Summarization of Contents
Coupling and uncoupling
Coupling
Attaching the machine to the tractor's lift arms and top link for operation.
The angle of the lift arms
Adjusting lift arm angle for better obstacle clearance and steering.
Hydraulics
Specifies the number of double-acting hydraulic tappings required for different models.
Operation
Transport lock
Securing the side sections of hydraulic models in the transport position.
Adjustment
Hydraulics
Describes hydraulic flow control valves for side sections on the hydraulic model.
Maintenance
In general
General maintenance advice including lubrication and tightening screw joints.
Backlash in the rings
Procedure to reduce unacceptable backlash between the rings using washers.
Cleaning and maintenance
Cleaning the machine after use and checking for wear and backlash.
Optional equipment
Crackerboard
Details on mounting, function, and adjustment of the crackerboard.
Indication lights
Requirements for mounting indication lights for public road use.
REPAIR
Replacement of bearings/shafts/rings
Procedure for replacing bearings, shafts, and rings on different models.
Replacement of the nylon rail
Steps to remove and replace the nylon rail on the linkage.
Replacement of the cylinders for raising and lowering the side sections
Repair process for side section cylinders and their packings.
Replacement of the cylinders for the crackerboard
Repair process for crackerboard cylinders and their packings.
