I n s t a l l atio n m an ua l
Virtuo Evolve 100, Virtuo Evolve 100/3
Virtuo Evolve 130, Virtuo Evolve 130/3
Virtuo Evolve 180, Virtuo Evolve 180/3
English
Store this document in a safe place
959.137.01.EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Virtuo Evolve 130 and is the answer not in the manual?

Questions and answers

Related Manuals for Dru Virtuo Evolve 130

Summary of Contents for Dru Virtuo Evolve 130

  • Page 1 I n s t a l l atio n m an ua l Virtuo Evolve 100, Virtuo Evolve 100/3 Virtuo Evolve 130, Virtuo Evolve 130/3 Virtuo Evolve 180, Virtuo Evolve 180/3 English Store this document in a safe place 959.137.01.EN...

  • Page 2: Table Of Contents

    I ns t al lat ion m an u al Content page 1. Step-by-step installation plan Introduction 3. Eu / UKCA declaration 4. Technical data Safety 5.1 General 5.2 Regulations 5.3 Safety instructions 6. Preparation 6.1 Removing the packaging 6.2 Electrical connection 7.
  • Page 3 i ns ta ll at ie - en g eb ruike r sh an dl ei di n g...

  • Page 4: Step-By-Step Installation Plan

    Installation manual 1. Step-by-step installation plan Carefully read the manual before the appliance is installed. The major points of attention of the installation are described in the check list below. Perform these steps and tick them once they have been performed correctly. After ticking all the steps, the appliance will be ready for use. ❏...

  • Page 5: Introduction

    After final delivery, the manual should be handed over to the end user. 3. CE declaration of conformity This declaration of conformity is issued under the full responsibility of the manufacturer, hereinafter referred to as DRU. DRU declares that company internal measures guarantee that appliances produced by DRU meet the essential requirements and guidelines of the regulation concerning electric stoves and the accompanying standards.

  • Page 6: Technical Data

    I ns t al lat ion m an u al 4. Technical datas Check the technical data based on the table below. Table 4-1: Technical data Virtuo Evolve 100, Virtuo Evolve 100/3 Model identifier(s) Virtuo Evolve 100/3, Virtuo Evolve 100...

  • Page 7: Safety

    i ns ta ll at ie - en g eb ruike r sh an dl ei di n g I ns t al lat ion m an u al Safety 5.1 General Observe the generally applicable regulations and precautions/safety instructions in this manual. - First check that the technical execution of the appliance to be installed is correct (table 4-1, 4-2, 4-3).

  • Page 8: Preparation

    Contact the supplier if you find that not all components have been supplied. Packaging must be disposed of in accordance with the regulations. Table 6-1: Parts included with the delivery Virtuo Evolve 100, Virtuo Evolve 130, Virtuo Evolve 180, Virtuo Evolve 100/3...

  • Page 9: Electrical Connection

    i ns ta ll at ie - en g eb ruike r sh an dl ei di n g I ns t al lat ion m an u al 6.2 Electric connection The appliance is provided with a tie-wrap to create a strain relief for the mains cord. This is to prevent the cord from unintentionally coming loose from the appliance.

  • Page 10: Installation

    i ns ta ll at ie - en g eb ruike r sh an dl ei di n g I ns t al lat ion m an u al Installation 7.1 Placing the appliance Separate sections describe different ways of placing the appliance. The general description below for placing the appliance applies to all these sections: Place the appliance on the location where it will be installed and take the following into account: - The construction dimensions of the appliance (fig.
  • Page 11 - en g eb ruike r sh an dl ei di n g I ns t al lat ion m an u al 1090 1150 1000 38C-2858/0 Virtuo Evolve 100/3 1015 1000 38C-2859/0 Virtuo Evolve 100...
  • Page 12 i ns ta ll at ie - en g eb ruike r sh an dl ei di n g I ns t al lat ion m an u al 1390 1450 1300 38C-2862/0 Virtuo Evolve 130/3 1315 1300 38C-2863/0 Virtuo Evolve 130...
  • Page 13 i ns ta ll at ie - en g eb ruike r sh an dl ei di n g I ns t al lat ion m an u al 1890 1950 1800 38C-2849/0 Virtuo Evolve 180/3 1815 1800 38C-2850/0 Virtuo Evolve 180...
  • Page 14 i ns ta ll at ie - en g eb ruike r sh an dl ei di n g I ns t al lat ion m an u al 1094 ≤100 2 mm 2 mm 38C-2857 1019 Virtuo 100 Virtuo 100/3 1394 ≤100 2 mm...

