  • Page 1 User Guide Advanced HD Radio™ Table Top NS-CLHD01...

  • Page 2: Table Of Contents

    Advanced HD Radio™ Table Top Contents Introduction ........3 Important safety instructions .

  • Page 3: Introduction

    Advanced HD Radio™ Table Top Introduction Congratulations on your purchase of a high-quality Insignia product. Your NS-CLHD01 represents the state of the art in HD Radio™ design and is designed for reliable and trouble-free performance. Important safety instructions Read these instructions.

  • Page 4: Features

    NS-CLHD01 Only use attachments/accessories specified by the manufacturer. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have...

  • Page 5: Package Contents

    Advanced HD Radio™ Table Top • Artist Experience image display • Automatic blending for Analog and Digital Signal • Digital time display - Dual Alarm/Snooze • Accessible mode with Voice prompt/feedback on button press for visually impaired users • Aux input/Headphone output Jack •...
  • Page 6 NS-CLHD01 Front Item Description Radio display screen. Headphone Plug headphones into this jack. jack MENU Press to open or close the menu system. In the menu system, press to close a sub-menu. Press to select menu options or save the settings.
  • Page 7 Advanced HD Radio™ Table Top Item Description Press to tune to the next lower or higher frequency. In time and alarm set mode , press to adjust the hours up or down. Press to go to the next lower or higher preset station.
  • Page 8 NS-CLHD01 Item Description (power) Press to turn your radio on or off. For more information, see “Turning your radio on or off” on page 24. In clock mode, press and hold SEL + Power together to switch between normal mode and accessible mode for visually impaired users.
  • Page 9 Advanced HD Radio™ Table Top Back and Bottom Item Description 12V DC Connect the AC adapter (provided) to this jack. AUX IN Connect an external sound source to this jack. Battery Install four (4) AA size alkaline batteries in this compartment compartment for clock backup.
  • Page 10 NS-CLHD01 LCD information Table clock modes 12-hour type display 24-hour type display Alarm 2 status indicator Alarm 1 status indicator Backup battery status indicator Current time www.insigniaproducts.com...
  • Page 11 Advanced HD Radio™ Table Top Analog radio mode Signal strength AM/FM indicator Stereo/Mono indicator Preset indicator Current time Backup battery status indicator Seek type Frequency selected (digital) Frequency bar (analog) www.insigniaproducts.com...
  • Page 12 NS-CLHD01 HD Radio mode - Artist Experience display Multicast channel number Signal strength Radio band Stereo/Mono indicator Preset indicator SIS short name/Universal short name Current time Display mode: AE–Artist Experience with full-scale image display. PG–Program Guide with scaled image display of the current program.
  • Page 13 Advanced HD Radio™ Table Top RBDS mode Signal strength Radio band Stereo/Mono indicator Preset indicator SIS short name/Universal short name Current time RBDS indicator. Indicates that RBDS is available on the current station Backup battery status indicator Seek type Frequency selected (digital) Frequency bar (analog) RBDS text www.insigniaproducts.com...

  • Page 14: Setting Up Your Radio

    NS-CLHD01 Setting up your radio Installing the batteries Note The batteries will keep your clock running in case of a power outage. To install the batteries: Open the battery compartment on the bottom of your radio. Place four AA size alkaline batteries (not included) in the battery compartment.

  • Page 15: Using The Clock And Alarm

    Advanced HD Radio™ Table Top Using the clock and alarm Setting the time To set the time: Press MENU to enter menu mode. The Main menu opens. Press SEEK or SEEK to select Time Set, then press SEL. The Time menu opens. www.insigniaproducts.com...
  • Page 16 NS-CLHD01 Press SEEK or SEEK to select Time Set, then press SEL. Press CH or CH to set the hours. Press PS or PS to set the minutes. Press SEL to save the current time and return to the Time menu.
  • Page 17 Advanced HD Radio™ Table Top to select Time Set, then press Press SEEK or SEEK SEL. Press SEEK or SEEK to select Hour Format, then press SEL. The Hour Format menu opens. Press SEEK or SEEK to select the hour format you want, then press SEL to save the hour format and return to the time menu..
  • Page 18 NS-CLHD01 Setting the alarm Your clock radio supports dual alarms. The alarms can be set up separately and the alarms can be set up in clock mode. To set the alarm time: Press and hold AL1 or AL2 to open the alarm set menu for the alarm of your choice.
  • Page 19 Advanced HD Radio™ Table Top To set the Volume Snooze: Press and hold AL1 or AL2 to open the alarm set menu for the alarm of your choice. Press SEEK or SEEK to select Volume Snooze, then press SEL. The Volume/Snooze Set screen opens. Press SEEK or SEEK to select the Volume.
  • Page 20 NS-CLHD01 Setting the alarm source To set the alarm source: Press and hold AL1 or AL2 to open the alarm set menu for the alarm of your choice. Press SEEK or SEEK to select Source Select, then press SEL. The Source Select screen opens.

