Summarization of Contents
Outer Panels Removal
Stop Valve Cover Disassembly
Procedure to remove the stop valve cover and its associated shield plate.
Top Panel Removal
Procedure to detach the top panel by removing three mounting screws.
Front Panel Screw Removal
Procedure to remove the front panel by unscrewing six screws.
Outdoor Fan and Fan Motor Disassembly
Outdoor Fan Removal
Procedure to detach the outdoor fan by removing its securing nut.
Fan Motor Wiring Disconnection
Procedure to disconnect fan motor lead wires from the terminal board and capacitor.
Fan Motor Fixing Frame Removal
Procedure to remove the fan motor fixing frame by unscrewing and unfastening hooks.
Electrical Components and Partition Plate Removal
Wire Fixture Removal
Procedure to remove the wire fixture by unscrewing and unfastening a hook.
Terminal Board Wiring Disconnection
Procedure to disconnect the connecting wire from the terminal board.
Right Side Panel Removal
Procedure to remove the right side panel by unscrewing and unfastening hooks.
Sound Blanket Removal
Sound Blanket Detachment
Procedure to untie strings and carefully pull out the sound blanket.
Capillary Tube Removal
Terminal Cover and Pipe Disconnection
Procedure to remove the terminal cover and disconnect pipes using a nut and washer.
Capillary Tube Brazed Part Heating
Procedure to heat brazed parts and remove the capillary tube.
Compressor Disassembly
Compressor Terminal Cover Removal
Procedure to remove the terminal cover from the compressor.
Compressor Lead Wires Disconnection
Procedure to disconnect compressor lead wires and remove the gasket.
Compressor Mounting Nuts Removal
Procedure to remove the three mounting nuts securing the compressor.
