- Page 1 HP StorageWorks Modular Smart Array 50 Storage Enclosure User Guide May 2005 (Second Edition) Part Number 379396-002...
- Page 2 © Copyright 2005 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
-
Page 3: Table Of Contents
Contents Component identification Front panel LEDs and buttons......................7 Rear panel components ........................8 Rear panel LEDs and buttons....................... 9 SAS and SATA drive numbers ......................10 SAS and SATA hard drive LEDs....................... 11 SAS and SATA hard drive LED combinations.................. 11 Operations Power up the storage enclosure...................... - Page 4 HP StorageWorks Modular Smart Array 50 Storage Enclosure User Guide Configuration and utilities Configuration tools ..........................31 Array Configuration Utility ....................31 Option ROM Configuration for Arrays .................. 32 Management tools ..........................32 HP Systems Insight Manager....................33 Management Agents ....................... 33 Diagnostic tools ..........................
- Page 5 Contents Electrostatic discharge Preventing electrostatic discharge...................... 51 Grounding methods to prevent electrostatic discharge ..............52 Specifications Environmental specifications ......................53 Storage enclosure specifications ......................53 Technical support Before you contact HP ........................55 HP contact information ........................55 Acronyms and abbreviations Index...
-
Page 7: Component Identification
Component identification In this section Front panel LEDs and buttons ......................7 Rear panel components........................8 Rear panel LEDs and buttons ......................9 SAS and SATA drive numbers.....................10 SAS and SATA hard drive LEDs ....................11 SAS and SATA hard drive LED combinations ................11 Front panel LEDs and buttons Item Description... -
Page 8: Rear Panel Components
HP StorageWorks Modular Smart Array 50 Storage Enclosure User Guide Item Description Status Fault LED Off = No fault condition Amber = Fault condition Heartbeat LED Green = System activity Off = No system activity Power On/Standby Green = On... -
Page 9: Rear Panel Leds And Buttons
Component identification Rear panel LEDs and buttons Item Description Status I/O module fault Green = No fault condition Amber = Fault condition Power supply 1 LED Green = Power available Amber = Fault condition Off = Power supply unseated from connector or failed Power supply 2 LED Green = Power available... -
Page 10: Sas And Sata Drive Numbers
HP StorageWorks Modular Smart Array 50 Storage Enclosure User Guide Item Description Status Fault LED Off = No fault condition Amber = Fault condition Heartbeat LED Green = System activity Off = No system activity SAS and SATA drive numbers... -
Page 11: Sas And Sata Hard Drive Leds
Component identification SAS and SATA hard drive LEDs Item Description Fault/ID LED (amber/blue) Online LED (green) SAS and SATA hard drive LED combinations NOTE: Predictive failure alerts can occur only when the storage enclosure is connected to a Smart Array controller. Online/Activity Fault/UID LED Interpretation... -
Page 12: Hp Storageworks Modular Smart Array 50 Storage Enclosure User Guide
HP StorageWorks Modular Smart Array 50 Storage Enclosure User Guide Online/Activity Fault/UID LED Interpretation LED (green) (amber/blue) Flashing regularly Amber, flashing Do not remove the drive. Removing a drive may terminate (1 Hz) regularly (1 Hz) the current operation and cause data loss. -
Page 13: Operations
Operations In this section Power up the storage enclosure ....................13 Power down the storage enclosure ....................14 Important Safety Information Before installing this product, read the Important Safety Information document provided. Power up the storage enclosure Observe the following guidelines before powering up the storage enclosure: Always install all components of the storage enclosure. -
Page 14: Power Down The Storage Enclosure
HP StorageWorks Modular Smart Array 50 Storage Enclosure User Guide Power down the storage enclosure CAUTION: In systems that use external data storage, be sure that the server is the first unit to be powered down and the last to be powered back up. -
Page 15: Setup
Setup In this section Rack planning resources.......................15 Optimum environment........................16 Rack warnings ..........................19 Shipping contents .........................20 Installing the storage enclosure into the rack ................20 Installing hardware options ......................21 Installing servers...........................21 Choosing a configuration......................22 Cabling the storage enclosure.......................23 Updating firmware........................25 Rack planning resources The rack resource kit ships with all HP branded or Compaq branded 9000, 10000, and H9 series racks. -