  • Page 21: Using Your Radio

    Advanced HD Radio™ Table Top Using your radio Understanding radio modes Your radio has a Clock mode and three audio modes (FM, AM, and AUX in). AM has Analog and HD Radio modes. FM has Analog, RBDS (Radio Broadcast Data System) and HD radio modes.

  • Page 22: Aux In Mode

    NS-CLHD01 Analog (FM) mode The Analog (FM) mode is the standard mode that has been in use for many years. The FM radio signal is an analog signal. When receiving an FM signal, the “FM” icon appears on the display.
  • Page 23 Advanced HD Radio™ Table Top HD Radio mode HD Radio mode is the new digital mode for AM and FM. Many HD Radio stations have several sub-channels called “multicast channels. ” When receiving an HD Radio signal, the “HD” icon and the channel number appear on the display.
  • Page 24 NS-CLHD01 Turning your radio on or off Connect the AC adapter to the DC jack on the back of your radio. Your radio turns on and the following screen appears on the display: Then the clock mode screen appears. www.insigniaproducts.com...
  • Page 25 Advanced HD Radio™ Table Top To turn your radio on or off: • Press the (power) button. Your radio turns on and the following message appears on the display: www.insigniaproducts.com...
  • Page 26 NS-CLHD01 Then one of the following screens appears: Analog (AM) mode Analog (FM) mode HD Radio mode RBDS mode AUX IN mode www.insigniaproducts.com...

  • Page 27: Adjusting The Volume

    Advanced HD Radio™ Table Top • To turn off your radio, press the (power) button. The display returns to clock mode. Adjusting the volume Caution Listening to your radio with the volume set too loud or using earphones for extended periods of time can damage your hearing.
  • Page 28 NS-CLHD01 Selecting the sound source To select the sound source: • Press SRC repeatedly to cycle through the available sound sources (AM > FM > Aux In). This only works in Radio mode. Automatically tuning to a station To automatically tune to a station in analog (AM or FM) mode: •...
  • Page 29 Advanced HD Radio™ Table Top • Press SEEK to automatically tune to the next lower HD Radio station. In HD SEEK mode, each time you press SEEK , your radio goes to the next lower multicast channel of the current station. When your radio reaches the lowest multicast channel, it goes to the next lower station (analog or HD Radio).
  • Page 30 NS-CLHD01 Manually tuning to a frequency When you manually tune, your radio goes to the next or previous frequency regardless of whether a station is broadcasting on the frequency. To manually tune to a frequency in analog (AM/ FM) mode or RBDS mode: •...
  • Page 31 Advanced HD Radio™ Table Top Setting a preset station To set and use preset stations: Tune to the station you want to make a preset. Press and hold PS to set the preset. To tune to a preset station, press PS or PS Note: You can store an unlimited number of presets.

  • Page 32: Radio Mode

    NS-CLHD01 Viewing the program guide (PG) in HD Radio mode To view the guide in HD Radio mode: Press DISP. A scaled album is displayed and the program list is displayed under the album. Press CH or CH or SEEK...

  • Page 33: Using The Menu

    Advanced HD Radio™ Table Top Using the menu Your radio has a menu that lets you set radio options. To use the menu: Press MENU. The Main menu opens. Press SEEK or SEEK to highlight an option, then press SEL to select that option. Press SEEK or SEEK or CH...
  • Page 34 NS-CLHD01 Using the bookmark option Displaying your bookmarks To display your bookmarks: Press MENU. The Main menu opens. Press SEEK or SEEK to select My Bookmarks, then press SEL to select it. The My Bookmarks list opens. Press MENU to return to the main menu.
  • Page 35 Advanced HD Radio™ Table Top To delete a bookmark: Press MENU. The Main menu opens. Press SEEK or SEEK to select My Bookmarks, then press SEL to select it. The My Bookmarks list opens. Press SEEK or SEEK to select the bookmark you want to delete, then press B).
  • Page 36 NS-CLHD01 Press SEEK or SEEK to select OK, then press SEL to confirm. A confirmation note is displayed. Press MENU to return to the main menu. To display the Bookmark - QR code: To display selected bookmark in QR Code format on the LCD, the...

