ADOBE AFTER EFFECTS 7.0 382
User Guide
Adjust the following controls for the 3D Channel Extract effect:
Specifies the channel that you want to extract from the 3D channel image file.
3D Channel
Specify the value that is mapped to white or black.
White Point, Black Point
See also
"About 3D layers" on page 173

Depth Matte effect (Pro only)

The Depth Matte effect reads the z-depth information in a 3D channel image file and can slice the image anywhere
along that z axis. Use this effect to create a matte for everything in front of or behind the value you specify. For
example, remove a background in a 3D scene, or insert objects into a 3D scene. Simply create two layers with the 3D
channel image file; then, in one layer, position everything behind a certain point. In the other layer, position every-
thing in front of that same point, so that the two layers together make up the original image; then insert a layer
between them with the object that you want to composite into the scene.
This effect works with 8-bpc color.
Original (left), and with Depth Matte applied with two different Depth values (center and right)
Adjust the following controls for the Depth Matte effect:
Specifies the depth of the z axis where you want to slice the image.
Depth
Specifies the amount of feather along the slice.
Feather
Inverts the feather.
Invert
See also
"About 3D layers" on page 173

Depth Of Field effect (Pro only)

The Depth Of Field effect simulates a camera that's focusing in on one area in a 3D scene (along the z axis) while
allowing other areas to blur.
This effect works with 8-bpc color.
Original (left), and with Depth Of Field applied using different Focal Plane values (center and right)
