Summarization of Contents
How to Start Up
Setting the Probe Constant
Configures the instrument for measuring reversed surfaces or diameters by accounting for probe diameter and deflection.
Measuring Heights
Describes the process for taking reference planes and measuring heights on the instrument.
Measuring Diameters and Centerlines
Details how to measure diameters and centerlines using the instrument's specific modes.
Measuring with Min and Max Mode
Explains how to use the instrument's minimum and maximum value measurement functions.
Measuring with Delta Mode
Guides on performing measurements using the Delta mode to find differences.
Measuring of Squareness
Outlines the procedure for measuring squareness using the instrument and a dial indicator.
Measuring with Two References
Describes how to perform measurements using two distinct reference points on the instrument.