  • Page 37: Setting The Time

    Advanced HD Radio™ Table Top • ISBN Bar Code Description Press MENU to return to the main menu. Viewing the Bookmark History list To display your Bookmark History: Press MENU. The Main menu opens. Press SEEK or SEEK to select Bookmark History, then press SEL to select it.
  • Page 38 NS-CLHD01 Setting the seek type To set the seek type: Press MENU. The Main menu opens. Press SEEK or SEEK to highlight Seek Type, then press SEL to select it. The Seek Type submenu opens. Press SEEK or SEEK to select the seek type you want, then press SEL to save Seek type and return to the Main menu.
  • Page 39 Advanced HD Radio™ Table Top Changing the settings Setting the tuning region Your radio is capable of tuning in different frequency spacing in both FM and AM (FM:200KHz, 100KHz, 50KHz/ AM:10KHz, 9KHz) for different regions. The default region is U.S. To set the tuning region: Press MENU.
  • Page 40 NS-CLHD01 Press SEEK or SEEK to highlight Tuning Region, then press SEL to select it. The Tuning Mode submenu opens. Press SEEK or SEEK to highlight the tuning mode you want, then press SEL. A confirmation box opens. Press SEEK or SEEK to select OK, then press SEL.
  • Page 41 Advanced HD Radio™ Table Top Setting the LCD control To adjust the LCD control: Press MENU. The Main menu opens. Press SEEK or SEEK to highlight Setting, then press SEL to select it. The Setting submenu opens. www.insigniaproducts.com...
  • Page 42 NS-CLHD01 to highlight LCD control, Press SEEK or SEEK then press SEL. The LCD Control submenu opens. Press SEEK or SEEK to highlight the option you want to change (Backlight or Contrast). Press CH or CH to change the Backlight or Contrast level, then press SEL to confirm the change and return to the Setting submenu.
  • Page 43 Advanced HD Radio™ Table Top to highlight Setting, then Press SEEK or SEEK press SEL to select it. The Setting submenu opens. Press SEEK or SEEK to highlight HW/SW Version, then press SEL. The HW/SW Version submenu opens showing the hardware and software version information.
  • Page 44 NS-CLHD01 Resetting options to factory defaults To reset options to factory defaults: Press MENU. The Main menu opens. Press SEEK or SEEK to highlight Factory default, then press SEL to select it. The Factory Default submenu opens. Press SEEK or SEEK to highlight OK, then press SEL.

  • Page 45: Troubleshooting

    Advanced HD Radio™ Table Top Troubleshooting Do not try to repair your radio yourself. Refer all servicing to qualified repair personnel. Symptoms Possible causes and solutions The radio does There is moisture or condensation in your radio. Let not turn on your radio warm up to room temperature for 60 minutes, then try again.

  • Page 46: Specifications

    NS-CLHD01 Specifications Frequency range Mode A : FM 87.5MHz - 108MHz (100 KHz step) AM 522KHz - 1620KHz (9 KHz step) Mode B : FM 87.5MHz - 107.9MHz (200 KHz step) AM 530KHz - 1710KHz (10 KHz step) Mode C : FM 87.5MHz - 108MHz (50 KHz step)
  • Page 47 Advanced HD Radio™ Table Top • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help.
  • Page 48 NS-CLHD01 www.insigniaproducts.com...

  • Page 49: 90-Day Limited Warranty

    Product at no charge with new or rebuilt comparable products or parts. Products and parts replaced under this warranty become the property of Insignia and are not returned to you. If service of Products or parts are required after the Warranty Period expires, you must pay all labor and parts charges.
  • Page 50 REPAIR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS YOUR EXCLUSIVE REMEDY. INSIGNIA SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR THE BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT, INCLUDING, BUT NOT LIMITED TO, LOST DATA, LOSS OF USE OF YOUR PRODUCT, LOST BUSINESS OR LOST PROFITS.
  • Page 51 7601 Penn Avenue South, Richfield, Minnesota, U.S.A. 55423-3645 © 2012 BBY Solutions, Inc. All rights reserved. INSIGNIA is a trademark of BBY Solutions, Inc. Registered in some countries. All other products and brand names are trademarks of their respective owners.
  • Page 52 7601 Penn Avenue South, Richfield, MN USA 55423-3645 © 2012 BBY Solutions, Inc. All rights reserved. INSIGNIA is a trademark of BBY Solutions, Inc. Registered in some countries. All other products and brand names are trademarks of their respective owners.