Page 16: Optimum Environment
HP StorageWorks Modular Smart Array 50 Storage Enclosure User Guide – Coupling multiple racks The Rack Products Documentation CD enables you to view, search, and print documentation for HP and Compaq branded racks and rack options. It also helps you set up and optimize a rack in a manner that best fits your environment. -
Page 17: Temperature Requirements
Setup CAUTION: Always use blanking panels to fill empty vertical spaces in the rack. This arrangement ensures proper airflow. Using a rack without blanking panels results in improper cooling that can lead to thermal damage. The 9000 and 10000 Series racks provide proper server cooling from flow- through perforations in the front and rear doors that provide 64 percent open area for ventilation. -
Page 18: Power Requirements
HP StorageWorks Modular Smart Array 50 Storage Enclosure User Guide Power requirements Installation of this equipment must comply with local and regional electrical regulations governing the installation of IT equipment by licensed electricians. This equipment is designed to operate in installations covered by NFPA 70, 1999 Edition (National Electric Code) and NFPA-75, 1992 (code for Protection of Electronic Computer/Data Processing Equipment). -
Page 19: Electrical Grounding Requirements
Setup Electrical grounding requirements The storage enclosure must be grounded properly for proper operation and safety. In the United States, you must install the equipment in accordance with NFPA 70, 1999 Edition (National Electric Code), Article 250, as well as any local and regional building codes. -
Page 20: Shipping Contents
HP StorageWorks Modular Smart Array 50 Storage Enclosure User Guide • At least two people are needed to safely unload the rack from the pallet. An empty 42U rack can weigh as much as 115 kg (253 lb), can stand more than 2.1 m (7 ft) tall, and may become unstable when being moved on its casters. -
Page 21: Installing Hardware Options
Setup Use the following information when connecting peripheral cables and power cords to the storage enclosure. Item Description SAS In connector SAS Out connector Power supply 1 Power supply 2 Installing hardware options Install any hardware options before initializing the storage enclosure. For options installation information, refer to the option documentation. -
Page 22: Choosing A Configuration
HP StorageWorks Modular Smart Array 50 Storage Enclosure User Guide NOTE: When installing servers, HP recommends installing all storage enclosures at the bottom of the rack. To optimize cabling access, avoid interleaving the storage enclosure and server products. Choosing a configuration Cable procedures vary, depending on the configuration. -
Page 23: Cascading (1+1) Configuration
Setup Cascading (1+1) configuration Item Description MSA50 storage enclosure 1 MSA50 storage enclosure 2 SAS cable SAS cable Server Cabling the storage enclosure After installing the storage enclosure in a rack, connect the SAS cables and power cords to the rear panel. Supported cables A 2-m (6.56-ft) SAS cable ships standard with the storage enclosure. -
Page 24: Sas Cabling Guidelines
HP StorageWorks Modular Smart Array 50 Storage Enclosure User Guide SAS cabling guidelines Observe the following guidelines: Only use supported SAS cables with 3-GB connectors Always be sure that the servers attached to the storage enclosure are powered down and power cords are disconnected before connecting SAS cables. -
Page 25: Updating Firmware
Setup Updating firmware To update storage enclosure firmware, refer to the HP website (http://www.hp.com/msa50). After installing hardware and powering up the storage enclosure for the first time, be sure to verify that the host controllers and drives have the latest firmware. -
Page 27: Hardware Options Installation
Hardware options installation In this section Hard drive options ........................27 Hard drive options The storage enclosure supports up to 10 SFF SAS drives. Always populate hard drive bays starting with the lowest drive number ("SAS and SATA drive numbers" on page 10). SAS and SATA hard drive guidelines When adding hard drives to the storage enclosure, observe the following general guidelines:... - Page 28 HP StorageWorks Modular Smart Array 50 Storage Enclosure User Guide 2. Remove the hard drive blank. 3. Prepare the hard drive.
- Page 29 Hardware options installation 4. Install the hard drive. IMPORTANT: When the drive is inserted, the drive LEDs flash for 2 seconds to indicate that the drive is seated properly and receiving power. 5. Determine the status of the hard drive from the SAS and SATA hard drive LED combinations (on page 11).
