3 Intel
SRCSASPH16I Characteristics
This chapter describes the characteristics of the Intel
Figure 4 displays the connectors and headers on the controller and Table 1 describes them.
Jumper
J1
J2
J3
J4
J5
Intel® RAID Controller SRCSASPH16I Hardware Guide
®
RAID Controller

Table 1. Jumper Descriptions

Description
2
Keyed I C 3-pin
connector connector
Port activity LED 8x2 header
header (8-15)
Drive Fault LED 8x2 header
header (8-15)
Internal SAS/SATA SFF8087
port connector,
ports 12-15
Internal SAS/SATA SFF8087
port connector,
ports 8-11
®
RAID Controller SRCSASPH16I.
Figure 4. Card Layout
Type
Out-of-band enclosure management (SAF-TE).
LED signal for activity per port for 8-15 ports.
LED signal support for front panel drive fault per
port (8-15).
Connection to SAS/SATA devices.
Connection to SAS/SATA devices.
s
Comments
12
