Trinity 510 Manual
Revision 2.01
S2266
Copyright © TYAN Computer Corporation, 2001. All rights reserved. No part of this manual may be
reproduced or translated without prior written consent from TYAN Computer Corp.
All registered and unregistered trademarks and company names contained in this manual are
property of their respective owners including, but not limited to the following.
TYAN, Trinity 510 S2266 are trademarks of TYAN Computer Corporation.
Intel, Intel Pentium, combinations thereof are trademarks of Intel Corporation.
VIA, P4X266, P4X, and combinations thereof are trademarks VIA Technology Inc.
Award, Award BIOS are trademarks of Phoenix Technologies Ltd.
Microsoft, Windows are trademarks of Microsoft Corporation.
IBM, PC, AT, PS/2 are trademarks of IBM Corporation.
Winbond is a trademark of Winbond Electronics Corporation.
Micronics is a trademark of Micronics Corporation.
Portable Document Format (PDF) is a trademark of Adobe Corporation.
Information contained in this document is furnished by TYAN Computer Corporation and has been
reviewed for accuracy and reliability prior to printing. TYAN assumes no liability whatsoever, and
disclaims any express or implied warranty, relating to sale and/or use of TYAN products including
liability or warranties relating to fitness for a particular purpose or merchantability. TYAN retains the
right to make changes to product descriptions and/or specifications at any time, without notice. In
no event will TYAN be held liable for any direct or indirect, incidental or consequential damage,
loss of use, loss of data or other malady resulting from errors or inaccuracies of information
contained in this document.
1
http://www.TYAN.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for TYAN TRINITY 510
Summary of Contents for TYAN TRINITY 510
- Page 1 Revision 2.01 S2266 Copyright © TYAN Computer Corporation, 2001. All rights reserved. No part of this manual may be reproduced or translated without prior written consent from TYAN Computer Corp. All registered and unregistered trademarks and company names contained in this manual are property of their respective owners including, but not limited to the following.
-
Page 2: Table Of Contents
Chapter 4: Installing the Hard Drives ……………………………………………Page 27 Chapter 5: System Resources ……………………………………………Page 29 5.1 Beep Codes ……………………………………………Page 29 5.2 Flash Utility ……………………………………………Page 29 Appendix I: Memory Installation Instructions ……………………………………………Page 30 Appendix II: Glossary ……………………………………………Page 31 Technical Support ……………………………………………Page 36 http://www.TYAN.com... - Page 3 http://www.TYAN.com...
-
Page 4: Before You Begin
1x Pentium 4 Heatsink Mounting Kit 1x 34-Pin floppy drive cable 1x Ultra-DMA-100/66/33 IDE cable 1x Trinity 510 user’s manual 1x TYAN driver CD 1x I/O shield with 1 LAN port (optional) If any of these items are missing, please contact your vendor/dealer for replacement before continuing with the installation process. -
Page 5: Chapter 1: Introduction
Chapter 1: Introduction 1.1 Congratulations! You are now the owner of the TYAN Trinity 510 motherboard, the most reliable, high performance motherboard for Pentium 4 processing. Designed to be portable as well as flexible, the Trinity 510 can fit into standard ATX chassis. This platform utilizes VIA’s high-performance P4X266 chipset, enabling next generation application and platform support. -
Page 6: Software Specifications
Conformity) Two USB ports (two via optional cables) PS/2 keyboard and mouse ports Note: The Trinity 510 S2266 accepts a standard ATX 2.01 power supply, with a minimum output of 30 amps on the 5-volt line. 1.3 Software Specifications Windows 9x/ME/NT/2000... -
Page 7: Chapter 2: Board Installation
Chapter 2: Board Installation Installation You are now ready to install your motherboard. The mounting hole pattern of the Trinity 510 matches the ATX system board specifications. Your chassis should support a standard ATX motherboard form factor. How to install our products right… the first time The first thing you should do is read this user’s manual. -
Page 8: Front Panel Connector
2.1 – Jumper Section Pin outs for certain connectors are available on the TYAN website: http://www.TYAN.com 2.2 – Front Panel Connector (J26) 1,3: HD LED 2,4: Power LED 5,7: Reset Switch 6,8: Power Switch 2.3 – CMOS Reset (J15) 1,2: Connect these two pins together to reset the CMOS settings in case an incorrect setting causes system instability or you have forgotten your system/setup password or have just flashed your BIOS. - Page 9 Note: All other jumpers on the Trinity 510 are NOT user adjustable. Also, for the IDE and floppy connectors on the motherboard, Pin 1 is located towards the inside of the motherboard whereas the last pins are towards the edge of the board.