  • Page 15: Placing Appliance

    i ns ta ll at ie - en g eb ruike r sh an dl ei di n g I ns t al lat ion m an u al 1894 ≤100 2 mm 2 mm 38C-2842-01 1819 Virtuo 180 Virtuo 180/3 7-10 7.2 Placing appliance When placing the appliance, observe the following instructions:...

  • Page 16: Platform Combined With Lower Decorative Strip

    I ns t al lat ion m an u al 7.3.1 Platform combined with lower decorative strip Virtuo 100, Virtuo 130, Virtuo 180 Create a recess in the platform, in which the appliance will be placed. (see fig. 7-13 A and C for options and Dimensions). Mutually adjust the height of the appliance and assembly set, so that the top side of the platform connects to the bottom side of the lower decorative strip.
  • Page 17 I ns t al lat ion m an u al 38C-2843-01 7-11 38C-2844-01 7-12...
  • Page 18 i ns ta ll at ie - en g eb ruike r sh an dl ei di n g I ns t al lat ion m an u al Virtuo 100, Virtuo 130, Virtuo 180 38C-2866 V180 = 50 V180 = 1819 V180 = 1819 V180 = 530 V130 = 50...
  • Page 19 i ns ta ll at ie - en g eb ruike r sh an dl ei di n g I ns t al lat ion m an u al Virtuo 100/3, Virtuo 130/3, Virtuo 180/3 38C-2867 V180/3 = 1840 V180/3 = 225 V180/3 = 485 V180/3 = 1840 V130/3 = 1340...

  • Page 20: Back And Side Wall Adjacent To The Glass Of The Side Pane

    i ns ta ll at ie - en g eb ruike r sh an dl ei di n g I ns t al lat ion m an u al 7.3.3 Back and side wall adjacent to the glass of the side pane - Where materials are installed up to the glass, heat-resistant material capable of withstanding temperatures of at least 85C.
  • Page 21 i ns ta ll at ie - en g eb ruike r sh an dl ei di n g I ns t al lat ion m an u al tooltip 38C-2846-01 7-16 ≥ 5mm 38C-2847-01 7-17...

  • Page 22: Placing The Chimney Breast

    i ns ta ll at ie - en g eb ruike r sh an dl ei di n g I ns t al lat ion m an u al 38C-2848-01 5 mm 7-18 7.4 Placing the chimney breast - The appliance should not function as a bearing element in the structure. Make sure the appliance does not have to bear the weight of the chimney breast for example.

  • Page 23: The Appliance

    i ns ta ll at ie - en g eb ruike r sh an dl ei di n g I ns t al lat ion m an u al The appliance 8.1 Glass panes The wood set and monitor(s) are supplied separately. These can be fitted after the glass panes and projection plate are removed.

  • Page 24: Projection Plate

    I nst al l at i on m a n ua l 8.2 Projection plate After placement of the wood set (see section 8.5), it is possible to place the projection plate: When taking the projection plate into operation, take note of the following: - Slowly remove the film when using for the first time.

  • Page 25: Metal Triangle

    I ns t al lat ion m an u al 8.3 Metal triangle The metal triangles are optional and are supplied with the three-sided appliances. These can be placed once the front glass pane and projection plate have been removed. Avoid damaging the glass panes and projection plate.

  • Page 26: Monitor(S)

    I ns t al lat ion m an u al 8.4 Monitor(s) Monitor(s) can only be transported in an upright position and are therefore not mounted. Proceed as follows when placing the monitor(s): Loosen the bolts on the inside of the appliance and lift the suspension brackets from the hooks to remove them from the stove.

  • Page 27: Log Set

    i ns ta ll at ie - en g eb ruike r sh an dl ei di n g I ns t al lat ion m an u al 8.5 Log set The appliance comes with a log set consisting of: logs, wood chips, chips, coals and glowing embers. Place them exactly as described for an optimum operation of the appliance.