-
Page 31: Configuration And Utilities
Configuration and utilities In this section Configuration tools ........................31 Management tools ........................32 Diagnostic tools ..........................33 Remote support and analysis tools ....................34 Keeping the system current ......................35 Configuration tools List of tools: Array Configuration Utility ......................31 Option ROM Configuration for Arrays ..................32 Array Configuration Utility NOTE: ACU does not support mixing SAS and SATA drives in the... -
Page 32: Option Rom Configuration For Arrays
HP StorageWorks Modular Smart Array 50 Storage Enclosure User Guide For optimum performance, the minimum display settings are 800 × 600 resolution and 256 colors. Servers running Microsoft® operating systems require Internet Explorer 5.5 (with Service Pack 1) or later. For Linux servers, refer to the README.TXT file for additional browser and support information. -
Page 33: Hp Systems Insight Manager
Configuration and utilities HP Systems Insight Manager HP SIM is a web-based application that allows system administrators to accomplish normal administrative tasks from any remote location, using a web browser. HP SIM provides device management capabilities that consolidate and integrate management data from HP and third-party devices. IMPORTANT: You must install and use HP SIM to benefit from the Pre-Failure Warranty for processors, hard drives, and memory modules. -
Page 34: Array Diagnostic Utility
HP StorageWorks Modular Smart Array 50 Storage Enclosure User Guide You can view recorded events in the IML in several ways, including the following: From within HP SIM ("HP Systems Insight Manager" on page 33) From within Survey Utility From within operating system-specific IML viewers –... -
Page 35: Keeping The System Current
Configuration and utilities Keeping the system current List of tools: Change control and proactive notification..................35 Natural language search assistant ....................35 Care Pack............................35 Change control and proactive notification HP offers Change Control and Proactive Notification to notify customers 30 to 60 days in advance of upcoming hardware and software changes on HP commercial products. -
Page 37: Removal And Replacement Procedures
Removal and replacement procedures In this section Safety considerations........................37 Hard drive blank ...........................37 Hot-plug SAS or SATA hard drive ....................38 Hot-plug power supply .........................40 Hot-plug fan..........................40 Safety considerations Before performing service procedures, review all the safety information. Hard drive blank CAUTION: To prevent improper cooling and thermal damage, do not operate the storage enclosure unless all bays are populated with either a component or a blank. -
Page 38: Hot-Plug Sas Or Sata Hard Drive
HP StorageWorks Modular Smart Array 50 Storage Enclosure User Guide To replace the blank, slide the blank into the bay until it locks into place. Hot-plug SAS or SATA hard drive You can replace hard drives without powering down the system. However,... - Page 39 Removal and replacement procedures – In RAID 1+0 configurations, any drives that are not mirrored to other removed or failed drives can be simultaneously replaced offline without data loss. To remove the component: CAUTION: To prevent improper cooling and thermal damage, do not operate the storage enclosure unless all bays are populated with either a component or a blank.
-
Page 40: Hot-Plug Power Supply
HP StorageWorks Modular Smart Array 50 Storage Enclosure User Guide In fault-tolerant configurations, allow the replacement drive to be reconstructed automatically with data from the other drives. While reconstruction is in progress, the online LED flashes. Hot-plug power supply CAUTION: To prevent improper cooling and thermal damage, do not operate the storage enclosure unless all bays are populated with either a component or a blank. - Page 41 Removal and replacement procedures To remove the component: To replace the component, reverse the removal procedure.
