Summarization of Contents
Safety Information
Important Safety Information
Key procedures and warnings to prevent hazards to persons and damage to the product.
Description
1.1 Principle of operation
Explains the working mechanism of the single-stage, oil-sealed rotary vane vacuum pump.
1.2 Technical characteristics
Details performance specifications for SV10B and SV16B models, including speed, pressure, and noise levels.
1.3 Connection fittings
Lists and illustrates various connection fittings, their specifications, and catalog numbers for the pumps.
1.4 Spare parts
Identifies essential spare parts and kits for maintenance and repair, including part numbers.
1.5 Lubricants
Recommends specific mineral oils (VG32) and Leybold's LVO120 for pump lubrication.
Transport and Storing
2.1 Transport and packing
Guidelines for safe transport and packing of vacuum pumps to prevent damage and environmental release.
2.2 Mounting orientation
Specifies the correct upright position for moving pumps filled with oil to prevent leakage.
2.3 Storage
Instructions for long-term storage, including returning to original condition and required maintenance.
Installation
3.1 Setting-up
Details requirements for pump setup, including flat surface mounting and ambient operating conditions.
3.2 Inlet connection
Guidance on connecting the inlet flange with vacuum-tight hoses/pipes, avoiding stresses and restrictions.
3.3 Connection to exhaust side
Recommendations for exhaust line installation, diameter, and preventing condensate entry into the pump.
3.4 Oil filling
Procedure for filling the pump with oil, checking the level against the MAX-mark.
3.5 Electrical connection
Instructions for electrical installation, voltage/frequency matching, and motor overload protection.
Operation
4.1 Operating advices
Guidance on using the gas ballast valve for condensable vapours and pump run-in procedures.
4.2 Shutdown
Information on pump shutdown procedures, including the function of the anti-suck back valve.
Maintenance
5.1 Safety Information
Essential safety precautions for maintenance, including switching off the pump and using trained personnel.
5.2 Maintenance Intervals
Provides a schedule of maintenance jobs, their frequency, and corresponding sections for normal operation.
5.3 Leybold Service
Procedure for returning equipment for service, requiring contamination declarations for safety.
5.4 Maintenance Work
Detailed steps for checking oil levels and changing oil, including precautions for pollution.
