Metro 130XTL RCH
G20/G25/G25.3 (Natural gas) G31 (Propane)
Installation manual
Store this document in a safe place
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Metro 130XTL RCH and is the answer not in the manual?

Questions and answers

Related Manuals for Dru Metro 130XTL RCH

Summary of Contents for Dru Metro 130XTL RCH

  • Page 1 Metro 130XTL RCH G20/G25/G25.3 (Natural gas) G31 (Propane) Installation manual Store this document in a safe place...

  • Page 2: Table Of Contents

    I N ST A L LA T I ON MA N U A L Contents 1. Introduction 2. CE declaration 3. SAFETY 3.1 General 3.2 Regulations 3.3 Precautions / safety instructions at installation 3.4 Principle of ignition cycle 4. Removing the packaging 5.

  • Page 3: Introduction

    The figures are at the back of this installation manual, in the appendix. Fully and carefully read and use this installation manual, before installing the appliance. When using the DRU Powervent system® or DRU CM system®, the accompanying installation manual should also be read completely and carefully, before installation work is started.

  • Page 4: Safety

    This has to do with the temperature development in the chimney breast. Ø Only use the flue gas discharge / combustion air supply system supplied by DRU. Ø When installing a free-standing appliance: place the appliance away from the back wall by the minimum distance stated further down in the text.

  • Page 5: Principle Of Ignition Cycle

    I N ST AL L A T ION M AN UA L 3.4 Principle of ignition cycle Below you will find a brief description of how this appliance is ignited. The receiver in the appliance will get a signal from the remote control to start the ignition process. The receiver will get the signal to start the ignition process.

  • Page 6: Installation

    It is possible to operate one or more lamps (in case of several lamps, a maximum of 8A/250VAC/30VDC) via the remote control of the appliance. You could think of the lamps of Dru's lux elements. For this, you can use switch contact B on the receiver (see appendix 3, fig 36).

  • Page 7: Placing A Built-In Appliance

    (if applicable) Not all built in DRU appliances are supplied with a control hatch. Built in appliances must be installed with the DRU control hatch. This is necessary to ensure a durable, safe and !Caution proper operation. The DRU control hatch can be ordered separately. Exceptions are: Appliances with supplied DRU guard cabinet.

  • Page 8: Placing The Control Hatch

    !Tip You should preferably apply the ventilation holes (outgoing) on both sides of the chimney breast. Use the DRU ventilation elements. Check the following issues, before the chimney breast is fully closed: •...
  • Page 9 I N ST AL L A T ION M AN UA L Ø Attach the bracket with gas control to the inner frame (A). Proceed as follows: • Unwind the cables. This will, amongst other things, prevent a poor operation of the ignition. •...

  • Page 10: Concentric System

    5.8 Concentric system 5.8.1 General The appliance is connected to a flue gas discharge / combustion air supply system delivered by DRU, hereafter referred to as the concentric system. The diameter for this connection is indicated in appendix 2, table 2. The passage to the outside can be created with a wall terminal (C11) or a roof terminal (C31).

  • Page 11: Connection To An Existing Chimney (C91)

    The following requirements apply when connecting to an existing chimney: • Only allowed when used in combination with the special DRU chimney set. The installation regulation is parat of the delivery. •...

  • Page 12: Additional Instructions

    I N ST A L LA T I ON MA N U A L 5.10 Additional instructions For adjusting Profile C (see Appendix 3, fig. 6) in relation to the construction frame, proceed as follows: Ø Loosen the self-tapping screws by one stroke. Slide the profile to the required distance in relation to the construction frame (15-30 mm).

  • Page 13: Placing Glass Panes

    5.11.4 Placing glass panes Placing the glass panes will take place in reverse order of the removal procedure described above. • The DRU logo should be in the bottom right corner. !Caution • The self-tapping screws should not be over-tightened, since otherwise they could break or strip the thread: tight=tight.

  • Page 14: Placing The Wood/Pebble Set

    I N ST A L LA T I ON MA N U A L 5.13 Placing the wood/pebble set The appliance is supplied with a wood set or a pebble set. The vermiculite that is used to fill the burner is black when using the wood set and has a natural colour when using the pebble set.

  • Page 15: Pebble Set

    I N ST AL L A T ION M AN UA L 5.13.2 Pebble set The pebble set consists of vermiculite (see Appendix 3, fig. 21) and pebbles. The figures do not always show the correct colours. !Caution Ø Remove the positioning bracket for the vermiculite tray (see Appendix 3, fig. 28). Ø...

  • Page 16: Control

    IN ST ALL AT ION M A N U A L 6. Control The appliance is supplied with a wireless black remote control for the user (see appendix 3, fig. 35 (B)). As an option, an orange remote control can be supplied for the installer (see appendix 3, fig. 35 (O). Controlling the flame height, igniting and switching off take place through the black remote control controlling the receiver.
  • Page 17 6.2.2.2 Control via application Also when operating the appliance via a tablet provided with the DRU Control App (iOS or Android), you will need a communication module. This module can be ordered from DRU. In order to control the fire via an application, proceed as follows: Ø...

