Summarization of Contents
Chapter 2 DNP 3.0 Protocol Implementation
2.1 Deviations from Standard
Outlines the specific ways the EM235/PM335/PM17X PRO implements the DNP3 protocol.
2.2 DNP Implementation
Explains how the device uses DNP3 for data retrieval, control, and other functions.
2.2.1 Class 0 Response
Describes how to configure Class 0 responses for static object information retrieval.
2.2.2 Event Objects
Explains how event objects are assigned, configured, and how change events are generated.
2.2.3 Device Address
Details the unique address requirements for devices on a DNP link.
2.2.4 Transaction Timing
Provides response time information for serial port communication based on baud rate.
2.2.5 Scaling 16-bit Analog Inputs
Explains how analog input data is scaled for 16-bit objects and the conversion formula.
2.2.6 Scaling 16-bit Binary Counters
Describes scaling for 16-bit binary counter objects to avoid over-range errors.
2.3 Password Protection
Details the password protection feature for device configuration and data.
2.4 File Transfer
Introduces support for file transfer operations for event and waveform data.
2.4.1 General File Operations
Explains the DNP functions used for file transfer and lists supported operations.
2.4.2 Reading Directory Files
Describes how to read directory files to list available event files.
2.4.3 Reading Event Data Files
Details the process for reading specific event data files, including filename templates.
2.4.4 Processing Errors
Covers errors and timeouts that can occur during file transfer operations.
Chapter 3 DNP Point Map
3.1 Analog Inputs - Basic Set
Lists basic analog input points, their object/point IDs, descriptions, and units.
3.2 Binary Inputs - Basic Set
Lists basic binary input points, including relay and digital input statuses.
3.3 Binary Counters - Basic Set
Lists basic binary counter points, such as kWh and kvarh values.
3.4 Frozen Binary Counters
Details frozen binary counter points, including total energies and extended set counters.
3.5 Analog Inputs, Binary Inputs, and Counters - Extended Set
Lists extended analog inputs, binary inputs, and counters with detailed parameters.
3.7 Device Control
Explains how to control device functions like relay operations and resets via DNP.
3.8 Device Setup
Covers basic and demand setup parameters for device configuration.
Communication Ports Setup
Configures communication ports, protocols, interfaces, addresses, and baud rates.
3.9 DNP Protocol Setup
Details DNP options setup, including object variations and event point configuration.
Chapter 6 Configuring DNP3
6.1 DNP Options
Details the DNP options available for configuring the device's DNP protocol behavior.
6.2 Configuring DNP Class 0 Response
Explains how to configure Class 0 response for static object information requests.
6.3 Configuring DNP Event Classes
Guides on setting up DNP event classes for analog, binary, and counter points.
