D) per diagram.
- Page 7 Place cushion (5) on top of chair per diagram.
