Summary of Contents for TRIMOS V1
- Page 1 USER’S MANUAL V1 / V1+ 750 50 0066 03...
- Page 3 Dear customer, congratulations on choosing a TRIMOS measuring instrument. For over 50 years, our products have built up an excellent reputation for quality, accuracy and durability. To ensure that you are completely satisfied with this product, please read these operating instructions carefully.
-
Page 4: Table Of Contents
Selecting the main measurement modes ..............9 Height measurement ....................9 Diameter and centre distance measurement (V1+) ..........10 Measurement in Min / Max / Delta mode (V1+) ............12 6. Secondary Functions ......................14 Display zero/preset ....................14 References ........................ 14 Probe constant (V1+) .................... -
Page 5: Safety Instructions
SAFETY INSTRUCTIONS 1.1 Important information To avoid damage due to incorrect handling, please read the following instructions carefully. TRIMOS accepts no responsibility for damage to the instrument caused by use not in accordance with this manual. 1.2 General precautions Protection against electrostatic interference: Static electricity can damage the instrument's electronic components. -
Page 6: Presentation Of The Instrument
User’s manual PRESENTATION OF THE INSTRUMENT 750 50 0066 03... -
Page 7: Instrument
Interchangeable measurement insert Carriage locking knob Fine adjustment knob Fine adjustment engagement lever (V1+) Pre-load ring (for constant measuring force - V1+) Crank handle for moving the measuring carriage Connector for RS232/Wireless communication 2.2 Display Status symbols (battery level, units, active modes, etc.), Secondary display line 10. -
Page 8: Setting Up
User’s manual SETTING UP 3.1 Delivery The standard packaging contains the following items: Instrument V1 : Scriber (TA-MI-122) V1+ : Ø6 mm ball-insert (TA-MI-121) CR2032 battery Carriage locking screw Installation instructions (750 50 0067 00) V1 : Declaration of conformity... -
Page 9: Start
V1 / V1+ START 4.1 Handwheels 4.1.1 V1 The V1 handwheel has a fine adjustment wheel. To engage the fine adjustment, slide the wheel to the right (Pos. 1). Then simply adjust the position precisely by turning the wheel with your thumb. -
Page 10: Switching On
User’s manual 4.2 Switching on 1 To switch the instrument on, press the On/Off button. To switch it off, press the same button until the instrument switches itself off. 2 The instrument asks you to pass the reference. To do this, slowly move the measuring carriage from bottom to top. -
Page 11: Main Functions
V1 / V1+ MAIN FUNCTIONS 5.1 Selecting the main measurement modes Height The Function button is used to select the 3 main Diameter/axis measurement modes (V1+). Min/Max/Delta 5.2 Height measurement H1 = Downward height measurement ( ) H2 = Upward Height measurements ( ) 1 Select the height measurement mode. -
Page 12: Diameter And Centre Distance Measurement (V1+)
User’s manual 3. Probe the surface to be measured. The required value is displayed (V1+: as soon as the measuring force has been applied). 5.3 Diameter and centre distance measurement (V1+) D = Diameter measurement ( C = Centre distance measurement ( Zero on a reference plane. - Page 13 V1 / V1+ 3a. Internal diameter Position the insert into the bore and probe downwards close to the reversal point (1), applying the measuring force. Move the workpiece or instrument sideways to the insert to determine the reversal point (2). This is confirmed by the display flashing and a beep.
-
Page 14: Measurement In Min / Max / Delta Mode (V1+)
User’s manual 5.4 Measurement in Min / Max / Delta mode (V1+) Delta Max = Measurement of the maximum value ( Min = Measurement of the minimum value ( Delta = Difference between maximum and minimum ( Measurements in Min, Max and Delta mode are always taken with the insert in contact with a surface. - Page 15 V1 / V1+ 2. Probe the surface to be measured. As soon as the measuring force is applied, the display initialises the 2 lines at the position of the surface being measured. Then move the insert or the part along the area to be analysed.
-
Page 16: Secondary Functions
Preset Pressing and holding the Zero/Preset button initializes >2 s the display to the preset value of the current reference. Note (V1+) : In diameter and centre distance mode, a zero/preset will be performed on the last measured centre distance. -
Page 17: Probe Constant (V1+)
The connector is located on the right-hand side of the measurement carriage. It allows conventional connection to external devices with RS232 interfaces. RS232 cable Use the RS232 cable ref. Trimos TA-EL-112. Software TrimosDataTransfer software is available free of charge from www.trimos.com, in the relevant product section. - Page 18 The format of the value sent corresponds to the numerical value of the display in ASCII characters. Note (V1+) : In diameter/center distance mode, the 2 values are sent simultaneously. They are separated by an EOT (End Of Transmission).
-
Page 19: Configuration
V1 / V1+ CONFIGURATION To enter the configuration menu, press the Function key for 2 seconds. Simply press the Function key to confirm your choice and move on to the next menu. > 2 s To exit the configuration menu, press the Function key again for 2 seconds. - Page 20 User’s manual Reference gauge size (V1+) The size of the setting gauge can be set in the GAUGE menu. To set the value, proceed in the same way as in the PRESET menu. Note: (>2 s) A negative value means that the gauge is measured externally.
-
Page 21: After-Sales Service
TRIMOS dealer. 8.3 Claims / Repairs If you have any problems, please contact your TRIMOS dealer. Use the original packaging for transport. 8.4 Agents The official list of TRIMOS distributors can be found on the website www.trimos.com. 750 50 0066 03... -
Page 22: Dimensions
User’s manual DIMENSIONS 9.1 V1/V1+ L: Depends on the insert used. 750 50 0066 03... -
Page 23: V1+ G (Granite Base)
V1 / V1+ 9.2 V1+ G (Granite base) L: Depends on the insert used. 750 50 0066 03... -
Page 24: Technical Specifications
User’s manual TECHNICAL SPECIFICATIONS Measuring range mm (in) 306 (12) 611 (24) Max. permissible errors, B µm Repeatability, R (2s) µm Maximum resolution mm (in) 0.01 (0.001) Measuring force Autonomy 2000 Interface RS232 Max. travel speed mm/s 1500 Operating temperature °C +10 ÷... -
Page 25: Declaration Of Conformity
V1 / V1+ DECLARATION OF CONFORMITY DECLARATION DE CONFORMITE KONFORMITÄTSERKLÄRUNG DECLARATION OF CONFORMITY TRIMOS déclare que les instruments de mesure TRIMOS erklärt, dass die Messgeräte TRIMOS declares that the measuring instruments V1-300 V1+-300 V1+-300G V1-600 V1+-600 V1+-600G sont conformes aux directives suivantes : mit folgenden Richtlinien übereinstimmen :...
