ANGLE GRINDER
ENG
Original instructions
WINKELSCHLEIFER
DE
Originalbetriebsanleitung
SMERIGLIATRICE ANGOLARE
IT
Istruzioni originali
ЪГЛОШЛИФОВЪЧНА МАШИНА
BG
Оригинална инструкция за използване
УГЛОШЛИФОВАЛЬНАЯ МАШИНА
RU
Оригинальная инструкция по эксплуатации
SH150CS / SH150CSE
SH115 / SH125CSE
Advertisement
Table of Contents
Related Manuals for Status SH125CSE
Summarization of Contents
General Power Tool Safety Warnings
Work Area Safety
Keep work area clean and well lit. Avoid explosive atmospheres. Keep children and bystanders away.
Electrical Safety
Match plugs, avoid body contact with earthed surfaces, keep away from rain/wet, do not abuse cord, use outdoor extension cord, use RCD in damp locations.
Personal Safety
Stay alert, use common sense, do not use while tired or under influence.
Personal Protective Equipment
Wear face shield, goggles, safety glasses, dust mask, hearing protectors, gloves, and apron. Ensure eye protection stops debris; dust mask filters particles; hearing protection prevents noise loss.
Prevent Unintentional Starting
Ensure switch is off before connecting power, picking up, or carrying.
Remove Adjusting Keys or Wrenches
Ensure no tools are left attached to rotating parts before operation.
Maintain Proper Footing and Balance
Maintain proper footing and balance for better control.
Proper Dress and Hair
Avoid loose clothing, jewelry, or long hair near moving parts.
Dust Extraction and Collection
Ensure dust extraction and collection facilities are connected and used properly.
Power Tool Use and Care
Do not force tool, use correct tool for application, do not use if switch is faulty.
Disconnect Power Before Adjustments
Disconnect power before making adjustments, changing accessories, or storing.
Store Idle Power Tools Safely
Store out of reach of children and untrained persons.
Maintain Power Tools
Check for misalignment, binding, or breakage; repair if damaged.
Keep Cutting Tools Sharp and Clean
Properly maintained cutting tools reduce binding and improve control.
Use Tool According to Instructions
Use tool only for intended operations to avoid hazardous situations.
Safety Instructions for Angle Grinders
General Operations Safety
Follow all warnings, instructions, illustrations, and specifications provided with this power tool.
Accessory Compatibility
Use only manufacturer-recommended accessories for safe operation.
Accessory Speed Rating
Accessory rated speed must match or exceed tool's maximum speed.
Accessory Size and Fit
Accessory diameter, thickness, and arbour size must match tool specifications.
Inspect Accessories Before Use
Inspect accessories for damage; test run to detect breakage.
Bystander Safety
Ensure bystanders wear PPE and stay clear of flying debris.
Avoid Live Wire Contact
Hold tool by insulated surfaces to avoid shock from live wires.
Cord Management
Keep cord away from spinning accessory to prevent cutting or snagging.
Safe Tool Storage
Allow accessory to stop completely before setting tool down to prevent loss of control.
Avoid Carrying Tool with Spinning Accessory
Avoid carrying the tool with a spinning accessory to prevent snagging and injury.
Clean Air Vents Regularly
Clean air vents to prevent dust accumulation causing electrical hazards.
Keep Away From Flammable Materials
Sparks from the tool can ignite flammable materials.
Avoid Liquid Coolants
Using liquid coolants may result in electrocution or shock.
Further Safety Instructions
Specific safety instructions for all operations.
Kickback Prevention
Explains kickback and provides methods to avoid it.
Resist Kickback Forces
Use a firm grip and body position to resist kickback forces.
Keep Hands Clear of Accessory
Keep hands away from the rotating accessory to prevent kickback injury.
Avoid Kickback Path
Avoid positioning body where the tool will move if kickback occurs.
Care with Corners and Edges
Be careful with corners/edges to avoid bouncing and snagging.
Avoid Saw Blades
Avoid saw blades as they cause frequent kickback and loss of control.
Grinding and Cutting-Off Safety
Specific safety instructions for grinding and cutting operations.
Grinding and Cutting-Off Operations Safety
Use Recommended Wheels and Guards
Use only wheels and guards recommended for your power tool.
Guard Placement
Ensure guard is securely attached and positioned for maximum safety.
Correct Wheel Application
Use wheels only for recommended applications, e.g., don't grind side of cut-off wheel.
Use Correct Wheel Flanges
Always use undamaged, correctly sized and shaped wheel flanges.
Avoid Jamming Cut-off Wheel
Do not jam cut-off wheel or apply excessive pressure to prevent breakage.
Avoid Kickback During Cuts
Do not position body in line with rotating wheel; avoid kickback.
Stop Tool When Wheel Binds
Switch off and hold tool motionless if wheel binds or cut is interrupted.
Support Large Workpieces
Support workpieces to minimize wheel pinching and kickback.
Caution with Pocket Cuts
Use extra caution for pocket cuts to avoid hitting hidden utilities.
Functional Description and Assembly
Tool Introduction
This tool is intended for grinding, cutting and de-burring metal materials without water.
Functional Description
Details the angle grinder's design for industrial grinding and cutting applications.
Assembly Instructions
General instructions for assembling the tool and its components.
Wheel Guard Installation
Procedure for attaching and removing the protective wheel guard.
Grinding Wheel Installation
Step-by-step guide for mounting the grinding or cutting disc.
Operation Instructions
Intended Use
Angle grinder for grinding/cutting steel, stone, ceramic, bricks, tiles; not for wood or soft metals.
Pre-Operation Checks
Ensure disc, guard, and tool are in good condition before starting.
Do Not Cover Exhaust Vents
Avoid covering exhaust vents to prevent motor damage and reduced efficiency.
Guide Tool Motion
Guide back and forth over the workpiece in a steady motion.
Diamond Cutting Wheel
Recommend diamond cutting wheel for cutting hard stone.
Switch Action
Instructions on how to start and stop the tool using the on/off switch.
Rotation Speed Setting
How to adjust rotation speed using the variable speed dial (SH125CSE/SH150CSE).
Grinding Technique
Achieve best results with 30-40° angle for grinding, 15° for finishing.
Cutting Technique
Do not use cutting disc for roughing; do not press, tilt, or oscillate.
Maintenance and Inspection
Always unplug tool before inspection or maintenance.
Specifications and Accessories
Model Specifications
Table detailing models, voltage, power, speed, wheel size, weight, and features.
Noise and Vibration Data
Provides measured values for sound pressure, sound power, and vibration emission.
CE Declaration of Conformity
Manufacturer Declaration
STATUS ITALIA S.r.l. declares conformity of angle grinders to European Directives and standards.
