LS BLADE
OPERATOR MANUAL
MBD1160A
TRACTOR Model
• MT122, MT125, MT225S
INNOVATIVE
TECHNOLOGY
PARTNER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LS BLADE MBD1160A and is the answer not in the manual?

Questions and answers

Summary of Contents for LS tractor LS BLADE MBD1160A

  • Page 1 INNOVATIVE TECHNOLOGY PARTNER LS BLADE OPERATOR MANUAL MBD1160A TRACTOR Model • MT122, MT125, MT225S PO Box 70, Battleboro, NC 27809 Tel : 252-984-0700 Fax : 252-984-0701 www.lstractor.com www.lstractorusa.com YP060-MES00 P/NO REVSION : 05...
  • Page 2 LS Blade OPERATOR MANUAL Model : MBD1160A Applied Tractor OPTION MT122 MT125 RUBBER BLADE : 40449116 MT225S...
  • Page 3 WARRANTY CONDITIONS Warranty Coverage : LS Mtron Tractor Division, herein referred to as LS Mtron, undertakes to replace or repair any part of a LS Mtron products where damage has been proven to be caused by defects in material or workmanship.
  • Page 4 PLEASE NOTE : Make sure all potential operators of the this equipment review this manual and all safety messages contained within. This safety symbol indicates important safety messages in this manual. When you see this symbol, carefully read the message that follows and be alert to the possibility of personal injury or death.
  • Page 5: Table Of Contents

    Table of Contents OPERATOR MANUAL ▣ Safety Precautions -------------------- ▣ Safety Decals -------------------- ▣ Specification -------------------- ▣ Introduction -------------------- ▣ Torque Tightening Chart -------------------- ▣ Product maintenance -------------------- ▣ Blade installation -------------------- ▣ Hydraulic system schematic -------------------- ▣ Trouble shooting -------------------- ▣...
  • Page 6: Safety Precautions

    SAFETY PRECAUTIONS Most tractor and / or Blade accidents can be avoided by following simple safety precautions. The safety information given in this manual does not replace safety codes, insurance requirements, federal, state, and local laws. Make sure your machine has the correct equipment required by your local laws and regulations.
  • Page 7 SAFETY PRECAUTIONS SAFETY PRECAUTIONS TRANSPORTATION ▶ Never allow riders on tractor. Always use accessory lights and devices when transporting on a road or highway to warn operators of ▶ other vehicles. Check your local government regulations. Be sure the Slow Moving Vehicle(SMV) emblem is visible from the rear view. If there is no SMV sign, ▶...
  • Page 8 SAFETY PRECAUTIONS SAFETY OPERATION ▶ Working area Careful operation is your best insurance against an accident. Read this section carefully before 1. Thoroughly inspect the area where the Blade is operating the Blade. All operators, no matter how to be used. much experience they may have had, should read this manual, tractor manual and other related manuals before operating Blade.
  • Page 9: Safety Decals

    SAFETY DECALS Care of Safety Decals. ▶ Keep safety decals clean and free of obstructing material. ▶ Clean safety decals with soap and water and dry with a soft cloth. ▶ Replace damaged or missing safety decals with new decals from your LS Mtron Dealer.
  • Page 10: Specification

    INTRODUCTION The purpose of this manual is to assist you in maintaining and operating your Snow Blade. Read it carefully, it furnishes information and instructions that will help you achieve years of dependable performance. Some information may be general in nature due to unknown and varying conditions. However, through experience and these instructions, you should be able to develop operating procedures suitable to your particular situation.
  • Page 11 SPECIFICATIONS UNIT : mm(inch) Model name MBD1160A Applied Tractor MT122, MT125, MT225S Size (in) 60 x 31.6 x 22.9 Working width (in) Quick attachment type Non-standard Quick Attachment ±30 º Tilting (deg) Right and left Weight (lb) - 9 -...
  • Page 12: Torque Tightening Chart

    TORQUE TIGHTENING CHART MINIMUM HARDWARE TIGHTENING TORQUES IN FOOT POUNDS (NEWTON-METERS) FOR NORMAL ASSEMBLY APPLICATIONS Always tighten hardware to these values unless a different torque value or tightening procedure is listed for a specific application. Fasteners must always be replaced with the same grade as specified in the manual parts list. Always use the proper tool for tightening hardware : SAE or SAE hardware and Metric for metric hardware.
  • Page 13: Product Maintenance

    Product maintenance Product maintenance CAUTION : In order to maintain the performance of the product and prevent damage or abrasion, it is necessary to inject sufficient grease into the designated area periodically. POINT 1 Every 6 months POINT 2 Every One year If Blade do not used for a long time.
  • Page 14: Blade Installation

