Table 2 lists the specifications for the Intel
Specification
Processor
(PCI Controller)
Operating Voltage
Card Size
Array Interface
to Host
SAS Bus Speed
SAS Controller
SAS / SATA Ports
Cache
Firmware
Compatible Devices
Cabling
Redundant
Configuration
Enclosure
Management

Array Performance Features

Table 3 shows the RAID Controller SRCSASPH16I array performance features.
Specification
PCI Express* Host
Data Transfer Rate
Drive Data Transfer
Rate
Maximum
Scatter/Gathers
Intel® RAID Controller SRCSASPH16I Hardware Guide

Table 2. Specifications

®
Intel 80333 I/O processor at 500 MHz
+3.3 V, +12 V
Full-height PCI Express* adapter card size (6.6 inches by 4.2 inches)
PCI Express* Rev 1.0A, x8 lane width 2.5 Gbps
3 GBps per port, point-to-point
One LSI SAS 1068 controller
4x4 internal ports. Supports 122 SAS/SATA devices using expanders, 64
virtual disks.
Integrated 256 MB RAM, optional battery backup
4 MB in reflashable flash ROM
Mixed capacity, mixed SATA and SAS in different enclosures; non-disk
devices, including expanders.
Small, thin cables do not restrict airflow; shared connectors for multiple
drive types.
32 Kb NVRAM and config on disk (COD) store RAID configuration.
2
I C out-of-band, SES2 in-band, SAF-TE (LEDs)

Table 3. Array Performance Features

2.5 Gigabit/s per lane
3 Gigabit/s per lane
26 elements
®
RAID Controller SRCSASPH16I.
®
Intel RAID Controller SRCSASPH16I
®
Intel RAID Controller SRCSASPH16I
