- Page 5 Use wrench (D) to secure love seat side frame (2) to love seat back frame (1) with bolt (A) and washer (C). Use wrench (D) to secure love seat's seat frame (4) to love seat side frame (2) with bolt (A) and washer (C), and secure love seat's seat frame (4) to love seat back frame (1) with bolt (B) and washer (C).
- Page 6 Use wrench (D) to secure love seat side frame (3) to love seat's seat frame (4) and love seat back frame (1) with bolt (B) and washer (C). Place cushion (16,17) on top of love seat's seat frame (4).
- Page 7 Left side of Love Seat assembly complete. Use wrench (D) to secure love seat side frame (6) to love seat back frame (5) with bolt (A) and washer (C).
- Page 8 Use wrench (D) to secure love seat side frame (7) to love seat's seat frame (8) and love seat back frame (5) with bolt (B) and washer (C). Copyright © 2018, by Walker Edison Furniture Co., LLC. All rights reserved.
- Page 9 Place cushion (16,17) on top of love seat's seat frame (8). Right side of Love Seat assembly complete.
- Page 10 Use wrench (D) to secure corner seat back frame (9,10) together with bolt (A) and washer (C). Use wrench (D) to secure corner seat's seat frame (12) to corner seat back frame (9,10) with bolt (B) and washer (C).
- Page 11 Use wrench (D) to secure corner seat side frame (11) to corner seat's seat frame (12) and corner seat back frame (10) with bolt (B) and washer (C). Place corner cushions (17,18) on top of corner seat’s seat frame (12).
- Page 12 Corner seat assembly finished. Use wrench (D) to secure leg (15) to table top (13) with bolt (A) and washer (C).
- Page 13 Use wrench (D) to secure shelf (14) to leg (15) with bolt (A) and washer (C). Table assembly finished.
