Summarization of Contents
Outer Panels Removal
Top Panel Removal
Steps to remove the top panel of the outdoor unit after disconnecting power.
Discharge Grille Removal
Steps to remove the discharge grille from the outdoor unit.
Front Panel Removal
Steps to remove the front panel of the outdoor unit by unfastening hooks and screws.
Outdoor Fan and Fan Motor Removal
Electrical Connections for Fan Motor
Disconnect terminals from capacitor and magnetic relay, release lead wire.
Outdoor Fan Removal
Remove the outdoor fan by unscrewing the fixing nut.
Fan Motor Fixing Frame and Motor Removal
Remove the fan motor fixing frame and the fan motor itself.
Electrical Component Assembly Removal
Initial Panel and Cover Removal
Remove the right side panel and stop valve cover.
Wire Fixture Removal
Remove the wire fixture securing electrical connections.
Terminal Board and Wiring Disconnection
Disconnect connecting and power supply wires from the terminal board.
Right Side Panel Detachment
Remove the right side panel by unfastening hooks and screws.
Sound Blanket and Partition Plate Removal
Sound Blanket Removal
Untie strings and pull out the sound blanket.
Partition Plate Removal
Remove the partition plate by unscrewing fixing screws.
Capillary Tube Removal
Terminal Cover and Pipe Disconnection
Remove terminal cover and disconnect brazed parts/pipes.
Compressor Lead Wires and Gasket
Disconnect compressor lead wires and remove the gasket.
Capillary Tube Brazed Parts Heating
Heat brazed parts of the capillary tube to remove it.
Compressor Removal
Terminal Cover and Pipe Disconnection
Remove terminal cover and disconnect brazed parts/pipes.
Compressor Lead Wires and Gasket
Disconnect compressor lead wires and remove the gasket.
Compressor Brazed Pipe Heating
Heat brazed parts of discharge and suction pipes to disconnect.
Compressor Nut Removal
Remove the nuts securing the compressor to the base.