-
Page 10: Mounting The Motherboard
The diagrams above are only representative of a few solutions for installing a NOTE motherboard into the chassis. The installation procedure for installing your motherboard into the chassis may differ. http://www.TYAN.com... -
Page 11: Installing Memory
Please keep in mind that although some memory modules may appear to be high-quality, they may contain inferior or substandard parts. The type of memory you choose to install should be checked against the memory compatibility list, which is available from TYAN’s website at http://www.TYAN.com. -
Page 12: Installing The Cpu And Cooling Fan
2.7 Installing the CPU and Cooling Fan Intel Pentium 4 processors (2.0GHz) can be used on this board. For updates on CPU compatibility, check TYAN’s website at http://www.TYAN.com/ When installing your CPU, remember the following: The CPU is a sensitive electronic component and can easily be damaged by static... - Page 13 CPU socket and or the CPU itself. Specifications Voltage Ground +12V Speed Amperage 0.3A The FAN connector has a 12V, 0.3A limitation. TYAN takes no responsibility and NOTE will not be held liable for damage related to the misuse of any FAN jumper. http://www.TYAN.com...
- Page 14 Alternatively, if you wish to also install chassis fans for increased cooling, headers are provided to power those fans as well. Chassis fan installation will vary depending on your chassis manufacturer’s design. Please check with your chassis manufacturer for details on proper chassis fan installation. http://www.TYAN.com...
- Page 15 Only TYAN-approved cables are recommended for this motherboard. If you are using an existing configuration with older cables, your system might not function NOTE properly. Use only TYAN-approved cables (i.e. the ones included with your new motherboard). Some symptoms of incorrectly installed HDDs are...
-
Page 16: Connecting Ide/Floppy Drives
Check power cables and cabling. May be a bad FDD does not power on power supply or IDE drive problem. Usually signifies that the cable is on backwards. FDD light is constantly on Reverse the cable at the floppy drive end and try again. http://www.TYAN.com... -
Page 17: Installing Add-In Cards
See the before (Figure 2.1a) and after (Figure 2.1b) example installation images below for details. Figure 2.1a Figure 2.1b *Your PCI slots may not look like those in the above diagrams; they are used NOTE simply as examples. http://www.TYAN.com... -
Page 18: Connecting The Power Supply
Step 1: Shown on the right, in Figure 2.4a, is the 20-pin connector of the ATX power supply. Note the clip in the image: it will help you install the plug correctly. T his is the CLIP Figu re 2.4a http://www.TYAN.com... - Page 19 (i.e. website or phone). Your ATX power connector may not look like those in the above diagram; they NOTE are used simply as examples. http://www.TYAN.com...
-
Page 20: Chapter 3: Bios Setup
The table below shows how to navigate in the setup program using the keyboard. Function Moves from one selection to the next Change from one menu to the Left/Right Arrow Keys next Up/Down Arrow Keys Move between selections Enter Opens highlighted selection PgUp/PgDn Keys Change highlighted selection Getting Help http://www.TYAN.com... -
Page 21: Main Setup
Chipset section unless you’re absolutely sure you need to. The Chipset defaults were carefully chosen by TYAN and or your system manufacturer for the best performance and reliability. Even a seemingly small change to anyone of the Chipset options without consideration, can cause your system to become unstable immediately or progressively. - Page 22 This option enables BIOS System BIOS cacheable Enabled to be cached to RAM. Enabled This option enables video Video RAM Cacheable Disabled RAM to be cached to RAM. Delay Prioir to Thermal 16 Min Leave this setting as is. http://www.TYAN.com...
