  • Page 1 INNOVATIVE TECHNOLOGY PARTNER LS BROOM OPERATOR MANUAL MBR1154A TRACTOR Model • MT122, MT125 • MT225S PO Box 70, Battleboro, NC 27809 Tel : 252-984-0700 Fax : 252-984-0701 www.lstractor.com www.lstractorusa.com P/NO YA054-MES00...
  • Page 2 LS Broom OPERATOR MANUAL Model : MBR1154A Applied Tractor Option MT122 SHATTER- PROF RUBBER PLATE : MT125 40449120 MT225S...
  • Page 3 WARRANTY CONDITIONS Warranty Coverage : LS Mtron Tractor Division, herein referred to as LS Mtron, undertakes to replace or repair any part of a LS Mtron products where damage has been proven to be caused by defects in material or workmanship.
  • Page 4 PLEASE NOTE : Make sure all potential operators of the this equipment review this manual and all safety messages contained within This safety symbol indicates important safety messages in this manual. When you see this symbol, carefully read the message that follows and be alert to the possibility of personal injury or death.

  • Page 5: Table Of Contents

    Table of Contents OPERATOR MANUAL ▣ Safety Precautions --------------------- ▣ Safety Decal --------------------- ▣ Specification --------------------- ▣ Introduction --------------------- ▣ Torque Tightening Chart --------------------- 10 ▣Gearbox management --------------------- 11 ▣ How to replace the brush --------------------- 12 ▣ Drive shaft management --------------------- 13 ▣...

  • Page 6: Safety Precautions

    SAFETY PRECAUTIONS Most tractor and / or Broom accidents can be avoided by following simple safety precautions. The safety information given in this manual does not replace safety codes, insurance requirements, federal, state, and local laws. Make sure your machine has the correct equipment required by your local laws and regulations.
  • Page 7 SAFETY PRECAUTIONS SAFETY PRECAUTIONS TRANSPORTATION ▶ Never allow riders on tractor. Always use accessory lights and devices when transporting on a road or highway to warn operators of ▶ other vehicles. Check your local government regulations. Be sure the Slow Moving Vehicle(SMV) emblem is visible to the rear. If there is no SMV sign, wear, ▶...
  • Page 8 SAFETY PRECAUTIONS SAFETY OPERATION ▶ Working area Careful operation is your best insurance against an accident. Read this section carefully before 1. Thoroughly inspect the area where the Broom operating the Broom ASS'Y. All operators, no ASS'Y is to be used. matter how much experience they may have had, should read this manual, tractor manual and other related manuals before operating Broom...

  • Page 9: Safety Decal

    SAFETY DECAL Safety Decal Locations Care of Safety Decals. ▶ Keep safety decals clean and free of obstructing material. ▶ Clean safety decals with soap and water and dry with a soft cloth. ▶ Replace damaged or missing safety decals with new decals from your LS Mtron Dealer.

  • Page 10: Specification

    SPECIFICATIONS UNIT : mm(inch) Model name MBR1154A Applied Tractor MT122, MT125, MT225S Size (in) 59.9 x 48.8 x 28.7 Working width (in) P.T.O rotation speed(rpm) 2620 Gearbox rotation speed(rpm) Brush rotation speed(rpm) Quick attachment type Non-standard Quick Attachment Power transmission method Mid P.T.O...

  • Page 11: Introduction

    INTRODUCTION The purpose of this manual is to assist you in maintaining and operating your Snow Broom. Read it carefully, it furnishes information and instructions that will help you achieve years of dependable performance. Some information may be general in nature due to unknown and varying conditions. However, through experience and these instructions, you should be able to develop operating procedures suitable to your particular situation.

  • Page 12: Torque Tightening Chart

    TORQUE TIGHTENING CHART MINIMUM HARDWARE TIGHTENING TORQUES IN FOOT POUNDS (NEWTON-METERS) FOR NORMAL ASSEMBLY APPLICATIONS Always tighten hardware to these values unless a different torque value or tightening procedure is listed for a specific application. Fasteners must always be replaced with the same grade as specified in the manual parts list. Always use the proper tool for tightening hardware : SAE or SAE hardware and Metric for metric hardware.

  • Page 13: Gearbox Management

    Gearbox management WARNING AVOID BURNS The gearbox is hot immediately after operation. Let gearbox cool or use gloves when servicing. Detach from the tractor before servicing. You may be killed or injured by a malfunction of the tractor. Replace the gearbox oil after the first 50 hours and every 200 hours or one year thereafter. Fix the broom on a flat surface and start working.