  • Page 18: Final Inspection

    I N ST A L LA T I ON MA N U A L 7. Final inspection In order to check whether the appliance is working properly and safely, you must perform the following inspections before the appliance is put into operation. 7.1 Gastightness All connections must be gastight.

  • Page 19: Flame Picture

    Avoid/remove fingerprints on the glass pane(s), as they will burn into the glass. • Only clean glass pane(s) with DRU glass pane cleaner, as other agents may damage and/or deteriorate the glass pane(s). For more information, visit our website www.dru.nl or ask your dealer.

  • Page 20: Parts

    I N ST A L LA T I ON MA N U A L 8.1 Parts Components that have to be replaced are available at the supplier. Delivery You must explain to the user how to operate the appliance. You must give him/her instructions on putting it into operation, the safety measures, the operation of the remote control and the annual maintenance (see the User Manual).

  • Page 21: Appendix 1 Malfunctions

    I N ST AL L A T ION M AN UA L Appendix 1 Malfunctions Error messages Error code Problem Possible cause Remedy Communication loss Communication cable does Make sure the connectors of between receiver and not make contact the communication cable burner device make proper contact Communication cable...
  • Page 22 I N ST AL L A T I O N M A N U A L Error messages Error code Problem Possible cause Remedy Ionization pin Replace the ionization (follow-up) defective (measure ionization current when 0) ESYS is not released ESYS is in hard-lock Wait half hour until ESYS resets itself.

  • Page 23: Appendix 2 Tables

    I N ST AL L A T ION M AN UA L Appendix 2 Tables Table 1: Parts included with the delivery Part Number Wood set / pebble set Control hatch Control hatch manual Installation manual User manual Decorative strip left Decorative strip right Decorative strip below Gauge for restrictor slide...
  • Page 24 I N ST AL L A T I O N M A N U A L Table 2: Technical data Model identifier(s) Metro 130XTL RCH Type of appliance Built-in Combustion Closed combustion Supply and discharge system Concentric 200/130 Flame protection version...
  • Page 25 I N ST AL L A T ION M AN UA L Table 3: Line-pressure when using G31 Country mbar NL / DK / FI / NO / SE / HU / BA / GR FR / BE / IT / PT / ES / GB / IE Permissibility and conditions concentric system with wall terminal Table 4: Conditions for setting the appliance G20/G25/G25.3/G31...
  • Page 26 I N ST AL L A T I O N M A N U A L Table 5: Determining permissibility concentric system with roof terminal G20/G25 Total number of meters Total no. of meters vertical and/or sloping pipe length G25.3/G31 horiz.

  • Page 27: Appendix 3 Figures

    Appendix 3 Figures min 868 max 883 1350 min 16 max 31 1397 1300 min 282 max 332 38C-1975 /0 Metro 130XTL RCH Left min 868 max 883 1350 1397 1300 min 282 max 332 38C-1976 /0 Metro 130XTL RCH Right...
  • Page 28 I N ST A L LA T I ON MA N U A L Tot. min. 200cm² 38c-1645 /0...
  • Page 29 I N ST AL L A T ION M AN UA L 38C-1868 d /0 1x90° 38c-744zi 0 - 5m...
  • Page 30 I N ST AL L A T I O N M A N U A L 38c-1646 /0 38c-1647 /0 38c-1649 /1 38c-1648 /0 38c-1650 /0 38c-1651 /0 38c-1652 /0 38c-1653 /0...
  • Page 31 I N ST AL L A T ION M AN UA L 38c-1655 /0 38c-1656 /0...
  • Page 32 I N ST AL L A T I O N M A N U A L 38C-1977 /0...
  • Page 33 I N ST AL L A T ION M AN UA L 38P-0263 38P-0432 38P-0434 38P-0433 38p-0022 38p-0023 38P-0028 /1...
  • Page 34 I N ST AL L A T I O N M A N U A L 38P-0169 38p-0443...
  • Page 35 I N ST AL L A T ION M AN UA L 38P-0442 38p-0444 38P-0445...
  • Page 36 I N ST AL L A T I O N M A N U A L 38P-0446 38P-0447 38c-1657 /0 38p-0448...
  • Page 37 I N ST AL L A T ION M AN UA L 38p-0440 38p-0441 0 – 3 V Modbus WiFi 38C-1871 /0 Router...
  • Page 38 I N ST AL L A T I O N M A N U A L 38p-0320 /0 – 0 – 3V     І     І     І    ...
  • Page 39 I N ST AL L A T ION M AN UA L (IN) 38p-0319 /2 Min. 0 mm Min. 0 mm 38C-2311/0 38C-2321/0 Min. 12,5 mm Min. 12,5 mm Min. 60 mm Min. 60 mm Min. 100 mm Min. 100 mm...
  • Page 40 DRU Verwarming B.V. The Netherlands Postbus 1021, NL-6920 BA Duiven Ratio 8, NL-6921 RW Duiven...