-
Page 23: Via Onchip Ide Device
VIA-3058 AC97 Audio Disabled onboard audio. (optional feature) Enabled Toggles the use of VIA-3043 OnChip LAN Disabled onboard LAN controller. (optional feature) Disabled Toggles the use of the LAN OnChip LAN Boot ROM Enabled BIOS to use bootable LAN. (optional feature) http://www.TYAN.com... -
Page 24: Super Io Configuration
ECP DMA Channel DMA2 when parallel port is set to Enabled. Leave this setting as is. Game Port Address (optional feature) Leave this setting as is. MIDI Port Address (optional feature) Leave this setting as is. MIDI Port IRQ (optional feature) http://www.TYAN.com... -
Page 25: Power Management Setup
Disabled Defines the time/date when RTC Alarm Resume Enabled the system will wake up. IRQs Activity Monitoring Press Enter Leave all settings as is. 3.11 IRQs Activity Monitoring Leave all settings as they are. http://www.TYAN.com... -
Page 26: Frequency/Voltage Control
TYAN. 107/71/36MHz 110/73/37MHz Note: Although user-adjustable speed settings are provided, TYAN does not support anything other than the default speeds that the motherboard and processor were designed to operate at. 3.13 Exit Options related exiting and saving can be done using the following. -
Page 27: Installing The Hard Drives
IDE controller. For best performance, we recommend that you use drives of identical model and capacity. By matching drives, you ensure compatibility as well. If you are planning to use an UDMA-66 or 100 drive, you must use an UltraDMA-66/100 cable (TYAN has included that cable with the motherboard). - Page 28 Blue end of the part of the installation. ATA- 66/100 cable Figure I-2 Below is a diagram showing where Pin 1 is located on the motherboard for the S2266. http://www.TYAN.com...
-
Page 29: Chapter 5: System Resources
BIOS is having difficulty initializing the video display. Any other beep sequences that may or may not occur are probably due to memory problems. If calling TYAN Tech Support, be sure that you know how many beeps your board made, and how long the beeps were. Also have other information such as your attached add-in cards, drives and OS to help speed up the support process and come to a possible solution faster. -
Page 30: Appendix I: Memory Installation Instructions
Install the memory in sequence. For example, install the first memory module in DIMM socket 1, then 2, and so on. DIMM socket 1 is shown in the picture above (Figure A-1). Check the Tyan website for updates on memory compatibility: http://www.tyan.com Memory Installation Chart The chart below shows how to install the memory correctly, and in what configurations. -
Page 31: Appendix Ii: Glossary
SRAM instead of in the slow DRAM. Note that the cache is also much smaller than your regular memory: a typical cache size is 512KB, while you may have as much as 4GB of regular memory. http://www.TYAN.com... - Page 32 EEPROM (Electrically Erasable Programmable ROM): also called Flash BIOS, is a ROM chip which can, unlike normal ROM, be updated. This allows you to keep up with changes in the BIOS programs without having to buy a new chip. TYAN’s BIOS updates can be found at http://www.TYAN.com ESCD (Extended System Configuration Data): a format for storing information about Plug-n- Play devices in the system BIOS.
- Page 33 Form factor: an industry term for the size, shape, power supply type, and external connector type of the Personal Computer Board (PCB) or motherboard. The standard form factors are the AT and ATX, although TYAN also makes some Baby-AT and ATX Footprint boards. Global timer: onboard hardware timer, such as the Real-Time Clock (RTC).
- Page 34 SDRAM (Synchronous Dynamic RAM): called as such because it can keep two sets of memory addresses open simultaneously. By transferring data alternately from one set of addresses and then the other, SDRAM cuts down on the delays associated with non-synchronous RAM, which must close one address bank before opening the next. http://www.TYAN.com...
- Page 35 ZIF Socket (Zero Insertion Force socket): these sockets make it possible to insert CPUs without damaging the sensitive CPU pins. The CPU is lightly placed in an open ZIF socket, and a lever is pulled down. This shift the processor over and down, guiding into the board and locking it into place. http://www.TYAN.com...
-
Page 36: Technical Support
Return Merchandise Authorization (RMA) number. The RMA number should be prominently displayed on the outside of the shipping carton and the package should be mailed prepaid. TYAN will pay to have the board shipped back to you. http://www.TYAN.com... - Page 37 Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by manufacturer. Dispose of used battery according to manufacturer instructions and in accordance with your local regulations. Document #: D1467-201 http://www.TYAN.com...