  • Page 14: How To Replace The Brush

    How to replace the brush WARNING Detach from the tractor before servicing. You may be killed or injured by a malfunction of the tractor. Disassemble Sem's bolt(No.1) To disassemble Side cover(No.2) , remove hex. nut(No. 3). To disassemble Plate(No.5) , remove hex. bolt(No. 4). Replace the old brush(No.6) with a new one.

  • Page 15: Drive Shaft Management

    Drive joint shaft management Must inject GREASE before work. WARNING If the drive shaft is damaged or broken, do not repair it, replace it with a new one. Precautions for PTO operation Operate the PTO switch when the engine speed is less than 1000RPM. If the PTO switch is operated while the engine speed is high, the universal joint or the work machine may be damaged and damaged.

  • Page 16: Product Maintenance

    Product maintenance Product maintenance CAUTION : In order to maintain the performance of the product and prevent damage or abrasion, it is necessary to inject sufficient grease into the designated area periodically. Every 6 months POINT 1 Before starting work, remove the grease injection cover and inject enough greas POINT 2 If Broom do not used for a long time.

  • Page 17: Broom Installation

    Broom installation Turn the quick attachment locking levers upward. After installing the snow blower, turn down the lever to lock quick attachment correctly. In order to prevent safety accidents, make sure that the broom are properly fixed before starting work. - 15 -...

  • Page 18: Drive Joint Installation

    Drive joint Installation Broom  gearbox spline shaft Just only  double  cardan joint Sub frame  drive spline  shaft Must only assemble the double cardan joint to the Broom gearbox spline shaft. If the double cardan joint is assembled in the reverse direction, there is a risk of joint damage and injury to people around it.
  • Page 19 - 17 -...

  • Page 20: Note On Snowbroom Work

    Note on Snowbroom work If the snow removal height is 1 inch or higher, snow removal may not work well, so other snow removal machines should be used. If the snow removal amount is too high or the snow removal is done only in the front, the product can be damaged and damaged.
  • Page 21 PART ILLUSTRATIONS GENERAL INFORMATION Illustrations The individual parts in their normal relationship to each other. Reference numbers are used in the illustrations. These numbers correspond to those in the "Number" column and are followed by the quantity required and description. Directional Reference "Right hand"...

  • Page 22: Imbr10. Frame & Brush Group

    IMBR10. FRAME & BRUSH GROUP - 20 -...
  • Page 23 IMBR10. FRAME & BRUSH GROUP DESCRIPTION LS PART NO. QT'Y SERIAL OR DATE MAIN FRAME W.D ASS'Y 40442470 BRUSH FRAME W.D ASS'Y 40442475 40442468 BRUSH, 24".RING I.D 6-3/8" ,POLYETHYLENE PLATE 40442482 HEX. BOLT, M10XL70 40365448 SIDE COVER W.D ASS'Y 40442471 HEX.

  • Page 24: Imbr20. Side Drive Line Group

    IMBR20. SIDE DRIVE LINE GROUP - 22 -...
  • Page 25 IMBR20. SIDE DRIVE LINE GROUP DESCRIPTION LS PART NO. QT'Y SERIAL OR DATE HEX. BOLT, M12XL40 40365450 UNIT BEARING, UCF205 40442424 40228642 SPRING WASHER, M12 HEX. NUT, M12 40228631 ROLLER CHAIN, #60-44 LINK 40442447 SPROCKET 2, #60,Z12 40442486 SPROCKET 1, #60,Z14 40442485 CHAIN COVER 40442478...

  • Page 26: Imbr30. Tilting Group

    IMBR30. TILTING GROUP - 24 -...
  • Page 27 IMBR30. TILING GROUP LS PART NO. DESCRIPTION QT'Y SERIAL OR DATE ATT. BRACKET WD ASS'Y-RH 40442527 RHSN BOLT, M10XL25 40440270 ATT. BRACKET WD ASS'Y-LH 40442528 40442474 MAIN HINGE FRAME WD ASS'Y SPRING WASHER, M10 40228641 HEX. NUT, M10 40305381 NYLON NUT, M14 40255414 FLAT WASHER, M14 40440274...