-
Page 43: Regulatory Compliance Notices
Korean notice A&B ........................49 Battery replacement notice ......................49 Taiwan battery recycling notice ....................50 Power cord statement for Japan....................50 Regulatory compliance identification numbers For the purpose of regulatory compliance certifications and identification, this product has been assigned a unique regulatory model number. The regulatory model number can be found on the product nameplate label, along with all required approval markings and information. -
Page 44: Federal Communications Commission Notice
HP StorageWorks Modular Smart Array 50 Storage Enclosure User Guide Federal Communications Commission notice Part 15 of the Federal Communications Commission (FCC) Rules and Regulations has established Radio Frequency (RF) emission limits to provide an interference-free radio frequency spectrum. Many electronic devices, including computers, generate RF energy incidental to their intended function and are, therefore, covered by these rules. -
Page 45: Class B Equipment
(2) this device must accept any interference received, including interference that may cause undesired operation. For questions regarding this product, contact us by mail or telephone: Hewlett-Packard Company P. O. Box 692000, Mail Stop 530113 Houston, Texas 77269-2000 1-800-HP-INVENT (1-800-474-6836). (For continuous quality improvement, calls may be recorded or monitored.) -
Page 46: Cables
Regulations. Modifications The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by Hewlett-Packard Company may void the user’s authority to operate the equipment. European Union regulatory notice... -
Page 47: Canadian Notice (Avis Canadien)
Regulatory compliance notices This marking is valid for non-Telecom products and EU harmonized Telecom products (e.g. Bluetooth). This marking is valid for EU non-harmonized Telecom products. *Notified body number (used only if applicable—refer to the product label) Canadian notice (Avis Canadien) Class A equipment This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. -
Page 48: Japanese Notice
HP StorageWorks Modular Smart Array 50 Storage Enclosure User Guide Japanese notice BSMI notice... -
Page 49: Korean Notice A&B
Regulatory compliance notices Korean notice A&B Class A equipment Class B equipment Battery replacement notice WARNING: The computer contains an internal lithium manganese dioxide, a vanadium pentoxide, or an alkaline battery pack. A risk of fire and burns exists if the battery pack is not properly handled. -
Page 50: Taiwan Battery Recycling Notice
HP StorageWorks Modular Smart Array 50 Storage Enclosure User Guide • Do not attempt to recharge the battery. • Do not expose the battery to temperatures higher than 60°C (140°F). • Do not disassemble, crush, puncture, short external contacts, or dispose of in fire or water. -
Page 51: Electrostatic Discharge
Electrostatic discharge In this section Preventing electrostatic discharge ....................51 Grounding methods to prevent electrostatic discharge..............52 Preventing electrostatic discharge To prevent damaging the system, be aware of the precautions you need to follow when setting up the system or handling parts. A discharge of static electricity from a finger or other conductor may damage system boards or other static- sensitive devices. -
Page 52: Grounding Methods To Prevent Electrostatic Discharge
HP StorageWorks Modular Smart Array 50 Storage Enclosure User Guide Grounding methods to prevent electrostatic discharge Several methods are used for grounding. Use one or more of the following methods when handling or installing electrostatic-sensitive parts: Use a wrist strap connected by a ground cord to a grounded workstation or computer chassis. -
Page 53: Specifications
Environmental specifications Specification Value Temperature range* Operating 10 C to 35 C (50 F to 95 F) Shipping -30 C to 50 C (-22 F to 122 F) Storage -40°C to 70°C (-40°F to 158°F) Maximum wet bulb 28 C (82.4 F) - Page 54 HP StorageWorks Modular Smart Array 50 Storage Enclosure User Guide Specification Value Width 42.62 cm (16.78 in) Weight (maximum) 16.78 kg (37 lb) Weight (no drives installed) 12.7 kg (27.5 lb)
-
Page 55: Technical Support
Technical support In this section Before you contact HP........................55 HP contact information.........................55 Before you contact HP Be sure to have the following information available before you call HP: Technical support registration number (if applicable) Product serial number Product model name and number Applicable error messages Add-on boards or hardware Third-party hardware or software... - Page 56 HP StorageWorks Modular Smart Array 50 Storage Enclosure User Guide – Call 1-800-HP-INVENT (1-800-474-6836). This service is available 24 hours a day, 7 days a week. For continuous quality improvement, calls may be recorded or monitored. – If you have purchased a Care Pack (service upgrade), call 1-800-633- 3600.
-
Page 57: Acronyms And Abbreviations
Acronyms and abbreviations Array Configuration Utility Advanced Data Guarding (also known as RAID 6) Array Diagnostics Utility Canadian Standards Association host bus adapter International Electrotechnical Commission IEEE Institute of Electrical and Electronics Engineers Integrated Management Log... - Page 58 HP StorageWorks Modular Smart Array 50 Storage Enclosure User Guide Modular Smart Array MSA50 Modular Smart Array 50 National Electrical Code NEMA National Electrical Manufacturers Association NFPA National Fire Protection Association ORCA Option ROM Configuration for Arrays OSEM Open Services Event Manager...
- Page 59 Acronyms and abbreviations serial attached SCSI SATA serial ATA SCSI small computer system interface small form-factor Systems Insight Manager TMRA recommended ambient operating temperature unit identification...
-
Page 61: Index