  • Page 28: Placing The Log Set Virtuo 100

    I ns t al lat ion m an u al 8.5.1 Installing the wood set Virtuo Evolve 100 Place the logs exactly in accordance with the following description in order to achieve a correct alignment of the flame picture and the logs.
  • Page 29 i ns ta ll at ie - en g eb ruike r sh an dl ei di n g I ns t al lat ion m an u al Step 2 Take log A and place it on the three small positioning cams in the centre rear of the stove (fig 8-13 en 8-14). Then take log B and place it diagonally on the positioning cams in the middle left rear and middle left front (fig.
  • Page 30 I ns t al lat ion m an u al 8-15...
  • Page 31 I ns t al lat ion m an u al Step 3 Place log D on the positioning cam on the left on the glow bed. The positioning cam at the bottom right on log D falls into the recess on log B (fig 8-16 and 8-17). Place log E on the positioning cam on the right on the glow bed.
  • Page 32 I ns t al lat ion m an u al 8-18...
  • Page 33 I ns t al lat ion m an u al Step 4 Place log H on the left on the glow bed. This log lies in front of log F as shown on (fig. 8-19 and 8-20). Here it is important that the log is not against the projection plate. 8-19 8-15 8-20...
  • Page 34 I ns t al lat ion m an u al Step 5 Spread out the complete set of glowing embers across the glow bed of the appliance, covering the entire elevated transparent part of the bottom. Here, it is important that the glowing embers connect properly to the logs and completely cover the transparent part of the glow bed.
  • Page 35 I ns t al lat ion m an u al i n s ta l l at i e h a n d l e i d i n g Step 7 Take the black chips and grey chips and spread them out in a playful and natural looking way around the glowing embers, black and grey coals and the flat section of the appliance’s bottom.
  • Page 36 I ns t al lat ion m an u al i n s ta l l at i e h a n d l e i d i n g Step 8 Evenly spread out the wood chips across the glow bed. Ensure that the chips are mixed. Ensure that particularly at the front of the stove there are chips with various dimensions lying together for the best possible bottom covering.

  • Page 37: Placing The Log Set Virtuo 130

    I ns t al lat ion m an u al 8.5.2 Installing the wood set Virtuo Evolve 130 Place the logs exactly in accordance with the following description in order to achieve a correct alignment of the flame picture and the logs. Step 1 Carefully remove the wood set from their packaging.
  • Page 38 I ns t al lat ion m an u al i n s ta l l at i e h a n d l e i d i n g Step 2 Take log A and place it on the three small positioning cams in the centre rear of the stove (fig 8-33 en 8-34). Then take log B and place it diagonally on the positioning cams in the middle left rear and middle left front (fig.
  • Page 39 I ns t al lat ion m an u al 8-35...
  • Page 40 I ns t al lat ion m an u al i n s ta l l at i e h a n d l e i d i n g Step 3 Place log D on the positioning cam on the left on the glow bed. The positioning cam at the bottom right on log D falls into the recess on log B (fig 8-36 and 8-37).
  • Page 41 I ns t al lat ion m an u al 8-38...
  • Page 42 I ns t al lat ion m an u al i n s ta l l at i e h a n d l e i d i n g Step 4  P lacelogHtotherearleft,inbackoflogEasshowninfigure8-39and8-40.Here,itisimportantthatthelogfalls intotherecessoftheglowbed. TakelogIandplaceitdiagonallybehindlogGasshownon(fig.8-39and8-40). TheleftsideoflogIrestsonlogC.. PlacelogJrightbehind,infrontoflogDasshownon(fig.8-39and8-40).ThislogisplacedbehindlogH. 8-39 8-40...
  • Page 43 I ns t al lat ion m an u al Step 5 Spreadoutthecompletesetofglowingembersacrosstheglowbedoftheappliance,coveringtheentireelevated transparent part of the bottom. Here, it is important that the glowing embers connect properly to the logs and completelycoverthetransparentpartoftheglowbed.(fig.8-41and8-42). Tobetterdistributetheglowingembers,itcanbeusefultotemporarilyremovelogsH-I-J.Placethelogsbackafter theglowingembershavebeendistributed. Step 6 Takethecoalsandspreadthemoutaroundtheglowingembersinanatural-lookingway.Spreadoutafewcoals ontopoftheglowingembers(fig.8-43and8-44). 8-41 8-43 8-42 8-44...
  • Page 44 I ns t al lat ion m an u al i n s ta l l at i e h a n d l e i d i n g Step 7 Taketheblackchipsandgreychipsandspreadthemoutinaplayfulandnaturallookingwayaroundtheglowing embers,blackandgreycoalsandtheflatsectionoftheappliance’sbottom.(fig.8-45). Itwilllookmorenaturalifthechipsareoccasionallyontopofoneanotheranddonotfullycoverthebottomofthe appliance. Makesurethatnochipsorothermaterialsprotrudeovertheedge.Thiscouldmakeitimpossibletoplacethe projectionplateorglasspaneorcausedamagetotheseitems(fig.8-45). 8-45...
  • Page 45 I ns t al lat ion m an u al Step 8 Evenlyspreadoutthewoodchipsacrosstheglowbed.Ensurethatthechipsaremixed. Ensurethatparticularlyatthefrontofthestovetherearechipswithvariousdimensionslyingtogetherforthebest possiblebottomcovering.(fig.8-46). After placing the wood set and projection plate, check the flame picture and adjust the placement of the logs wherenecessary(fig.8-47).Atcompletionoftheinstallation,alsoensureaproperdistributionofthechips,glowing embersandblackandgreycoals. 8-46 8-47...

