- Page 1 Advanced User Guide Eaton 3P Ellipse 3P550F 3P550D 3P550I 3P700F 3P700D 3P700I 3P700UF 3P700UD 3P700UI 3P900UF 3P900UD 3P900UI 3P1300UF 3P1300UD 3P1300UI 3P1700UF 3P1700UD 3P1700UI Copyright © 2025 EATON English All rights reserved. DSD-3P2306...
-
Page 2: Table Of Contents
7.3 When to replace batteries........................17 7.4 Replacing batteries ..........................17 7.5 Recycling the used equipment ......................21 Troubleshooting......................21 8.1 Service and support ..........................22 Specification and technical characteristics..............23 9.1 UPS model list ............................23 9.2 Dimensions and weight ........................23 Eaton-3P-Ellipse-EMEA DSD-3P2306... - Page 3 9.3 Electrical input ............................24 9.4 Electrical input connections......................... 25 9.5 Electrical output............................ 26 9.6 Electrical output connection........................ 26 9.7 Battery ..............................27 9.8 Environmental and safety ........................27 10 Glossary ........................... 29 Eaton-3P-Ellipse-EMEA DSD-3P2306...
-
Page 4: Special Symbols
Surge Outlet: This outlet specifically guards against overvoltage surges. USB Communication Port USB Power Port: The USB port is designed for recharging devices, with the maximum current shared between the two ports. Alternating Curent (AC) Direct Curent (DC) Eaton-3P-Ellipse-EMEA DSD-3P2306... -
Page 5: Introduction
Thank you for selecting an Eaton 3P Ellipse product to protect your electrical equipment. The Eaton 3P Ellipse range has been designed with the utmost care. We recommend that you take the time to read this advanced user guide to take full advantage of the many features of your UPS (Uninterruptible Power System). -
Page 6: Benefits
- causing hours of lost productivity and expensive repairs. With the Eaton 3P Ellipse , you can safely eliminate the effects of power disturbances and guard the integrity of your equipment. Providing outstanding performance and reliability, the Eaton’s unique benefits include: •... -
Page 7: Presentation
Remote Monitoring cloud application. ELRACK Rack mounting kit – Allows to install 3P Ellipse in a 19’ rack. ELWALL Wall mounting kit – Allows to mount the 3P Ellipse vertically on a wall or on the side of a cabinet. Eaton-3P-Ellipse-EMEA DSD-3P2306... -
Page 8: Installation
⑤ 1 Schuko input cable (FR & DIN models) / KC power cord set is not shipped with UPS ⑥ 2 IEC output cables (IEC models) ⑦ 1 USB communication cable (USB models) ⑧ Cloud card (optional on USB models) Eaton-3P-Ellipse-EMEA DSD-3P2306... -
Page 9: Recommended Positions
UPS is in the upright direction (EATON logo readable). Horizontally, the Eaton 3P Ellipse can be positioned under an object, provided that the object does not weigh more than 10kg (22 lbs), does not heat, and that the room temperature does not exceed 30°C. - Page 10 The protected outlets are not backed up by battery power in the event of a power outage. Equipment connected to these outlets is supplied as soon as the AC cord is plugged in. These are not affected by ON/OFF button. Eaton-3P-Ellipse-EMEA DSD-3P2306...
-
Page 11: Register Warranty
USB charging port USB models only : Connect your device to the USB charging ports, 1 USB A, 1 USB C (5V – 2.0 A maximum). 4.4 Register warranty Register warranty at https://www.pqproductregistration.eaton.com Eaton-3P-Ellipse-EMEA DSD-3P2306... -
Page 12: Interfaces And Communication
Low range mode: AC supply between 161V and 264V – LEDs ② = ON & ④ = OFF o Low and high range mode: AC supply between 161V et 284V – LEDs ② = OFF & ④ = ON • Memorizing the mode: 10 sec. after the last press of the button. Eaton-3P-Ellipse-EMEA DSD-3P2306... - Page 13 • Memorizing the mode: 10 sec. after the last press of the button. Note: it is not possible to silence the alarm while the UPS in on battery mode. Note: Audible mode setting can be performed through Eaton UPS Companion software for USB models. Eaton-3P-Ellipse-EMEA DSD-3P2306...