  • Page 28: Imbr40. Drive & Wheel Group

    IMBR40. DRIVE & WHEEL GROUP - 26 -...
  • Page 29 IMBR40. DRIVE & WHEEL GROUP LS PART NO. DESCRIPTION QT'Y SERIAL OR DATE GEARBOX COVER WD ASS'Y 40442484 COLLAR, H10 40284537 SEM'S BOLT, M8XL20 40245474 40228616 HEX. BOLT, M12XL40 SEM'S BOLT, M8XL25 40230889 NYLON NUT, M8 40230896 KEY, 8X8XL25 40440282 DRIVE SHAFT WD ASS'Y 40442476 NYLON NUT, M10...

  • Page 30: Imbr50. Hydraulic Group

    IMBR50. HYDRAULIC GROUP - 28 -...
  • Page 31 IMBR50. HYDRAULIC GROUP DESCRIPTION LS PART NO. QT'Y SERIAL OR DATE CYLINDER ASS'Y, ∅70*∅30*114ST*300CL 40442449 NIPPLE(ELBOW), 1/2-20UNF,HOSE*PF1/4,O-RING 90 40230664 40230701 O-RING, 1BP11 HOSE- WEBING, 1(PT3/8)-4(1/2-20UNF) 1550L(1/4) 40440298 HOSE- WEBING, 1(PT3/8)-4(1/2-20UNF) 1750L(1/4) 40442401 NIPPLE, 1/2-20UNF,HOSEX PF1/4, O-RING 40358852 QUICK COUPLER, 3/8, FEMELE 40228721 DUST PLUG, 3/8, BLUE, MELE 40228722...

  • Page 32: Imbr60. Cylinder Group

    IMBR60. CYLINDER GROUP - 30 -...
  • Page 33 IMBR60. CYLINDER GROUP DESCRIPTION LS PART NO. QT'Y SERIAL OR DATE 40442433 SNAPRING, RTW-35 (HOLE) BEARING, GE20ES 40442430 ROD ASS'Y 40440284 STOP RING, Ø44*2T 40442432 40442436 DUST SEAL, DKBI 30*42*6/9 BACK UP RING, G65 40248815 O-RING, 1BG65 40230861 ROD COVER, Ø70*Ø30*60L 40442435 DU-BUSH, 3030 40256361...

  • Page 34: Imbr70. Gearbox Group

    IMBR70. GEARBOX GROUP - 32 -...
  • Page 35 IMBR70. GEARBOX GROUP LS PART NO. DESCRIPTION QT'Y SERIAL OR DATE CASE-LH 40442465 PRESSURE RELIEF PLUG 40415701 OIL SEAL, D30XD50X8T 40442407 40440294 TAPER ROLLER BEARING, #32206 WORM WHEEL 40442461 SHAFT 40442460 KEY, 8X8XL25 40440282 SEAL COVER 40442464 NYLON NUT, M8 40230896 CASE-RH 40442466...
  • Page 36 IMBR90. SHATTER- PROF RUBBER PLATE(Option) - 34 -...
  • Page 37 IMBR90. SHATTER- PROF RUBBER PLATE(Option) DESCRIPTION LS PART NO. QT'Y SERIAL OR DATE HOOK-LH 40442491 HOOK-RH 40442492 40442496 GUIDE WD ASS'Y-RH GUIDE WD ASS'Y-LH 40442497 HOOK CROSS BAR 40442493 PLATE 40442494 RUBBER FILM, 1370*430*5T 40442495 GUARD WD ASS'Y 40442498 RHSN BLOT, M8XL25 40440262 HEX.

  • Page 38: Img980. Decal Group

    IMG980. DECAL GROUP CAUTION : Before use, read the tractor user manual and familiarize yourself with the decal attached to the attachme - 36 -...
  • Page 39 IMG980. DECAL GROUP DESCRIPTION NO. LS PART NO. QT'Y SERIAL OR DATE DECAL-MD(MBR1154A)-ATG980 40438863 DECAL-OPERATE WARNING-IMG980 40438854 DECAL-CRUSH WARNING-IMG980 40438858 40435060 DECAL-HYD WARNING-IMG980 DECAL-DRIVELINE DANGER-IMG980 40438853 DECAL-FLYING_ENTANGLE WARNING-IMG980 40438857 DECAL-DUST WARNING-IMG980 40438856 DECAL-MISUSE WARNING-IMG980 40438855 NAME PLATE-LSTA-IMG980 40450477 DECAL-LS-TRG980 40359777 DECAL-WARNING-TSMM 40376542 - 37 -...
