Summarization of Contents
General Power Tool Safety Warnings
Work Area Safety
Keep work area clean, well lit, and free from explosive atmospheres.
Electrical Safety
Proper plug usage, avoid contact with grounded surfaces, protect from water.
Personal Safety
Stay alert, use PPE, prevent unintentional starting, maintain balance.
Power Tool Use and Care
Use correct tool, maintain tool, disconnect power before adjustments.
Battery Tool Use and Care
Service
Have tool serviced by qualified personnel, do not service damaged battery packs.
Cordless Drill / Impact Drill Safety Warnings
Safety Instructions for All Operations
Wear ear protection, use auxiliary handles, brace the tool properly.
Additional Safety Warnings
General Precautions and Best Practices
Follow safety guidelines for drilling, handling tools, and battery use.
Caution on Lithium-Ion Battery
Battery Handling Warning
Prevent battery leakage, heat generation, smoke emission, explosion, and ignition.
Battery Liquid Contact Caution
Handle battery fluid carefully to avoid eye or skin irritation.
Lithium-Ion Battery Transportation
Battery Transportation Warning
Notify company, follow instructions for packages containing lithium-ion batteries.
USB Device Connection Precautions
USB Cable Warning
Check USB cable for defects; using a defective cable can cause smoke or ignition.
USB Charging Notes
Be aware of potential pauses during charging and remove USB devices when not in use.
Specifications
Specification Notes
Specifications subject to change due to ongoing research and development.
Charging
Charging Indicator Lamp Indications
Details on charge indicator lamp states during charging.
Battery Temperature and Charging Time
Details on charging temperatures and times for different battery types.
Recharging Notes
Recharging time may vary; handle charger cord and battery properly.
Battery Performance Longevity
Recharge Before Complete Exhaustion
Recharge when tool power weakens to prevent battery damage.
Avoid Recharging at High Temperatures
Allow hot batteries to cool before recharging to prevent deterioration.
Maintenance and Inspection
Inspecting the Tool
Sharpen or replace dull tools to maintain efficiency and prevent motor malfunction.
Inspecting Mounting Screws
Regularly inspect and tighten mounting screws to prevent hazards.
Terminal Inspection Caution
Check for and remove swarf/dust from terminals to prevent malfunction.
Motor Maintenance
Protect the motor winding from damage, oil, or water.
Cleaning the Exterior
Wipe with a soft dry cloth or damp cloth; avoid solvents.
Storage
Store tool and battery in a cool, dry place, out of reach of children.
Battery Storage Note
Ensure lithium-ion batteries are fully charged before storage for optimal performance.
Troubleshooting
Power Tool Troubleshooting
Addresses issues like tool not running, stopping suddenly, or bits not attaching.
Charger Troubleshooting
Addresses issues with charge indicator lamps, battery charging time, and USB charging.