    Blade installation ◆ In case of assembling the blade in a dedicated sub frame. Turn the quick attachment locking levers upward. After installing the blade, turn down the lever to lock quick attachment correctly. In order to prevent safety accidents, make sure that the blade are properly fixed before starting work.
  • Page 15 ◆ In case of assembling the blade to the loader ① If the loader has a quick attach. Turn the quick attachment locking levers upward. After installing the blade, turn down the lever to lock quick attachment correctly. In order to prevent safety accidents, make sure that the blade are properly fixed before starting work.
  • Page 16 ② If the loader does not have a quick attach. Precautions before work CAUTION : After attaching the blade to the tractor, change the stand position as shown in the picture. Otherwise, the stand may collide with the floor during work and cause damage. After installing the blade on the tractor, fix the stand at position (1) using a "D"...
  • Page 17 How to connect hydraulic ports A 3rd Function Extension Kit is required if you use blades on your loader. (3rd function Kit No. : 40432048) To connect with the 3rd function hydraulic kit, you have to change the blade's quick coupler(①) from female to male.
  • Page 18: Hydraulic System Schematic

    HYDRAULIC SYSTEM SCHEMATIC AUXILIARY HYDRAULIC VALVE PACKAGE When the blade is assembled  When the blade is assembled in  in the sub frame.(MT225S) the sub frame.(MT122,MT125) When the blade is assembled to the loader. - 16 -...
  • Page 19: Trouble Shooting

    TROUBLE SHOOTING This Trouble Shooting Chart is provided for reference to possible Sub frame & drive kit operational problems. Determine the problem that best describes the operational problem being experienced and eliminate the possible causes as listed by following the correction procedures. PROBLEM POSSIBLE CAUSE CORRECTION...
  • Page 20 MEMO...
  • Page 21: Parts Illustrations General Information

    PART ILLUSTRATIONS GENERAL INFORMATION Illustrations The individual parts in their normal relationship to each other. Reference numbers are used in the illustrations. These numbers correspond to those in the "Number" column and are followed by the quantity required and description. Directional Reference "Right hand"...
  • Page 22: Imbd10 Body Group

    IMBD10. BODY GROUP - 20 -...
  • Page 23 IMBD10. BODY GROUP LS PART NO. DESCRIPTION QT'Y SERIAL OR DATE 40442529 BLADE WD ASSY 40442530 BLADE ATT. WD ASS'Y 40442531 ATT. BRACKET WD ASS'Y-RH 40442532 ATT. BRACKET WD ASS'Y-LH 40442535 SUSPENSION ASS'Y 40442536 SUSPENSION WD ASS'Y 40442537 SPRING CAP, 1.2t 40440279 SPRING, Ø10xPCD70xL260 40343502...
  • Page 24: Imbd20 Hydraulic Group

    IMBD20. HYDRAULIC GROUP In case of assembling the  blade to the loader valve  ports. (MT225S) In case of assembling the  blade to the 3 function  In case of assembling the  blade to the loader valve  ports. (MT122, MT125) - 22 -...
  • Page 25 IMBD20. HYDRAULIC GROUP LS PART NO. DESCRIPTION QT'Y SERIAL OR DATE 40440337 CYLINDER ASS'Y, Ø50*Ø35*159.5ST*386CL 40230664 NIPPLE(ELBOW), 1/2-20UNF,HOSE* PF1/4,O-RING 90 40230701 O-RING, 1BP11 40440299 HOSE- WEBING, 1(PT3/8)-4(1/2-20UNF) 1550L(1/4) 40440300 HOSE- WEBING, 1(PT3/8)-4(1/2-20UNF) 1750L(1/4) 40440291 CABLE TAI, 780mm (30"), BLACK 40228721 QUICK COUPLER, 3/8, FEMALE 40228722 DUST PLUG, 3/8, BLUE, MALE...
  • Page 26: Imbd30 Cylinder Group

    IMBD30. CYLINDER GROUP - 24 -...
  • Page 27 IMBD30. CYLINDER GROUP LS PART NO. DESCRIPTION QT'Y SERIAL OR DATE 40440290 ROD ASS'Y 40442441 CAP-OUTER, Ø50XØ60X40L 40440338 ROD COVER, Ø50XØ35X65L 40228766 DUST SEAL, SDR 35*43*5/6.5 40228884 U-PACKING, SKY 35*45*6 40228768 DU-BUSH, 3530 40442442 O-RING, 1BG45 40442451 PISTON, Ø50XØ27X50L 40228870 O-RING, 1BG27 40228880 U-PACKING, ISI 35*45*6...
  • Page 28: Img980 Decal Group

    IMG980. DECAL GROUP CAUTION : Before use, read the tractor user manual and familiarize yourself with the decal attached to the attachment Refer to category "Safety decals" - 26 -...
  • Page 29 IMG980. DECAL GROUP LS PART.NO DESCRIPTION SERIAL OR DATE 40438862 MODEL NAME 40439298 DECAL, WARNING 40435056 DECAL, WARNING 40438854 DECAL, WARNING 40438855 DECAL, WARNING 40410879 NAME PLATE 40359777 LS LOGO. - 27 -...