-
Page 14: Communication Ports
Eaton Picoslot Cloud Card Connectivity cards allow the UPS to communicate in a variety of networking environments and with different types of devices. The Eaton 3P Ellipse communication models have one available communication bay for the following connectivity card: •... -
Page 15: Control Panel
The UPS is "ON" and the load is protected. Green Flashes The UPS operates on battery power. Green The surge protection is “ON” and the outlets are protected. Green Battery fault / UPS fault. See troubleshooting page for additional information. Eaton-3P-Ellipse-EMEA DSD-3P2306... -
Page 16: Cybersecurity
5.4 Cybersecurity Eaton is committed to minimizing the Cybersecurity risk in its products and employs cybersecurity best practices and the latest cybersecurity technologies in its products and solutions, making them more secure, reliable and competitive for our customers. Eaton also offers Cybersecurity Best Practices whitepapers to its customers, referenced at www.eaton.com/... -
Page 17: Return Of Ac Input Power
If you store the equipment for a long period, recharge the battery every 6 months by connecting the UPS to utility power. The internal batteries charge to 90% capacity in less than 3 hours. However, Eaton recommends that the batteries charge for 48 hours after long-term storage. - Page 18 • ELECTRIC ENERGY HAZARD. Do not attempt to alter any battery wiring or connectors. Attempting to alter wiring can cause injury. • Failed batteries can reach temperatures that exceed the burn thresholds for touchable surfaces. Eaton-3P-Ellipse-EMEA DSD-3P2306...
- Page 19 Step 9: Close battery door, slide it back to its original place and put screws back on with Phillips screwdriver (not provided) • Step 10: connect the UPS to main power • Step 11: Switch ON the UPS Eaton-3P-Ellipse-EMEA DSD-3P2306...
- Page 20 Step 9: Close battery door, slide it back to its original place and put screws back on with Phillips screwdriver (not provided) • Step 10: Connect the UPS to main power • Step 11: Switch ON the UPS Eaton-3P-Ellipse-EMEA DSD-3P2306...
-
Page 21: Recycling The Used Equipment
For proper disposal, contact your local recycling/reuse or hazardous waste center. 8 Troubleshooting The Eaton 3P Ellipse is designed for durable, automatic operation and alerts you whenever potential operating problem may occur. Usually the alarms shown by the product do not mean that the output power is affected. Instead, they are preventive alarms intended to alert the user. -
Page 22: Service And Support
④ life. 8.1 Service and support If you have any question or problem with the UPS, call Eaton or your local service representative in your country / region. Please have the following information ready when you call for service: •... -
Page 23: Specification And Technical Characteristics
Eaton Ellipse 3P 700 DIN 3P700D 420W / 700VA Tower Eaton Ellipse 3P 700 IEC 3P700I 420W / 700VA Tower Eaton Ellipse 3P 700 USB FR 3P700UF 420W / 700VA Tower Eaton Ellipse 3P 700 USB DIN 3P700UD 420W / 700VA Tower... -
Page 24: Electrical Input
3P900UI 3P1300UF 3P1300UD 3P1300UI 7.7 / 16.9 312 x 81 x 305 / 12.3 x 3.2 x 12 3P1700UF 3P1700UD 3P1700UI 9.3 Electrical input Default frequency 50Hz Nominal frequency 50/60Hz Frequency range 47-70Hz Protective class Protective class I Eaton-3P-Ellipse-EMEA DSD-3P2306... -
Page 25: Electrical Input Connections
9.4 Electrical input connections Catalog Number Input connection Input cable 3P550I 3P700I 3P700UI IEC C14-10A Not provided 3P900UI 3P1300UI 3P1700UI 3P550F 3P550D 3P700F 3P700D 3P700UF 3P700UD Input cord with Schuko plug 1.7m Schuko cable provided 3P900UF 3P900UD 3P1300UF 3P1300UD 3P1700UF 3P1700UD Eaton-3P-Ellipse-EMEA DSD-3P2306... -
Page 26: Electrical Output
Harmonic distortion same as mains <40% 550VA, 700VA, 900VA: 0.6 Power Factor 1300VA: 0.646 1700VA: 0.611 9.6 Electrical output connection Catalog Number Output conection Output cable 3P700I 3P700UI 3P900UI IEC- 10A 2 IEC 10A 3P1300UI 3P1700UI Eaton-3P-Ellipse-EMEA DSD-3P2306... -
Page 27: Battery
3-5 year float service life at 25°C (77°F) 9.8 Environmental and safety IEC/EN 62040-1 Safety Standards IEC/EN 62040-2 Electromagnetic Compatibility IEC/EN 62040-3 Performance CISPR32 Class B IEC/EN 61000-3-2 Harmonics EMC (Emissions) IEC/EN 61000-3-3 Flickers EN IEC 62040-2 Eaton-3P-Ellipse-EMEA DSD-3P2306... - Page 28 Up to 3,000 meters (9,843 ft) above sea level, no derating for 40°c (104°F) room Operating altitude temperature. Above 2,000 meters (6,526ft) apply a derating 1% of load per 100 meters. Transit altitude Up to 10,000 meters (32,808 ft) above sea level Audible noise <25dBA Overvoltage Category Category II Pollution degree Eaton-3P-Ellipse-EMEA DSD-3P2306...
-
Page 29: Glossary
The normal UPS operating mode in which the AC source supplies the UPS which, in turn, provides AC power to the connected loads. Normal AC source Normal source of power for the UPS. Overload. When the load exceeds 100% of the maximum load of the UPS. Uninterruptible Power System. Eaton-3P-Ellipse-EMEA DSD-3P2306...
