VDO CONTISYS OBD Quick Reference Manual page 7

Quick Reference Guide
Overview
4 D I
3 C J
2 11 B K
1 12 A L
5
4
3
2
1
CON0016s
The kit includes:
1. Service tool
2. EOBD cable
3. Carry case
4. CD ROM containing the Operating
Instructions
5. EOBD pin-switchable cable
6. EU power supply
7. USB software update cable
Keypad
6
Esc
7
CON0018s
The service tool is operated via the 6-
button keypad.
The table below details the keypad
buttons and their functionality.
Key Function
Select a menu option,
Continue or Yes.
Exit a menu or No.
Scroll up within a menu or
text.
Scroll down within a menu or
text.
Scroll left and right.
Provide context sensitive
help (where available).
7