  • Page 46: Placing The Log Set Virtuo 180

    I ns t al lat ion m an u al i n s ta l l at i e h a n d l e i d i n g 8.5.3 Installing the wood set Virtuo Evolve 180 Place the logs exactly in accordance with the following description in order to achieve a correct alignment of the flame picture and the logs.
  • Page 47 I ns t al lat ion m an u al Step 2 Take log A and place it on the two small positioning cams in the centre rear of the stove (fig. 8-53 and 8-54). Then place log B perpendicularly across log A, whereby the right side fits on a cam (fig. 8-53) on the glow bed. This causes the cam at the bottom of log B to fall into the recess of log A (fig.
  • Page 48 I ns t al lat ion m an u al i n s ta l l at i e h a n d l e i d i n g 8-55...
  • Page 49 I ns t al lat ion m an u al Step 3 Place log D on the centre right rear and centre right front positioning cams (fig. 8-56 and 8-57). Place the right side of log F on the most right cam of the glow bed (fig. 8-56). Allow the positioning cam of log F to rest on the recess on the back of log D (fig.
  • Page 50 I ns t al lat ion m an u al i n s ta l l at i e h a n d l e i d i n g 8-58...
  • Page 51 I ns t al lat ion m an u al Step 4 Place log H to the rear left, in front of log E as shown in figure 8-59 and 8-60.Here, it is important that the log falls into the recess of the glow bed.
  • Page 52 I ns t al lat ion m an u al i n s ta l l at i e h a n d l e i d i n g Step 5 Spreadoutthecompletesetofglowingembersacrosstheglowbedoftheappliance,coveringtheentireelevated transparent part of the bottom. Here, it is important that the glowing embers connect properly to the logs and completelycoverthetransparentpartoftheglowbed.(fig.8-64and8-65).
  • Page 53 I ns t al lat ion m an u al Step 7 Taketheblackchipsandgreychipsandspreadthemoutinaplayfulandnaturallookingwayaroundtheglowing embers,blackandgreycoalsandtheflatsectionoftheappliance’sbottom.(fig.8-68). Itwilllookmorenaturalifthechipsareoccasionallyontopofoneanotheranddonotfullycoverthebottomofthe appliance. Makesurethatnochipsorothermaterialsprotrudeovertheedge.Thiscouldmakeitimpossibletoplacethe projectionplateorglasspaneorcausedamagetotheseitems(fig.8-68). 8-68...
  • Page 54 I ns t al lat ion m an u al i n s ta l l at i e h a n d l e i d i n g Step 8 Evenlyspreadoutthewoodchipsacrosstheglowbed.Ensurethatthechipsaremixed. Ensurethatparticularlyatthefrontofthestovetherearechipswithvariousdimensionslyingtogetherforthebest possiblebottomcovering.(fig.8-69). After placing the wood set and projection plate, check the flame picture and adjust the placement of the logs wherenecessary(fig.8-70).Atcompletionoftheinstallation,alsoensureaproperdistributionofthechips,glowing embersandblackandgreycoals..

  • Page 55: Final Check

    I ns t al lat ion m an u al Final check For a good and safe operation of the appliance, the following checks must be performed prior to commissioning. Familiarise the end user with the appliance. Instruct him about using it for the first time, the safety measures, how the remote control works and the recommended annual maintenance.

  • Page 56: Delivery

    I ns t al lat ion m an u al i n s ta l l at i e h a n d l e i d i n g 10. Maintenance - Make sure there is no voltage on the appliance during maintenance work. - Make sure the appliance has cooled down to room temperature and has been made free from voltage before maintenance is started.

  • Page 57: Malfunctions

    I ns t al lat ion m an u al 11. Malfunctions In case of poor operation of the appliance, consult the following overview of malfunctions. Does it not contain your malfunction? Remove the plug from the socket and contact your dealer. Do not open the appliance yourself and do not make changes yourself.
  • Page 58 I ns t al lat ion m an u al The appliance does switch on, but the heating does not switch on. Switch the appliance off and on by making it free from voltage using the main switch. Switch the main switch as described in user manual section 3.3. Perform a factory reset as described in user manual section 5.3.
  • Page 59 I ns t al lat ion m an u al Notes ..........................................................
